Sida 1/2
1. Battery Installation
1) Use the included the T10 Torx tool unscrew battery cover screw until the battery to
cover can be opened as shown in Fig 2.
2) Inspect the battery compartment for dirt, moisture, or corrosion, and then clean
the battery compartment if needed.
3) Inspect the O-ring seal on the battery cover to make sure that it is free of sand and
dirt particles and that it has not been damaged.
4) Install the battery as marked on the battery compartment floor with the ribbon
under the battery cell to help with future battery removal. (See Fig 2 ).
5) After installing the battery, close the battery cover and use the included the T10
Torx tool rotate the battery cap screw until secure .to clockwise
Caution:
The P.ID includes a flat top 18350 Li-ion battery which requires use of the included
charging cable or a high quality charger only. Frequently inspect the condition of the
battery, including the terminals and outer shrink wrap. Do not use a battery with
signs of damage.
1) High Power White LED with Visible Laser (DUAL includes IR Laser)
2) Rechargeable 18350 battery
3) Magnetic Charging Port
4) CNC Milled 7075 Aluminum Housing
5) IP68 Dust and Waterproof
6) 2 Rail Interface Adapters
www.holosun.com
WEAPON LIGHT + LASER SIGHT
P.ID PLUS
P.ID DUAL
System Description
Battery
Thank you for purchasing the P.ID PLUS/DUAL from HOLOSUN The P.ID .
PLUS/DUAL is a weapon combines a visible laser (PLUS) or visible light system that
and IR laser (DUAL) high-power LED designed for Positive with a white light
IDentification in all-weather and . lighting conditions The P.ID PLUS/DUAL attaches
to any firearm that uses a MIL-STD 1913 Picatinny rail and includes adapters for
universal compatibility. This product is a Class III laser. Before operation, please
read the User's Manual carefully:
2. Battery Recharging
1) The recharging voltage for the P.ID PLUS/DUAL is DC5V.
2) Connect the USB end of the charging cable to an external USB power source,
then attach the opposite end of the magnetic charging cable to the charging port of
the sight (See Fig 3)..
I. Red indicator light: charging
ii. Green indicator light: fully charged
Caution:
Do not connect the charger if there is no battery installed.
Do not use a disposable battery.
Please keep the charging port clean, wipe any dust or debris away before charging.
The P.ID PLUS/DUALcan only be charged with the included magnetic charging
cable, that is not compatible with other MCC cables.
Fig 2
2
WARNING:
1. Do not point the light or laser towards human eyes.
This may cause temporary, or permanent damage to
the eyes.
2. Do not look into the laser through binoculars or
telescopes.
Important Notices
1. Component Description
2. Packaging
The P.ID PLUS/DUAL packaging includes the following items:
1) P. ID PLUS or DUAL Light w/ Laser Sight(s)
2) User Manual
3) 2 Rail Interface Adapter Inserts(Adapter 1 is installed on the product)
4) T10 Torx Tool
5) USB Magnetic Charging Cable
6) Flat Top 18350 Battery
when the light is on. The radiant energy of the light may cause damage to the light
itself, or even result in burning other materials.
5. Do not leave the light in any type of fabric bag or fusible plastic container under
high temperature.
CAUTION:
1. Ensure the firearm is unloaded and safe by removing all ammunition and
magazines from firearm and verifying an empty chamber before installation and
battery replacement.
DO NOT ATTEMPT TO INSTALL THIS SIGHT KIT ON A
LOADED FIREARM
.
2. Remove the P.ID PLUS/DUAL from the firearm and ensure the light is OFF before
performing any inspections.
3. Please remove the battery before storing the light for a long period of time.
4. Please keep the packaging should you need to make a warranty claim.
1
User Manual
Features
Fig 3
Battery
Compartment
Battery
Battery Insulation
Material
Battery Cover
O-Ring Seal
Screw
THIS PRODUCT COMPLIES WITH 21CFR PARTS
1040.10 AND 1040.11 EXCEPT FOR DEVIATION
PURSUANT TO LASER NOTICE 50 DATED JUNE 24,2007.
THIS PRODUCT COMPLIES WITH IEC
60825-1:2007-03 ED. 2.0 AND IEC
60825-1:2014-05 ED. 3.0
WARNING VISIBLE AND INVISIBLE
LASER RADIATION
DO NOT STARE INTO THE BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS II LASER PRODUCT
0.7mW @800-860nm CW
ÿ
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
5mW@500-670nm CW
ÿ
Fig 1
1 Bezel 9 VIS Windage Adjustment
2 Body 10 IR Windage Adjustment(DUAL)
3 Adapter Insert 11 IR Elevation Adjustment(DUAL)
4 Clamping Block 12 VIS Elevation Adjustment
5 Locking Screw 13 Battery Compartment Screw
6 Magnetic charging port 14 Battery Compartment
7 Mode Indicator(DUAL) 15 Bottom Activation Buttons
8 Charging Indicator 16 Top Activation Buttons
6
7
9
13
16
16
15
1
2
3
4
5
8
12
11
10
15
Charging Indicator
Magnetic charging
port
Mode
Indicator
(DUAL)
3. Do not point the laser beam at reflective surfaces.
4. Do not cover the light head, or place the light head down on the ground
Installation
1. Installation on an Accessory Rail
1) Using the included T10 torx tool, loosen the clamp block in order to install the P.ID
PLUS/DUAL on the accessory rail.
2) Press the head of the clamp screw to open up the rail clamp to it’s maximum width.
