Wired IO Module flush-mounted – 6

channels

HmIPW-FIO6

Installation and Operating Manual

Table of contents

1 Package contents.................................................................................................3

2 Information about this manual.........................................................................3

3 Hazard information..............................................................................................3

4 General system information..............................................................................5

5 Function and device overview..........................................................................5

6 Start-up.................................................................................................................. 5

6.1 Installation instructions...............................................................................................6

6.2 Selecting the supply voltage..................................................................................... 7

6.3 Installation..................................................................................................................... 8

6.4 Pairing with a control unit.........................................................................................9

7 Troubleshooting................................................................................................. 10

7.1 Command not confirmed........................................................................................ 10

7.2 Flash codes.................................................................................................................. 11

8 Restoring factory settings................................................................................ 12

9 Maintenance and cleaning...............................................................................12

10 Disposal.............................................................................................................. 12

11 Technical specifications..................................................................................13

Documentation © 03/2025 eQ-3 AG, Germany

processes without the written consent of the publisher.

It is possible that this manual may contain typographical errors or printing errors. However, the information contained in this manual is reviewed on

a regular basis and any necessary corrections will be implemented in the next edition. We accept no liability for technical or typographical errors or

the consequences thereof. All trademarks and industrial property rights are acknowledged.

Changes in line with technical progress may be made without prior notice.

Version 2.2

Package contents

1 Package contents

1x Wired IO Module flush-mounted –

6 channels

2x Connecting cable for inputs and

outputs

1x Operating manual

2 Information about this

manual

Read this manual carefully before begin-

ning operation with your HomematicIP

Wired device. Keep the manual for later

consultation. If you hand the device over

to other persons for use, please ask them

to read this manual.

Symbols used

This indicates a hazard.

This section contains important ad-

ditional information.

3 Hazard information

We accept no liability for damage

caused by use for other than the

intended purpose, incorrect han-

dling or failure to observe the haz-

ard warnings. In such cases, all war-

ranty claims are void. We accept no

liability for consequential damage.

Do not use the device if it has visi-

ble damage or a malfunction. If you

have any doubts, have the device

checked by a qualified expert.

For safety and licensing reasons

(CE), unauthorised conversions to

and/or modification of the device

are not permitted.

The device is not a toy – do not al-

low children to play with it.

Plastic film, plastic bags, polystyrene

parts, etc. can be dangerous for

children. Keep the packaging mate-

rial out of the reach of children and

dispose of it immediately.

Clean the device using a soft and

clean lint-free cloth. Do not use any

detergents containing solvents for

cleaning purposes.

Do not expose the device to mois-

ture, vibrations, constant solar or

other heat radiation, excessive cold

or mechanical loads. The device

must only be operated indoors.

Overloading the device can lead

to the destruction of the device, to

a fire or to an electrical accident.

Before connecting a load, check

the technical data, in particular the

maximum permissible connected

load and the type of load to be con-

nected (load types) in accordance

with the instructions. Load the de-

vice only up to the specified power

limit.

Loads connected to the output ter-

minals require sufficient insulation.

Produktspecifikationer

Varumärke:	Homematic IP
Kategori:	Smarth hem
Modell:	HMIPW-FIO6
Vikt:	20 g
Bredd:	57 mm
Djup:	14 mm
Höjd:	14 mm
Förpackningens bredd:	122 mm
Gränssnitt:	Kabel
Modell:	Väggmonterad
Antal kanaler:	6 kanaler
Driftspänning:	24 V
Produktens färg:	Grå
Låddjup:	36 mm
Vikt inkl. förpackning:	90 g
Temperatur vid drift:	-5 - 40 ° C
Internationellt skydd (IP) kod:	IP20
Anslutningsteknologi:	Kabel
Strömförbrukning i vänteläge:	0.06 W
