Sida 1/20
INSTRUCTIONS FOR INSTALLATION AND USE
MONTAGE- UND GEBRAUCHSANWEISUNG
INSTRUCTIONS POUR L'INSTALLATION ET L’UTILISATION
ISTRUZIONI PER L'INSTALLAZIONE E L’USO
INSTRUCCIONES PARA INSTALACIÓN Y USO
INSTRUÇÕES DE INSTALAÇÃO Y UTILIZAÇÃO
AANWIJZING VOOR GEBRUIK EN INSTALLATIE
ENGLISH
The hood may be in the filtering or the ducting version.
Filtering version (Fig. 1A or 1B): The hood aspirates the kitchen air saturated with fumes and odours, purifies it through
the grease filters and charcoal filter and returns clean air into the room. For constant efficiency, the charcoal filter must
be replaced periodically. The charcoal filter is not supplied.
Ducting version (Fig. 2): The hood aspirates the kitchen air saturated with fumes and odours, passes it through the
grease filters and expels it to the outside through an outlet pipe. With this version the charcoal filter is not required. Decide
from the outset on the type of installation (filtering or ducting). For greater efficiency, we recommend you install the hood
in the ducting version (if possible).
INSTALLATION
ATTENTION: Two persons are required for proper installation; the unit should be installed by a qualified
operator. Remove the grease filters before proceeding with the assembly instructions. This will make the appliance easier
to handle.
1. Removal of grease filters: Fig. 3: push the stop towards the rear of the appliance and turn the filter outwards.
INSTALLATION IN DUCTING VERSION: Before fixing, the outlet pipe for air evacuation to the outside must be
installed. Use an outlet pipe with: minimum indispensable length; minimum possible bends (maximum angle of bend:
90°); certified material (according to the State); an as smooth as possible inside. It is also advisable to avoid any
drastic changes in pipe cross-section (recommended diameter: 150 mm). For air evacuation to the outside, follow all the
other instructions given on the “Warnings” sheet. Prepare the power supply within the telescopic chimney (for the electrical
connection, follow all the other instructions on the “Warnings” sheet).
2. Fixing to the wall: Draw a line on the wall in vertical line with your hob. Mark the first 2 holes to be drilled in
the wall, respecting the distances indicated in Fig. 4. Drill the 2 holes and fit the screw anchors provided. As already specified
on the “Warnings” sheet, bear in mind that the distance between the lower edge of the hood and the hob must be min.
650 mm. Fix the metal bracket (A) to the wall using the 2 holes just drilled (Fig. 5); the screws for fixing the bracket are
provided. Use the 2 cut-out triangles on the bracket to position it exactly along the vertical axis of the hood. Hang the
hood on the bracket (Fig. 6). Adjust the horizontal position moving the hood to the right or left so that it is aligned with
the wall units. If you also need to adjust the hood in height, operate on the adjusting screws (B) provided. When adjustment
has been completed, without removing the hood, mark the other 4 holes to be drilled (C) in the wall. Remove the hood
and drill the holes marked (8 mm diameter). Then use the 4 screw anchors and the 4 screws provided for final fixing.
3. Flange assembly: set the flange (E) over the motor and press slightly (Fig. 7).
4. Mount the plate of the electrical system fixing it with 3 screws (Fig. 7V).
5. Fixing the telescopic flues:
5a - Adjust the width of the support bracket (D) of the telescopic flue by means of the screws (E) as shown in Fig.8; then,
by means of the screw anchors and screws (F) provided, fix the bracket to the ceiling in such a way that it is positioned
along the axis with your hood.
5b - Connect the air outlet pipe to the air vent of the hood. - Use a flexible pipe and lock it to the air vent of the hood
with a metal hose clamp - Fig. 9 (pipe and clamp are not provided). - For exhaust hoods, turn the upper flue over so that
the air exhaust grid is in the lower section (Fig. 10).
5c - Plug in the hood. Insert the extension flues setting them on the hood; extend the upper flue to the ceiling and secure
with the 2 screws (H) - Fig. 11.
INSTALLATION IN FILTERING VERSION: Prepare the power supply within the telescopic flues (for the electrical
connection, follow all the other instructions on the “Warnings” sheet).
Fixing to the wall: for fixing to the wall refer to the instructions for the ducting version (see points 2, 3, and 4), then
continue with the instructions below.
Fixing the telescopic flues: - Adjust the width of the support bracket (D) of the telescopic flue by means of the
screws (E) as shown in Fig. 8. - Then, by means of the screw anchors and screws (F) provided, fix the bracket to the
ceiling in such a way that it is positioned along the axis with your hood. - Mount the flange on the hood in correspondence
to the air outlet point (Fig. 12). – Take the air baffle and fit a flexible pipe to it (125 mm diameter) locking it with a metal
hose clamp (pipe and clamps are not provided). Fit the air baffle to the upper flue (Fig. 13) with 4 screws.
- Connect the flexible pipe to the flange on the air vent (Fig. 14). - Plug in the hood. Insert the extension flues setting
them on the hood; extend the upper flue to the ceiling and secure with the 2 screws H (Fig. 11). - Install the charcoal
filter fitting the two filter clips in their housings (Fig. 15) and turning the filter upward.
OPERATION
CONTROLS shown in Fig. 16:
A) Turns the LIGHTS on and off.
B) Turns the LUMINOUS STRIP on and off.
C) Reduces the motor speed until reaching zero. If pressed for 2" the motor is turned off.
D) Activates the motor (calling the last speed used) and increases the speed until reaching maximum..
E) FILTER ALARM/TIMER RESET: when pressing the key during display of the filter alarm (motor off) it resets the hour
counter. When pressing the key when the motor is running, the TIMER is activated and the hood will automatically be switched
L1) The 4 green LEDs indicate the running speed.
L2) When the LED is red (motor off) it indicates the FILTER ALARM. When the LED is green (flashing) it indicates that
the TIMER has been activated with the key E.
FILTER ALARM:
After 30h of operation, the LED L2 turns RED. It indicates that the grease filters need to be cleaned.
After 120h of operation, the LED L2 turns RED and flashes; It indicates that the grease filters need to be cleaned and
the charcoal filters replaced.
After cleaning the grease filters (and/or replacing the charcoal filters), restart the hour counter (RESET) by pressing the
key E during display of the filter alarm.
Grease filters: special attention must be given to the grease filters which must be periodically cleaned, whenever
the grease filter alarm trips. For instructions of the filter Alarm, refer to the Controls paragraph. Remove the filters as
shown in para. 1 and wash with neutral detergent.
Charcoal filters: if the filtering version appliance is used, the charcoal filters will have to be periodically replaced
when the charcoal filter alarm trips. For instructions on the filter Alarm, refer to the Controls paragraph. Removing the charcoal
filter/s: first of all, remove the grease filters; push the catch inwards (Fig. 3) and remove the charcoal filter from its case
(Fig. 15). Reposition a new charcoal filter of the same type inverting the operations.
Lighting: to change the halogen bulbs open the cover levering from the proper slots (Fig. 17). Replace with bulbs
of the same type. CAUTION: Do not handle glass bulb with bare hands. If, after replacing the halogen lights,
these fail to work, allow the appliance to cool and then interrupt power for a few seconds.

Produktspecifikationer

Varumärke: Hoover
Kategori: Fläktkåpa
Modell: HSHD 9102 X
Vikt: 21100 g
Bredd: 900 mm
Djup: 570 mm
Höjd: - mm
Motoreffekt: 290 W
Antal lampor: 2 lampor
Höjd (min): 671 mm
Antal filter: 2 styck
Strömförsörjning: 230 - 240 V, 50 Hz
Antal hastigheter: 4
Modell: Väggmonterad
Produktens färg: Rostfritt stål
Kontrolltyp: Knappar
Vikt inkl. förpackning: 27700 g
Fettfilter typ: Metall
Höjd (max.): 898 mm
Lamptyp: halogen
Ljudnivå Lc IEC: 59 dB
Typ av fläkt: Frånluft/recirkulerande
Maximal flödeskapacitet: 700 m³/h
Förpackningsstorlek (B x D x H): 1040 x 530 x 695 mm
