CR1-2-3B-HS(-L)
3/19/15
Item # 13276
Hoshizaki America, Inc. reserves the right to change
specifications without notice.
*AutoCad available on KCL
Item #
Project:
Qty:
• Stainless steel exterior front and sides
• Energy efficient, vacuum formed, seamless, one piece ABS interior liner
• Refrigerant flow is controlled with a TXV expansion valve
• Unique “ducted” air distribution system
• Solid state digital controller with temperature alarms and LED display (Fahrenheit or Celsius)
• Cabinet and doors are insulated with 2-3/8” of R-134a, CFC free, foamed in place polyurethane
• Doors are constructed of stainless steel exterior, an ABS interior liner and are standard with locks
• Exclusive "stepped" door design to protect recessed door gasket
• Spring assisted self closing doors with stay open feature
• Sturdy 8 gauge stainless steel hinge plate with welded hinge pin
• One piece, full length, extruded aluminum flush mount door handle
• Field reversible doors (with optional kit)
• Enamel coated evaporator coil
• Automatic hot gas condensate evaporator
• Stainless steel shelf supports
• (3) Epoxy coated wire shelves per section adjustable 1” on center
• Standard with 4" factory installed casters (two with brakes)
• Stackable (two units high) to conserve warehouse floor space
• Three years parts and labor warranty
• Five year compressor warranty
• 8 ft. cord and plug
* CR1B-HS is ENERGY STAR qualified
CRB-HS Dimensions
W x D x H
1
Section - 27.5” x 33.6” x 79.63”*
2 Section - 55” x 33.6” x 79.63”*
3 Section - 84” x 33.6” x 79.63”*
*
with 4” casters
Electrical/Refrigeration
Voltage 115/60/1
H
ACR Breaker
1
& 2 Section - 15.0
3 Section - 20.0
Electrical Connection (NEMA)
1 & 2 Section - 5-15P
3 Section - 5-20P
Voltage Range 104-126
Ambient Temp. Range 45˚-100˚F
Control Setpoint Range 34˚ to 52˚F
*Refrigerant R-134a
Warranty
Valid in United States, Canada, Puerto Rico,
and U.S. Territories. Contact factory for
warranty in other countries.
• Three Year - Parts & Labor on entire
machine.
• Five Year - Parts on: Compressor.
Options
• Door reversal kit
• Additional epoxy shelves
• Stainless steel shelves
• Combination universal tray/pan slides
• Air filter
Dimensions / Capacity
Electrical & Refrigeration Data
Model # One Section
CR1B-HS(-L)
Two Section
CR2B-HS
Three Section
CR3B-HS
Nominal Storage Capacity (CF) 23.3 ft
3
51.0 ft
3
74.3 ft
3
Interior Storage Capacity (CF) (AHAM) 20.8 ft
3
47.0 ft
3
67.9 ft
3
Overall Width x Depth 27.5” x 33.6” 55” x 33.6” 84” x 33.6”
Height (including 4” casters) 79.63” 79.63” 79.63”
Door Opening Width x Height 22.8” x 28.1” 22.8” x 28.1” 22.8” x 28.1”
Depth with Door open at 90° 59.6” 59.6” 59.6”
Adjustable Shelves 3 6 6 (Left) 3 (Right)
Shelf Dimensions (W x D) 21.25” x 26” 23.9” x 24.6” 23.9” x 24.6” 21.25” x 26”
Crated Shipping Weight 345 lbs 540 lbs 875 lbs
Crated Height x Width x Depth 83” x 31.5” x 39.5” 83” x 59” x 39.5” 83” x 90.5” x 39.5”
Model # One Section
CR1B-HS(-L)
Two Section
CR2B-HS
Three Section
CR3B-HS
Amperage
3.7 7.0 12.0
Energy Consumption (kwh/day)
ENERGY STAR
2.28 3.52 5.80
Heat Rejection (BTU/Hr.) @ NSF
450 866 866 (Left) 450 (Right)
Approx. Nominal Compres. BTU/HR(HP)
1625(.2HP) 2373(.25+HP)
2373(.25+HP) 1625(.2HP)
CR1-2-3B-HS(-L)
Commercial Series Refrigerators
© HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269
TEL 800-438-6087
FAX 800-345-1325
www.hoshizaki.com
