Sida 1/2
KM-1900S_J(3)
STACKABLE CRESCENT CUBER
KM-1900S_J(3)
02/13/18
Item # 13190
Item #:
Project:
Qty:
AIA#:
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
* approximate size in inches, image not to scale
Features
• Up to 1933 lbs. of ice production per 24 hours
• Stackable for 3866 lbs. per 24 hours ice production
in the same floor space
• Durable stainless steel exterior
• Protected by H-Guard Plus
Antimicrobial Agent
• EverCheck
TM
alert system
• R-404A Refrigerant
Air-Cooled 1 Phase
Shown on optional bin: B-900
KM-1900SAJ
Individual crescent cube
Stainless steel evaporator
CycleSaver
TM
design
TM
TM
Available on Bins:
Warranty:
B-1500SS
B-1650SS
• Ambient Temp Range 45 - 100°F
• Water Temp Range 45 - 90°F
• Water Pressure 10 - 113 PSIG
• Voltage Range 187 - 253V
Operating Limits
• Icemaker Water Supply Line: Min. 3/8” Nominal ID Copper Water
Tubing or Equivalent
• Icemaker Drain Line: Min. 3/4” Nominal ID Hard Pipe or Equivalent
Water-Cooled Model (Lines Must Be Independent of Icemaker)
• Condenser Water Supply Line: Min. 3/8” Nominal ID Copper Water
Tubing or Equivalent
• Condenser Drain/Return Line: Min. 3/8” Nominal ID Hard Pipe
(open drain system) or Copper Water Tubing (closed loop system)
or Equivalent
Plumbing
• Panels easily removed and all components
accessible for service.
• Allow 6” (15 cm) clearance at rear, sides, and top
for proper air circulation and ease of maintenance/
service.
Service
48" x 27
3/8
" x 36
7/16
”
W x D x H
Hoshizaki reserves the right to change specifications without notice.
®
B-800
B-900
Valid in United States, Canada, Puerto Rico and U.S. Territories.
Contact factory for warranty in other countries.
Top kit may be required.
See Bin Spec Sheets.
Printed in the U.S.A.
B-1150SS
B-1300SS
Water-Cooled 1 Phase
KM-1900SWJ
Remote Air-Cooled 1 Phase
KM-1900SRJ
Air-Cooled 3 Phase
KM-1900SAJ3
Water-Cooled 3 Phase
KM-1900SWJ3
Remote Air-Cooled 3 Phase
KM-1900SRJ3
1
1/2
”
1/2
”
1
1/8
”
KMEdge
DESIGN
KM Edge Cube Dimensions*
1875
1880
1933
1865
1880
1933
KM-1900SAJ
KM-1900SWJ
KM-1900SRJ
KM-1900SAJ3
KM-1900SWJ3
KM-1900SRJ3
Air
1675
1875
1700
1675
1875
1700
3.90
3.20
3.90
3.90
3.20
3.90
19.0
21.0
19.0
19.0
21.0
19.0
N/A
85
N/A
N/A
85
N/A
30A
30A
30A
20A
20A
20A
Water
21,200
21,500
24,200
20,900
21,900
20,700
390 / 415
390 / 415
390 / 415
390 / 415
390 / 415
390 / 415
208-230V/60/1
208-230V/60/1
208-230V/60/1
208-230V/60/3
208-230V/60/3
208-230V/60/3
Remote
Air
Water
Remote
Air / Water Temp
Lbs. per 24 hours
Condenser
Model
70°/ 50°F 90°/ 70°F
ICE PRODUCTION
Potable
Gal. per 100 lbs.
Condenser
Gal. per 100 lbs.
Max. Fuse Size
or HACR
Circuit Breaker
Heat
Rejection
BTU/hr.
Voltage
WATER USAGE
90°/ 70°F 90°/ 70°F
ELECTRICAL
90°/ 70°F
kWh Used
per 100 lbs.
Amperage
1 Phase3 Phase
14.5A
15.8A
15.9A
8.9A
8.9A
13.5A
Circuit
Wires
(including ground)
Net / Ship
Weight (lbs.)
Refrigerant
Charge Amount
4*
4*
4*
4
4
4
4 lb. 10.1 oz.
3 lb. 1.4 oz.
13 lb. 12.5 oz.
4 lb. 10.1 oz.
3 lb. 1.4 oz.
13 lb. 12.5 oz
.
51
3/4
" x 33" x 43"
Shipping Dimensions
Please refer to water filter spec sheet for recommended configurations.
Water Filter
†
with condenser
*If neutral is not available, transformer kit (HS-5030) is required. Refer to Instruction Manual for installation and electrical requirements.
21 lbs. 7.9 oz.
†
21 lbs. 7.9 oz.
†
Power cord not included
