RH3-SSB-FG(HG)
10/14
Item #13280
RH3-SSB-FG(HG)
Professional Series Reach-in Refrigerators
nc. reserves the right to change
specifications without notice.
*AutoCad available on KCL
Item #
Project:
Qty:
• Stainless steel interior and exterior
• Energy efficient thermostatic expansion valve self contained refrigeration system
• EverCheck
®
digital control system with audio and visual alarms
• Entire cabinet is insulated with 2 3/8" foamed in place polyurethane
• Unique “ducted” air distribution system
• Glass doors are energy efficient Triple Pane, Argon filled with Low-E non reflective coating and locks
• Dual door frame heaters with energy saving on/off switch
• All metal torsion spring door hinge design with stay open feature
• Rugged, die cast aluminum door handles
• Door hinging is reversible at the factory
• Epoxy coated evaporator coil
• Hinged upper front panel for easy access to controller
• Removable, cleanable refrigeration system air filter
• Energy efficient automatic hot gas condensate evaporator
• (3) Epoxy coated wire shelves per section
• Standard with 4" factory installed casters (two with brakes)
• Three years parts and labor warranty
• Five year compressor warranty
• 8 ft. cord and plug
* RH3-SSB-FG is ENERGY STAR qualified
© HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269
TEL 800-438-6087
FAX 800-345-1325
www.hoshizaki.com
RH3-SSE-FG Dimensions
W x D x H
3
Section - 82.5” x 33.6” x 82.5”*
*with 4" casters
Electrical/Refrigeration
V
oltage -
115/60/1
H
ACR Breaker - 20.0
Electrical Connection - 5-20P
(NEMA)
Voltage Range 104 - 126
Ambient Temp. Range 45˚-100˚F
Control Setpoint Range 36˚-50˚F
*Refrigerant R-404A
Warranty
Valid in United States, Canada, Puerto Rico,
and U.S. Territories. Contact factory for
warranty in other countries.
• Three Year - Parts & Labor on entire
machine.
• Five Year - Parts on: Compressor.
Options
• 6” legs with stainless steel bullet feet
• Door reversal kit (Half Door only)
• Additional epoxy shelves
• Stainless steel shelves
• Foot pedal door opener
• Combination universal tray/pan slides
• Door padlock hasp
• NAFEM Data Protocol connection
(Software by other vendors)
Model # Three Section
RH3-SSB-FG
Three Section
RH3-SSB-HG
Interior Storage Capacity (CF) (AHAM) 74.0 ft
3
73.6 ft
3
Overall Width x Depth 82.5” x 33.6” 82.5” x 33.6”
Height (including 4” casters) 82.5”
Door Opening Width x Height 21.75” x 59.25” 21.75” x 26.75”
Depth with Door open at 90° 58.5”
Adjustable Shelves 9
Center Shelves 6
Shelf Dimensions (W x D) 21.25” x 26”
Crated Shipping Weight 825 lbs
Crated Height x Width x Depth 85” x 87” x 38”
Dimensions / Capacity
Model # Three Section
RH3-SSB-FG
Three Section
RH3-SSB-HG
Amperage 11.8 14
Energy Consumption (kwh/day)
ENERGY STAR
7.25 8.17
Heat Rejection (BTU/Hr.) 2080
Approx. Nominal Compres. BTU/HR(HP)
5200 BTU/HR(3/4HP)
Electrical & Refrigeration Data
*
