Instructions for

Installation and Use

50cm ELECTRIC COOKER

Contents

Safty Information, 2

Introduction, 6

Installation tips , 7

Features, control panel, 4

The Controls, 5

Electronic Timer/Minute Minder , 9

Use and Care of the Ceramic Hob, 10

Grilling, 13

Top Oven - Conventional Cooking, 14

Main Oven Cookery Notes, 14

Oven Cooking Charts - Baking, 15

Oven Cooking Charts - Meat, 16

Using The Main Oven

for other Functions, 17

Care and Cleaning, 18

Cooking Results Not Satisfactory?, 21

Something Wrong with your Cooker?, 22

ENEN

HD5V93CCB/UKHD5V93CCB/UKHD5V93CCB/UK

HD5V93CCW/UKHD5V93CCW/UKHD5V93CCW/UK

Installation, 23

HD5V93CCSS/UKHD5V93CCSS/UKHD5V93CCSS/UKHD5V93CCSS/UK

Care and maintenance

,19,19,19

SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

Before using the appliance, read these safety

instructions. Keep them nearby for future

reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all

times. The manufacturer declines any liability for

failure to observe these safety instructions, for

inappropriate use of the appliance or incorrect

setting of controls.

WARNING: The appliance and its accessible

parts become hot during use. Care shoul be taken

to avoid touching heating elements. Children less

than 8 years of age must be kept away unless

continuously supervised.

WARNING : If the hob surface is cracked, do not

use the appliance – risk of electric shock.

WARNING : Danger of fire : Do not store items

on the cooking surfaces.

CAUTION : The cooking process has to be

supervised. A short cooking process has to be

supervised continuously.

WARNING: Leaving the hob unattended when

cooking with fat or oil can be dangerous – risk of

fire. NEVER try to extinguish a fire with water, but

switch off the appliance and then cover the flames

e.g. with a lid or a fire blanket.

Do not use the hob as a work surfaceorsupport.

Keep clothes or other flammable materials away

from the appliance, unitl all the components have

cooled down completely – risk of fire.

Very young children (0-3 years) should be kept

away from the appliance. Young children (3-8

years) should be kept away from the appliance

unless continuously supervised. Children from 8

years old and above and persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge can use this appliance

only if they are supervised or have been given

instructions on safe use and understand the

hazards involved. Children must not play with the

appliance. Cleaning and user maintenance must

not be carried out by children without supervision.

WARNING: The appliance and its accessible

parts become hot during use. Care should be taken

to avoid touching heating elements. Children less

than 8 years of age must be kept away unless

continuously supervised

Never leave the appliance unattended during

food drying. If the appliance is suitable for

probe usage, only use a temperature probe

recommended for this oven - risk of fire.

Keep clothes or other flammable materials

away from the appliance, until all the components

have cooled down completely - risk of fire. Always

be vigilant when cooking foods rich in fat, oil or

when adding alcoholic beverages - risk of fire. Use

oven gloves to remove pans and accessories. At

the end of cooking, open the door with caution,

allowing hot air or steam to escape gradually

before accessing the cavity - risk of burns. Do not

obstruct hot air vents at the front of the oven - risk

of fire.

Exercise caution when the oven door is in the

open or down position, to avoid hitting the door.

PERMITTED USE

CAUTION: The appliance is not intended to

be operated by means of an external switching

device, such as a timer, or separate remote

controlled system.

This appliance is intended to be used in

household and similar applications such as: staff

kitchen areas in shops, offices and other working

environments; farm houses; by clients in hotels,

motels, bed & breakfast and other residential

environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do

not use the appliance outdoors.

Do not store explosive or flammable

substances (e.g. gasoline or aerosol cans) inside or

near the appliance - risk of fire.

INSTALLATION

The appliance must be handled and installed

by two or more persons - risk of injury. Use

protective gloves to unpack and install - risk of

cuts.

Installation, including water supply (if any),

electrical connections and repairs must be carried

out by a qualified technician. Do not repair or

replace any part of the appliance unless specifically

stated in the user manual. Keep children away from

the installation site. After unpacking the appliance,

make sure that it has not been damaged during

transport. In the event of problems, contact the

dealer or your nearest Aftersales Service. Once

installed, packaging waste (plastic, styrofoam

parts etc.) must be stored out of reach of

children - risk of suffocation. The appliance must

be disconnected from the power supply before

any installation operation - risk of electric shock.

During installation, make sure the appliance does

not damage the power cable - risk of fire or electric

shock. Only activate the appliance when the

installation has been completed.

Do not remove the appliance from its polystyrene

foam base until the time of installation.

Donotinstallthe appliancebehinda decorative

door - risk of fire.

if the range is placed on a base, it must

be leveled and fixed to the wall by the

retention chain provided, to prevent the

appliance slipping from the base.

WARNING: In order to prevent the

appliance from tipping, the retention chain

provided must be installed. Refer to the

instructions for installation.

ELECTRICAL WARNINGS

The rating plate is on the front edge of the

oven (visible when the door is open).

It must be possible to disconnect the appliance

from the power supply by unplugging it if

plug is accessible, or by a multi-pole switch

installed upstream of the socket in accordance

with the wiring rules and the appliance must

be earthed in conformity with national electrical

safety standards.

Do not use extension leads, multiple sockets

or adapters. The electrical components must not

be accessible to the user after installation. Do not

use the appliance when you are wet or barefoot.

Do not operate this appliance if it has a damaged

power cable or plug, if it is not working properly,

or if it has been damaged or dropped.

If the supply cord is damaged, it must

be replaced with an identical one by the

manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard -

risk of electric shock.

If the power cable needs to be replaced,

contact an authorized service center.

WARNING: Ensure that the appliance is

switched off before replacing the lamp to avoid

the possibility of electric shock.

CLEANING AND MAINTENANCE

WARNING: Ensure that the appliance is

switched off and disconnected from the power

supply before performing any maintenance

operation; never use steam cleaning equipment -

risk of electric shock.

Do not use harsh abrasive cleaners or metal

scrapers to clean the door glass since they can

scratch the surface, which may result in shattering

of the glass.

Do not use abrasive or corrosive products,

chlorine-based cleaners or pan scourers.

Make sure the appliance has cooled down

before cleaning or performing maintenance. - risk

of burns.

WARNING: Switch off the appliance before

replacing the lamp - risk of electric shock.

DISPOSAL OF PACKAGING MATERIALS

The packaging material is 100% recyclable and is marked with the

recycle symbol . The various parts of the packaging must therefore

be disposed of responsibly and in full compliance with local authority

regulations governing waste disposal.

DISPOSAL OF HOUSEHOLD APPLIANCES

This appliance is manufactured with recyclable or reusable materials.

Dispose of it in accordance with local waste disposal regulations.

For further information on the treatment, recovery and recycling

of household electrical appliances, contact your local authority, the

collection service for household waste or the store where you purchased

the appliance. This appliance is marked in compliance with European

Directive 2012/19/EU, Waste Electrical and Electronic Equipment (WEEE).

By ensuring this product is disposed of correctly, you will help prevent

negative consequences for the environment and human health. The

symbol

on the product or on the accompanying documentation

indicates that it should not be treated as domestic waste but must be

taken to an appropriate collection centre for the recycling of electrical

and electronic equipment.

ENERGY SAVING TIPS

Only preheat the oven if specified in the cooking table or your recipe. Use

dark lacquered or enamelled baking trays as they absorb heat better.

DECLARATIONS OF CONFORMITY

This appliance meets Ecodesign requirements of European Regulation

66/2014 in compliance with the European standard EN 60350-1.

This appliance meets Ecodesign requirements of European Regulation

66/2014 in compliance with the European standard EN 60350-2.
