CONTROL PANEL
FIRST TIME USE
Remove all the tapes used to hold items on the machine.
Before you use it, clean the inside of the drum to remove any dust
that could have accumulated during transport.
Slight odour or vapour may be found if you open the door during
its first use, this is normal and should only last a few minutes.
Make sure that the ventilation hose is properly inserted (refer to the
Safety Instructions).
DESCRIPTION OF CONTROL PANEL
"High Heat" button
To be used to increase the heat on drying cycles. When the button is out
low heat is selected and when it is pushed in high heat is selected.
"Start" button
Press to begin drying.
"Drying light"
is on when a drying programme is running, it goes out
at the end of the drying programme or if you open the door.
"Timer" selection knob
This is used to set the drying time: turn the knob in a clockwise
direction until the indicator is set to the desired drying time.
The 0 position switches off the dryer.
OPENING THE DOOR DURING THE CYCLE
Laundry can be checked while the drying cycle runs and any
garments already dry can be removed, while drying continues for
the remaining items. After closing the door, press the "Start" button
to resume machine operation.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to clean your lter after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door, ensure that the filter is clean and securely
placed, check to see if the drum is empty before loading it.
3. Load garments; always refer to instructions on clothing labels and
the max loads indicated in the drying time table. Empty pockets.
Make sure garments do not get caught between the door and/or
the door filter.
Do not load items that are dripping wet. Do not
tumble dry large, very bulky items.
4. Close the door.
5. Turn the “Timer" selection knob until the indicator is pointing
towards the most suitable drying time for the type of fabric in
that load.
Note: do not attempt to turn the knob anticlockwise.
6. If necessary, set the temperature using the "High Heat" button.
7. Press the "Start" button to begin drying and the drying light
comes on.
8. A final COOL TUMBLE phase (i.e. the fabrics are cooled)
activates during the last few minutes of the drying cycle;
always allow this phase to finish.
9. The cycle ends when the selection knob reaches the "0" zero
position and the drum stops.
10. Open the door, remove the laundry.
11. Disconnect the dryer from the power supply.
12. Clean the filter and replace it.
Synthetics - High (full) Heat Acrylics - Low (gentle) Heat
Drying times on reduced spin in washing machine
1kg 2kg 1kg 2kg
20-30mins 30-45mins 30-50mins 50-70mins
DRYING TIMES
Refresh
A short cycle suitable for refreshing fibres and garments through the
emission of fresh air. It lasts about 10 minutes. As this is not a drying cycle,
it is not to be used for garments that are still wet. It can be used on any load
size but is more effective on smaller loads.
Drying Times
The drying time depends on the size of the load and on the type of fabric
it contains (see the table below).
A cool tumble cycle runs during the final 10 minutes of the cycle.
High Heat Cotton is the most efficient setting in terms of energy
consumption (EU 392/2012). To reach maximum efficiency, select the
highest temperature option.
Drying Times table
The tables below show approximate drying times in minutes.
Weights refer to dry garment weights.
Drying times are approximate and may vary depending on the following:
• Amount of water retained after the spin cycle: towels and delicate items
can retain a lot of water (if laundry retains a large amount of water,
use a longer cycle than the one recommended).
• Fabrics: items of the same fabric, but with different texture and
thickness may have different drying times.
• Amount of laundry: single items and small loads take less time to dry.
• Ironing: if you will be ironing laundry, remove while slightly damp for
better results. Items not being ironed can be left longer.
• Temperature of the room: the lower the temperature of the room, the
longer it will take for the dryer to dry clothing.
• Bulky items: bulky items require special care. We recommend removing
several times the items during the drying cycle to shake them out.
Warning: do not over-dry items.
All fabrics contain natural dampness which helps to keep them soft and fluffy.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the fi rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
Standard Cotton - High (full) Heat
Drying times 800-1000rpm spin in washing machine
1kg 2kg 3kg 4kg
30-40mins 40-55mins 60-70mins 85-120mins
MAX COTTON LOAD 4 Kg (Dry load)
MAX SYNTHETIC LOAD 2 Kg (Dry load)
DRYING
OFF
120’
110’
100’
90’
80’
70’
60’
50’
40’
30’
20’
10’
HIGH HEAT
LOW HEAT
1 Kg 30’ - 40’
2 Kg 40’ - 55’
3 Kg 60’ - 70’
4 Kg 85’ - 120’
Standard Cotton
HIGH HEAT
1 Kg 20’ - 30’
2 Kg 30’ - 45’
Synthetics
HIGH HEAT
1 Kg 30’ - 50’
2 Kg 50’ - 70’
Acrylics
LOW HEAT
4Kg
Reverse Action
MADE IN GREAT BRITAIN
First Edition
START
Heat Button
Start Button
Drying Light
Indicator
Timer Knob
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance, please
register your product on www.hotpoint.eu/register
Policies, standard documentation, ordering of spare parts and additional product information can be
found by:
• Visiting our website docs.hotpoint.eu and parts-selfservice.whirlpool.com
• Using QR Code
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When
contacting our After-sales Service, please state the codes provided on your product’s identifi cation plate.
EN
Quick guide
Before using the appliance carefully read the Safety
Instructions.
xxxxxxxxxxxx
xxxx
EN
Instruction for use
