SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

Download the complete instruction manual http://

docs.hotpoint.eu or call the phone number shown

on the warranty booklet.

These instructions are valid if the country symbol

appears on the appliance. If the symbol doesn’t appear

on the appliance, it is necessary to refer to the technical

instructions which will provide the necessary instructions

concerning modication of the appliance to the

conditions of use of the country.

CAUTION: The use of the gas cooking appliance

results in the production of heat, moisture and

products of combustion in the room in which it is

installed. Ensure that the kitchen is well ventilated

especially when the appliance is in use: keep natural

ventilation holes open or install a mechanical

ventilation device (mechanical extractor hood).

Prolonged intensive use of the appliance may call for

additional ventilation, such as opening a window, or

more eective ventilation, for example increasing the

level of mechanical ventilation (if possible).

Failure to follow the information in this manual

exactly may cause a re or explosion, resulting in

property damage or personal injury.

Before using the appliance, read these safety

instructions. Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all times.

The manufacturer declines any liability for failure to

observe these safety instructions, for inappropriate

use of the appliance or incorrect setting of controls.

WARNING: If the hob surface is cracked, don’t use

the appliance – risk of electrical shock.

WARNING: Danger of re: Do not store items on the

cooking surfaces.

CAUTION: The cooking process has to be supervised. A

short cooking process has to be supervised continuously.

WARNING: Unattended cooking on a hob with fat

or oil can be dangerous – risk of re. NEVER try to

extinguish a re with water, but switch o the appliance

and then cover ame e.g. with a lid or a re blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away from

the appliance, until all the components have cooled

down completely – risk of re.

Very young children (0-3 years) should be kept

away from the appliance. Young children (3-8 years)

should be kept away from the appliance unless

continuously supervised. Children from 8 years old

and above and persons with reduced physical, sensory

or mental capabilities or lack of experience and

knowledge can use this appliance only if they are

supervised or have been given instructions on safe use

and understand the hazards involved. Children must

not play with the appliance. Cleaning and user

maintenance must not be carried out by children

without supervision.

CAUTION: In case of hotplate glass breakage: shut

immediately o all burners and any electrical heating

element and isolate the appliance from the power

supply; do not touch the appliance surface; do not use

the appliance.

The glass lid can break in if it is heated up. Turn o all

the burners and the electric plates before closing the

lid. Do not shout down lid when burner alight.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to avoid

touching heating elements. Children less than 8 years of

age must be kept away unless continuously supervised.

The food must not be left in or on the product for

more than one hour before or after cooking.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in household

and similar applications such as: sta kitchen areas in

shops, oces and other working environments; farm

houses; by clients in hotels, motels, bed & breakfast

and other residential environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not

use the appliance outdoors.

Use pots and pans with bottoms the same width as

that of the burners or slightly larger (see specic table).

Make sure pots on the grates do not protrude beyond

the edge of the hob.

Improper use of the grids can result in damage to

the hob: do not position the grids upside down or slide

them across the hob.

Do not let the burner ame extend beyond the edge of the pan.

If the hob surface is in glass material, do not use the cast iron griddles, ollar

stones, terracotta pots and pans.

Do not use: heat diusers such as metal mesh, or any other types; two burners

simultaneously for one receptacle (e.g. Fish kettle).

Should particular local conditions of the delivered gas make the ignition of

burner dicult, it is advisable to repeat the operation with the knob turned to

small ame setting.

In case of installation of a hood above the cooktop, please refer to the hood

instructions for the correct distance.

The protective rubber feet on the grids represent a choking hazard for young

children. After removing the grids, please ensure that all the feet are correctly fitted.

INSTALLATION

The appliance must be handled and installed by

two or more persons - risk of injury. Use protective

gloves to unpack and install - risk of cuts.

The electrical and gas connections must comply

with local regulation.

Installation, including water supply (if any) and

electrical connections, and repairs must be carried out

by a qualied technician. Do not repair or replace any

part of the appliance unless specically stated in the

user manual. Keep children away from the installation

site. After unpacking the appliance, make sure that it

Produktspecifikationer

Varumärke:	Hotpoint
Kategori:	Ugn
Modell:	PCN 752 T/IX/HAR
Inbyggd display:	Nej
Timer:	Nej
Vikt:	11400 g
Bredd:	750 mm
Djup:	510 mm
Höjd:	33 mm
Sladdlängd:	1 m
Elektronisk tändning:	Ja
Antal gasbrännare:	5
Produktens färg:	Rostfritt stål
Kontrolltyp:	Rotations-
AC-inspänning:	220 - 240 V
Apparatens placering:	Inbyggd
Växelström Frekvens:	50 - 60 hz
På / av-knapp:	Nej
Installationsfack, bredd:	555 mm
Installationsfack, djup:	475 mm
Barnsäkert:	Nej
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	5
Kokzon 3, form:	Rund
Diameter på platta/tillagningsyta 1:	55 mm
Placering av platta/tillagningsyta 4:	Vänster bak
Typ av platta/tillagningsyta 4:	Stor
Typ av platta/tillagningsyta 3:	Vanlig
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Höger fram
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	gas
Diameter på platta/tillagningsyta 4:	100 mm
Typ av platta/tillagningsyta 1:	Sjudning
Placering av platta/tillagningsyta 2:	Höger bak
Diameter på platta/tillagningsyta 2:	75 mm
Diameter på platta/tillagningsyta 3:	75 mm
Strömförsörjning till platta/tillagningsyta 4:	gas
Strömförsörjning till platta/tillagningsyta 2:	gas
Typ av platta/tillagningsyta 2:	Vanlig
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	gas
Placering av platta/tillagningsyta 1:	Främre till vänster
Manöverplats:	Framsida
Effekt på platta/tillagningsyta 1:	1000 W
Effekt på platta/tillagningsyta 2:	1650 W
Effekt på platta/tillagningsyta 3:	1650 W
Effekt på platta/tillagningsyta 4:	2600 W
Typ av ytskikt:	Rostfritt stål
Anslutningseffekt (elektrisk):	- W
Anslutningseffekt (gas):	9250 W
Termoelement skydd:	Ja
Boost-funktionen:	Nej
Material i hällstativ:	Emaljerad
Effekt på platta/tillagningsyta 5:	3600 W
Typ av platta/tillagningsyta 5:	Extra stor
Kokzon 5, form:	Rund
Placering av platta/tillagningsyta 5:	Central
Strömförsörjning till platta/tillagningsyta 5:	gas
Spisens bredd, storlek:	75 cm
Integrerad huva:	Nej
Indikerar att spisen är på:	Nej
Diameter på platta/tillagningsyta 5:	130 mm
Gastyp:	Metan
