Instruction booklet

TUMBLE DRYER

Step 1

Open the door of your dryer.

Step 2

Pull out the ﬁlter (using the two

ﬁnger grips).

Step 3

Clean the ﬂuff off the ﬁlter and

replace it correctly.

Step 4

Make sure the ﬁlter is pushed fully home -

NEVER run the dryer without the ﬁlter in position.

Failure to clean the ﬁlter after EVERY drying

cycle will affect the drying performance of your

machine.

It will take longer to dry and as a result will use

more electricity during drying.

Step 1

Open the condenser cover.

Step 2

Remove the condenser by turning

the 3 catches and

pulling the condenser

towards you. It is normal for some

residual water to be left in the

condenser unit.

Step 3

Flush the condenser

from the rear with water to remove

any ﬂuff deposits.

Step 4

Replace the condenser unit and

make sure that all 3 catches are

closed and that the position arrows

on the front of the condenser are

pointing upwards.

Less than 1m

This symbol reminds you to read this booklet

WHERE TO INSTALL THE TUMBLE DRYER

Install the dryer far from

gas ranges, stoves, radiators

or hobs as ﬂames may

damage it. If the dryer is

installed below a worktop,

ensure there are 10 mm

between the upper panel of

the dryer and any objects

above it and 15 mm between

the sides of the machine

and the walls or furniture units adjacent to it. This

ensures adequate air circulation.The appliance

must be installed with the rear surface placed

against a wall.

! We do not recommend that the dryer is installed

in a cupboard but the dryer must never be

installed behind a lockable door, a sliding door or

a door with a hinge on the opposite side to that of

the dryer door.

Priming the Water Collection System.

When your dryer is new, the water container will not collect water

until the system is primed. This will take 1 or 2 drying cycles. Once

primed it will collect water during every drying cyc .le

WATER DRAINAGE CONNECTION

If the dryer is installed next to a drain the

water can be plumbed into this drain. This

does away with the need to empty the

water container. The height of the drain

must be less than 1m from the bottom of

the dryer. Remove the existing hose from

the dryer and connect it to the drain (if

required add an additional length of hose).

ELECTRICAL CONNECTIONS

The socket must be grounded.

! The power cord must be regularly checked. If

the supply cord is damaged it must be replaced

by the manufacturer, its service agent or similarly

qualiﬁed persons in order to avoid a hazard.

BEFORE YOU START USING YOUR DRYER

Once you have installed your dryer and before

you use it clean the inside of the drum to remove

any dust that could have accumulated during

transport.

CONDENSER UNIT

You MUST clean the ﬂuff from the condenser

EVERY month. Failure to clean the condenser

could cause premature failure of your dryer.

Remove the condenser unit regularly (at least

monthly) and clean off any ﬂuff deposits.

WATER CONTAINER

You empty the water container after MUST EVERY

drying cycle. Removing the water container:

Step 1 Pull the water container

towards you and remove it

completely from the dryer.

Step 2 Empty all the water in the

water container.

Step 3 Replace the water

container making sure that it is securely ﬁxed.

! Failure to empty the water container will

cause the machine to stop heating and the

load may still be wet at the end of the drying

cycle. The ‘Empty Water’ light will tell you

that the water container needs to be emptied

FLUFF FILTER

You must clean the ﬂuff ﬁlter after EVERY drying cycle.

TCM 580

15 mm
