Instruction booklet

TUMBLE DRYER

FLUFF FILTER

You must clean the ﬂuff ﬁlter after drying cycle. EVERY

Step 1 - Open the door of your dryer, remove the ﬁler.

Step 2 - Clean any ﬂuff deposits from the ﬁlter mesh, and reﬁt the ﬁlter.

Step 3 - Make sure the ﬁlter is pushed fully home - run the dryer NEVER

without the ﬁlter in position.

Failure to clean the ﬁlter after EVERY drying cycle will affect the drying

performance of your machine.

V4D 01 P

To remove the ﬁlter

Installation

WHERE TO PUT YOUR DRYER

The dyer should be placed where air can freely

circulate around it preferably near a window

that can be opened to reduce the possibility of

condensation occurring while the dryer is in use.

If the dryer is enclosed or ﬁtted under a work

surface a gap of at least 50 mm (2”) must be

allowed above the top for the full width of the dryer

and at least 25 mm (1”) either side. This allows

air to enter into the rear air inlet. The dryer must

never be run in a cupboard with a closed door.

The dryer must never be installed behind a

lockable door, a sliding door or a door with a hinge

on the opposite side to that of the dryer door.

This symbol reminds you to read this booklet.

VENTILATION

When the dryer is in use there has to be adequate

ventilation to avoid the back ﬂow of gases into

the room from appliances burning other fuels,

including open ﬁres.

The vent tube should not exceed 2.4 metres in length.

The tube should be kept clear of the air intake vent

and kinks or ‘U’ bends must be avoided as these

will obstruct the tube and trap condensation.

ELECTRICAL CONNECTIONS

The socket must be grounded. The power supply cord should be checked periodically and, if required,

replaced by a cord specially prepared for this dryer.

Laundry

MAX LOAD SIZE

Do not load more than maximum capacity.

These numbers refer to dry weight:

Natural ﬁbres: 4kg max

Synthetic ﬁbre: 2kg max

WASH CARE LABELS

Look at the labels on your garments, especially when tumble drying

for the ﬁrst time. The following symbols are the most common:

May be tumble dried

Do tumble dryNOT

Tumble dry at high heat setting

Tumble dry at low heat setting

ITEMS NOT SUITABLE FOR TUMBLE DRYING

1. Articles that contain rubber or rubber-like materials or plastic

ﬁlm, any ﬂammable articles or objects that contain ﬂammable

substances.

2. Glass ﬁbres.

3. Items which have been dry cleaned.

4. Large bulky items (quilts, sleeping bags, etc). These expand

when drying and prevent airﬂow through the dryer.

Produktspecifikationer

Varumärke:	Hotpoint
Kategori:	Torktumlare
Modell:	V4D 01 P
Värmekälla:	Elektrisk
Vikt:	19000 g
Bredd:	490 mm
Djup:	480 mm
Höjd:	670 mm
Årlig energiförbrukning:	330 kWh
Energiförbrukning:	- kWh
Antal torkprogram:	13
Förpackningens bredd:	530 mm
Nominell kapacitet:	4 kg
Produktens färg:	Vit
Kontrolltyp:	Rotations-
Låddjup:	530 mm
Apparatens placering:	Fristående
Gångjärnssida:	Vänster
Hängbar dörr:	Ja
Ljudnivå Lc IEC:	66 dB
Laddning:	Frontmatad
Drum volym:	58 l
Skrynkelreducering:	Ja
Periodlängd:	94 min
Alarm:	Ja
Dörröppningsvinkel:	180 °
