Maintenance and Service Guide

P22v G5 model

SUMMARY

This guide diagnostic testsprovides about information spare parts, removal and replacement parts, of , problem

troubleshooting, and more.

Company, L.P.

AMD is a trademark of Advanced Micro

Devices, Inc. Bluetooth is a trademark

owned by its proprietor and used by HP

Inc. under license. NVIDIA is a trademark

and/or registered trademark of NVIDIA

Corporation in and other the U.S.

countries. USB Type C and C are - -USB

registered trademarks of USB

Implementers Forum. DisplayPort and the

DisplayPort logo are trademarks owned

by the Video Electronics Standards

Association (VESA) in the United States

and other countries.

The information contained herein is

subject to change without notice. The

only warranties for HP products and

services are set forth in the express

warranty statements accompanying such

products and services. Nothing herein

should be construed as constituting an

additional warranty. HP shall not be liable

for technical or editorial errors or

omissions contained herein.

First Edition: June 202 2

Document Part Number:

N08864 001- - P22v G5- - MSG V1

Assembly part number: N08864 001-

Product notice

Only trained service personnel familiar with

this product should service it. Before

performing any maintenance or service, be

sure to read “Important Safety Information”.

Table of Contents

1 Getting started............................................................................................................................................................ 1

Important safety information ............................................................................................................................... 1

Important service information and precautions ................................................................................................ 1

RoHS (2002/95/EC) requirements ..................................................................................................................... 2

General descriptions 2...........................................................................................................................................

Firmware updates ................................................................................................................................................ 2

Before returning the repaired product to the customer 2..................................................................................

2 3 Monitor features .........................................................................................................................................................

Features ................................................................................................................................................................ 3

Front components ................................................................................................................................................ 4

Rear components 5................................................................................................................................................

Locating product number the serial number and ............................................................................................. 6

3 Illustrated parts catalog............................................................................................................................................. 7

How to order parts ............................................................................................................................................... 8

4 Removal and replacement procedures................................................................................................................... 9

Preparation disassemblyfor ............................................................................................................................... 9

Rear Cover .......................................................................................................................................................... 10

Power board ....................................................................................................................................................... 13

Connector repair ................................................................................................................................................ 17

HDMI connector J3 .................................................................................................................................... 18

Stick Gasket on the Shielding for HDMI .................................................................................................... 19

Function test ....................................................................................................................................................... 20

Support and troubleshooting ............................................................................................................................ 21

Index .................................................................................................................................................................... 22
