HP Pavilion dv6 Entertainment PC

Maintenance and Service Guide

Development Company, L.P.

ATI Mobility Radeon is a registered

trademark of Advanced Micro Devices, Inc.

Bluetooth is a trademark owned by its

proprietor and used by Hewlett-

Packard Company under license. Intel,

Celeron, Core, and Pentium are trademarks

of Intel Corporation in the U.S. and

other countries. Microsoft, Windows, and

Windows Vista are U.S. registered

trademarks of Microsoft Corporation.

SD Logo is a trademark of its proprietor.

The information contained herein is subject

to change without notice. The only

warranties for HP products and services are

set forth in the express warranty statements

accompanying such products and services.

Nothing herein should be construed as

constituting an additional warranty. HP shall

not be liable for technical or editorial errors

or omissions contained herein.

First Edition: July 2010

Document Part Number: 597854-001

MSG revision history

Revision Publication date Description

A August 2010 ●Updated commodities in the following location: Product description

on page 1.

●Added newly supported processors to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 98on page , and Processor on page .

●Removed obsolete processors from spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 98on page , and Processor on page .

●Added newly supported system boards to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and System board on page 91.

●Removed obsolete system boards from spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and System board on page 91.

●Added newly supported hard drives to spare parts listings in the following

locations: Computer major components on page 18, Mass storage devices

on page on page 32, Sequential part number listing 35, and Hard drive

on page 55.

●Added newly supported WLAN modules to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and WLAN module on page 57.

●Added newly supported keyboards to spare parts listings in the following

locations: Computer major components on page 18 and Sequential part

number listing on page 35.

●Updated miscellaneous parts to spare parts listings in the following locations:

Miscellaneous parts on page 34 and Sequential part number listing

on page 35.

●Updated hard drive specifications in the following location: Hard drive

specifications on page 107.

iii

B November 2010 ●Updated commodities in the following location: Product description

on page 1.

●Added newly supported processors to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 98on page , and Processor on page .

●Added newly supported Thermal Pad Kit to spare parts listings in the following

locations: Miscellaneous parts on page 34 and Sequential part number listing

on page 35.

●Added newly supported system boards to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and System board on page 91.

●Added newly supported display assemblies and removed obsolete display

assemblies from spare parts listings in the following locations: Computer major

components on page 18 35, Sequential part number listing on page , and

BrightView display assembly on page 77.

●Added newly supported hard drives and removed obsolete hard drives from

spare parts listings in the following locations: Computer major components

on page on page Sequential part number18, Mass storage devices 32,

listing 35 55on page , and Hard drive on page .

●Added newly supported optical drives to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35on page , and Optical drive on page 63.

●Added newly supported keyboards to spare parts listings in the following

locations: Computer major components on page 18 and Sequential part

number listing on page 35.

●Added newly supported top covers to spare parts listings in the following

locations: Computer major components on page 18, Sequential part number

listing 35 67on page , and Top cover on page .

●Added newly supported fan/heat sink assembly to spare parts listings in the

following locations: Computer major components on page 18, Sequential

part number listing on page 35, and Fan/heat sink assembly on page 95.

●Updated miscellaneous parts to spare parts listings in the following locations:

Miscellaneous parts on page 34 and Sequential part number listing

on page 35.

●Updated optical disc specifications in the following location: Blu-ray Writer

with DVD±R/RW SuperMulti DL Drive on page 110.

iv MSG revision history

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a

hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft

surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to

contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer

and the AC adapter comply with the user-accessible surface temperature limits defined by the

International Standard for Safety of Information Technology Equipment (IEC 60950).

vi Safety warning notice

Plastic parts ............................................................................................. 45

Cables and connectors ............................................................................. 46

Drive handling ......................................................................................... 46

Grounding guidelines .............................................................................................. 47

Electrostatic discharge damage .................................................................. 47

Packaging and transporting guidelines ........................................ 48

Workstation guidelines .............................................................. 48

Equipment guidelines ................................................................. 49

Component replacement procedures ........................................................................................ 50

Service tag ............................................................................................................. 50

Computer feet ......................................................................................................... 52

Battery ................................................................................................................... 53

Hard drive cover ..................................................................................................... 54

Hard drive ............................................................................................................. 55

WLAN module ........................................................................................................ 57

Memory module ...................................................................................................... 60

RTC battery ............................................................................................................ 62

Optical drive .......................................................................................................... 63

Keyboard ............................................................................................................... 65

Top cover ............................................................................................................... 67

Power button board ................................................................................................. 70

Touchscreen display assembly .................................................................................. 72

BrightView display assembly .................................................................................... 77

Webcam/microphone module .................................................................................. 82

Bluetooth module .................................................................................................... 83

Speaker assembly ................................................................................................... 85

USB board ............................................................................................................. 87

Power connector ..................................................................................................... 89

System board ......................................................................................................... 91

Fan/heat sink assembly ........................................................................................... 95

Processor ............................................................................................................... 98

5 Setup Utility (BIOS) ....................................................................................................... 100

Starting Setup Utility ............................................................................................................. 100

Using Setup Utility ................................................................................................................ 100

Changing the language of Setup Utility .................................................................... 100

Navigating and selecting in Setup Utility .................................................................. 101

Displaying system information ................................................................................. 101

Restoring default settings in Setup Utility ................................................................... 102

Exiting Setup Utility ............................................................................................... 102

Setup Utility menus ............................................................................................................... 103

viii

RJ-11 (modem) ..................................................................................................................... 133

Universal Serial Bus .............................................................................................................. 133

9 Power cord set requirements ........................................................................................ 134

Requirements for all countries or regions ................................................................................. 134

Requirements for specific countries or regions .......................................................................... 135

10 Recycling .................................................................................................................... 136

Battery ................................................................................................................................ 136

Display ............................................................................................................................... 136

Index ............................................................................................................................... 140

1 Product description

Category Description

Product Name HP Pavilion dv6 Entertainment PC

Processors Intel® Core™ 2 Quad Intel Core i7 Processors

Intel Core i7-840QM processor with 1.86 GHz, SC turbo up to 3.2 GHz, Quad 45 W

Intel Core i7-820QM processor with 1.73 GHz, SC turbo up to 3.06GHz, Quad 45 W

Intel Core i7-740QM processor with 1.73 GHz, SC turbo up to 2.93 GHz, Quad 45 W

Intel Core i7-720QM processor with 1.6 GHz, SC turbo up to 2.8 GHz, Quad 45 W

Intel Core 2 Duo Intel Core i5 Processors

Intel Core i5-580M processor with 2.66 GHz, SC turbo up to 3.33 GHz, Dual 35 W

Intel Core i5-560M processor with 2.66 GHz, SC turbo up to 3.33 GHz, Dual 35 W

Intel Core i5-540M processor with 2.53 GHz, SC turbo up to 3.06 GHz, Dual 35 W

Intel Core i5-520M processor with 2.4 GHz, SC turbo up to 2.93 GHz, Dual 35 W

Intel Core i5-480M processor with 2.66 GHz, SC turbo up to 2.93 GHz, Dual 35 W

Intel Core i5-460M processor with 2.53 GHz, SC turbo up to 2.8 GHz, Dual 35 W

Intel Core i5-450M processor with 2.4 GHz, SC turbo up to 2.66 GHz, Dual 35 W

Intel Core i5-430M processor with 2.26 GHz, SC turbo up to 2.53 GHz, Dual 35 W

Intel Core i3 Processors

Intel Core i3-390M processor with 2.66 GHz, Dual 35 W

Intel Core i3-380M processor with 2.53 GHz, Dual 35 W

Intel Core i3-370M processor with 2.4 GHz, Dual 35 W

Intel Core i3-350M processor with 2.26 GHz, Dual 35 W

Intel Pentium P6 Processors

Intel Pentium P6300 processor with 2.26 GHz

Intel Pentium P6200 processor with 2.13 GHz

Intel Pentium P6100 processor with 2.00 GHz

Intel Pentium P6000 processor with 1.86 GHz

Category Description

Chipset Intel HM55 Express Chipset

Graphics Intel HD graphics

Switchable discrete graphics

ATI Capilano Pro (ATI Mobility Radeon™ HD 6550) graphics with 1024-MB of dedicated

video memory (64MB x 16 DDR3 @ 800 MHz x 8 pcs) and 128-MB of sideport video

memory

ATI Robson XT (ATI Mobility Radeon HD 63 of dedicated video70) graphics with 512-MB

memory (64MB x 16 DDR3 @ 800 MHz x 4 pcs) and 128-MB of sideport video memory

ATI Madison Pro (ATI Mobility Radeon HD 5650) graphics with 1024-MB of dedicated

video memory (64MB x 16 DDR3 @ 800 MHz x 8 pcs) and 128-MB of sideport video

memory

ATI Park XT (ATI Mobility Radeon HD 5470) graphics with 512-MB of dedicated video

memory (64MB x 16 DDR3 @ 800 MHz x 4 pcs) and 128-MB of sideport video memory

Supports Blu-ray and/or HD-DVD playback with HD Decode, DX11 support

and HDMI support

Panels 39.6-cm (15.6-inch) SVA HD LED BrightView (1366x768) (5.5 mm max)

39.6-cm (15.6-inch) HD+ LED Touchscreen

Supports lighted logo on top bezel

Memory Two customer-accessible/upgradeable SODIMM slots

DDR3 PC3-10600 1333-MHz memory

Supports dual channel

DDR3/1333-MHz and DDR3/1066-MHz (only computer models equipped with the Intel

Core i7-840QM 1.86 GHz processor, the Intel Core i7-820QM 1.73GHz processor, the

Intel Core i7-740QM 1.73 GHz processor, and the Intel Core i7-720QM 1.6 GHz

processor run at DDR3/1333-MHz; all other computer models run at DDR3/1066-MHz)

Supports up to 8 GB system memory in the following configurations:

1024-MB total system memory (1024 MB x 1)

2048-MB total system memory (1024 MB x 2, dual-channel)

2048-MB total system memory (2048 MB x 1)

3072-MB total system memory (1024 MB x 1 + 2048 MB x 1)

4096-MB total system memory (2048 MB x 2, dual-channel)

6144-MB total system memory (2048 MB x 1 + 4096 MB x 1)

8192-MB total system memory (4096 MB x 2, dual-channel)

Hard drives Supports 6.35-cm (2.5-in) hard drives (HD), 12.7-mm (.50-in), and 9.5-mm (.37-in)

thicknesses

Supports one hard drive

Supports solid state drives (SSD)

2 Chapter 1 Product description

Category Description

Supports Accelerometer Hard Drive Protection

Single hard drive configurations:

160-GB SSD

250 GB (7200 rpm, 9.5 mm)

320 GB (7200 rpm, 9.5 mm)

500 GB (7200 rpm, 9.5 mm)

640 GB (5400 rpm and 7200 rpm, 9.5 mm)

750 GB (5400 rpm and 7200 rpm, 9.5 mm)

1 TB (5400 rpm, 12.7 mm)

Optical drives 12.7-mm tray load

Serial ATA (SATA)

Fixed (removal of one screw required)

Supports the following optical drives:

LightScribe DVD±R/RW SuperMulti DL Drive

DVD±R/RW SuperMulti DL Drive

Blu-ray ROM with LightScribe DVD±R/RW SuperMulti DL Drive

Blu-ray ROM with DVD±R/RW SuperMulti DL Drive

Blu-ray Writer with DVD±R/RW SuperMulti DL Drive

Webcam Low-light VGA camera

Fixed (no tilt)

Activity LED

640 × 480 by 24 frames per second

Microphone 2 omnidirectional microphones, dual-array with appropriate software (supports beam

forming, echo cancellation, and noise suppression)

Audio HD Audio

Dolby advance audio

Integrated subwoofer

Supports Microsoft® Premium Requirements

Pavilion-branded Altec Lansing speakers

Ethernet Integrated 10/100/1000 network interface card (NIC)

Wireless Integrated wireless local area network (WLAN) options by way of wireless

module:

Atheros AR9285 802.11b/g/n 1x1 WLAN module

Produktspecifikationer

Varumärke:	HP
Kategori:	Laptop
Modell:	Pavilion dv6-3075ss
Enhetsplacering:	Vrijstaand
Färg på produkten:	Wit
Bredd:	554 mm
Djup:	551 mm
Höjd:	1440 mm
Nettoskatt:	80 W
Ljudnivå:	41 dB
Årlig-energiförbrukning:	177 kWu
Energieffektivitetsklass (gammal):	A++
Frys bruttokapacitet:	- l
Frys nettokapacitet:	160 l
Fryskapacitet:	12 kg/24u
Retentionstid vid strömavbrott:	15 uur
Antal fryshyllor:	4
Energianvändning per dag:	0.486 kWh/24u
Klimaatklasse:	N-T
Justerbara fötter:	Ja
AC-ingångsspänning:	220 - 240 V
AC-ingångsfrekvens:	50 Hz
