See back page for Customer Service Information
Consulte el reverso para Servicio de Información al Cliente
Voir pages verso pour des renseignements le service à la clientèle
© Copyright Huffy Corporation 2017
Owner’s Manual
for Mountain Bikes
Please read and fully understand this manual
before operation.
Save this manual for future reference.
This manual contains important safety, assembly,
operation and maintenance information.
H-MTB EN 030117 m0012
EN
Owner’s Manual Index
Your Bike
• Owner’s Bicycle Identication Record ............................................................................ 3
• Fitting the Rider to the Bicycle ..........................................................................................3
• Warning and Safety Information ...................................................................................... 4
• The Owner’s Responsibility - Rules of the Road ........................................................4-5
Bicycle Assembly
• Parts Assembly .....................................................................................................................6-7
• Introduction to Assembly / Tools Needed ....................................................................8
• Accessories ...............................................................................................................................9
• Handlebar and Stem Installation ................................................................................ 10-12
• Front Wheel Installation .....................................................................................................13
• Quick Release Axle (as equipped) ............................................................................... 14-15
• Testing Stem and Handlebar Tightness ........................................................................16
• Seat Installation ................................................................................................................. 17-18
• Testing Seat Clamp and Post Clamp Tightness ..........................................................18
• Pedal Installation and Three-Piece Cranks (on some models) ..............................19
• Reector Brackets Installation ..........................................................................................20
• Installing Derailleur Guard (as equipped) ....................................................................20
Brake System
• Rim Brake Setup ................................................................................................................ 21-24
• Brake Pad Replacement ......................................................................................................24
• Disc Brake Setup (as equipped) ................................................................................... 25-26
Shift System
• Shift System Setup ........................................................................................................... 27-29
• Rear/ Front Derailleur Adjustments ........................................................................... 30-33
Maintenance and Service
• Repair and Service - Torque Table ...................................................................................34
• Tires ........................................................................................................................................35
• Lubrication/ Lubrication Table .........................................................................................36
• Inspection of the Bearings ................................................................................................37
• Suspension Frame (on some models) ...........................................................................37
Warranty .............................................................................................................................38
IMPORTANT!! BEFORE YOUR FIRST RIDE:
• Read entire manual, including all safety warnings.
See Maintenance section to:
• Check Tire Pressure.
• Check Brake Adjustment.
• Check Shift/Derailleur Adjustments.
3
3
1
2
Owner’s Bicycle Identi cation Record
NOTE: This information is only available on the bicycle itself. It is not available from Hu y.
Each Hu y bicycle has a Recovery Code
stamped into the frame. The Recovery Code
can be found on the bottom of the crank
housing as shown.
Write this number below to keep it for future
reference.
If the bicycle is stolen, give this number and
a description of the bicycle to the police.
This will help them nd the bicycle.
1
Recovery Code:
Purchase Date:
Model Name:
To determine the correct size of bicycle for the rider:
• Straddle the assembled bicycle with feet shoulder width
apart and at on the ground.
• There must be at least 1 inch (2.5 cm) of clearance
between the highest part of the top tube
and the
crotch of the rider with tires properly in ated.
• The minimum leg-length for the rider is the highest
part of the top tube plus one inch
.
Fitting the Rider to the Bicycle
Your Bike
Your Bike
IMPORTANT!! Read All Warning And Safety Information
