531833-2EN_A

Operations Manual

788ci HD & 788ci HD DI Combo

Thank You!

Thank you for choosing Humminbird®, America's #1 name in fishfinders.

Humminbird® has built its reputation by designing and manufacturing

top-quality, thoroughly reliable marine equipment. Your Humminbird® is

designed for trouble-free use in even the harshest marine environment. In the

unlikely event that your Humminbird® does require repairs, we offer an

exclusive Service Policy - free of charge during the first year after purchase,

and available at a reasonable rate after the one-year period. For complete

details, see the separate warranty card included with your unit. We encourage

you to read this operations manual carefully in order to get the full benefit from

all the features and applications of your Humminbird® product.

Contact our Customer Resource Center at 1-800-633-1468 or visit our Web

site at humminbird.com.

WARNING! This device should not be used as a navigational aid to prevent collision,

grounding, boat damage, or personal injury. When the boat is moving, water depth may

change too quickly to allow time for you to react. Always operate the boat at very slow

speeds if you suspect shallow water or submerged objects.

WARNING! Disassembly and repair of this electronic unit should only be performed by

authorized service personnel. Any modification of the serial number or attempt to repair the

original equipment or accessories by unauthorized individuals will void the warranty.

WARNING! This product contains chemicals known to the State of California to cause

cancer and/or reproductive harm.

WARNING! Do not travel at high speed with the unit cover installed. Remove the unit cover

before traveling at speeds above 20 mph.

NOTE: The illustrations in this manual may not look exactly like the display on your

Humminbird® model, but your model will work in the same way.

ENVIRONMENTAL COMPLIANCE STATEMENT: It is the intention of Humminbird® to be

a responsible corporate citizen, operating in compliance with known and applicable

environmental regulations, and a good neighbor in the communities where we make or sell

our products.

NOTE: Some features discussed in this manual require a separate purchase, and some

features are only available on international models. Every effort has been made to

clearly identify those features. Please read the manual carefully in order to understand

the full capabilities of your model.

WEEE DIRECTIVE: EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment

Directive (WEEE)” impacts most distributors, sellers, and manufacturers of consumer

electronics in the European Union. The WEEE Directive requires the producer of consumer

electronics to take responsibility for the management of waste from their products to

achieve environmentally responsible disposal during the product life cycle.

WEEE compliance may not be required in your location for electrical & electronic equipment

(EEE), nor may it be required for EEE designed and intended as fixed or temporary

installation in transportation vehicles such as automobiles, aircraft, and boats. In some

European Union member states, these vehicles are considered outside of the scope of the

Directive, and EEE for those applications can be considered excluded from the WEEE

Directive requirement.

This symbol (WEEE wheelie bin) on product indicates the product must not be

disposed of with other household refuse. It must be disposed of and collected for

recycling and recovery of waste EEE. Humminbird® will mark all EEE products in

accordance with the WEEE Directive. It is our goal to comply in the collection,

treatment, recovery, and environmentally sound disposal of those products; however, these

requirements do vary within European Union member states. For more information about

where you should dispose of your waste equipment for recycling and recovery and/or your

European Union member state requirements, please contact your dealer or distributor from

which your product was purchased.

ROHS STATEMENT: Product designed and intended as a fixed installation or part of a

system in a vessel may be considered beyond the scope of Directive 2002/95/EC of the

European Parliament and of the Council of 27 January 2003 on the restriction of the use of

certain hazardous substances in electrical and electronic equipment.

ProMap™ and LakeMaster® are trademarked by or registered trademarks of Waypoint

Technologies, Inc.

Navionics® Gold, HotMaps™, and HotMaps Premium™ are registered trademarks of Navionics®.

700 Series™, Cannon®, CannonLink™, Down Imaging™, DualBeam PLUS™, Fish ID+™, Fishing

GPS®, Humminbird®, HumminbirdPC™, InterLink™, QuadraBeam PLUS™, RTS™, RTS

Window™, Structure ID®, Selective Fish ID+®, WeatherSense®, WhiteLine™, WideSide®,

UniMap™, and X-Press™ Menu are trademarked by or registered trademarks of Humminbird®.

ATTENTION INTERNATIONAL CUSTOMERS: Products sold in the U.S. are not

intended for use in the international market. Humminbird® international units provide

international features and are designed to meet country and regional regulations.

Languages, maps, time zones, units of measurement, and warranty are examples of

features that are customized for Humminbird® international units purchased through

our authorized international distributors.

To obtain a list of authorized international distributors, please visit our Web site at

humminbird.com or contact our Customer Resource Center at (334) 687-6613.

Produktspecifikationer

Varumärke:	Humminbird
Kategori:	Navigator
Modell:	788CI
Skärm diagonal:	5 "
Vattentät:	Ja
Antal färger:	256 färger
Bakgrundsbelysning:	Ja
Maximalt djup:	457.5 m
Frekvens:	200 kHz
Toppeffekt:	4000 W
Uteffekt (RMS):	500 W
Produktstorlek (BxDxH):	149.9 x 190.5 x 114.3 mm
Displaytyp:	TFT LCD
Skärmstorlek (HxB):	640 x 640 mm
Vatten temperaturgivare:	Ja
