INSTRUCTIONS

REMOTE-CONTROLMICROPHONE

HM-162B/SW

Thank you for purchasing the HM-162B/SW

REMOTE

-

CONTROLMICROPHONE

. The COMMANDMIC III

TM

is a

remote control microphone for use with the IC-M604

or else.

Please read the connected transceiver’s instruction

manual carefully before installation and operation.

These instructions are just described the remote-

control operations only.

qBUSY/TRANSMIT INDICATOR

➥“

BBUUSSYY

” appears when receiving a signal or when the

squelch opens.

➥“

TTXX

” appears while transmitting.

wRECEIVER ATTENUATOR INDICATOR

“

LLOOCC

” appears when the Attenuator function is in use.

eSCRAMBLER INDICATOR

“

SSCCRRAAMM

” appears when an optional voice scrambler is acti-

vated.

rSCAN INDICATOR

➥Either “

NNOORRMMAALLSSCCAANN

” or “

PPRRII--SSCCAANN1166

” scan type

appears while scanning.

➥“

DDUUAALL1166

” appears during dualwatch; “

TTRRII1166

” ap-

pears during tri-watch.

tSELECTOR STATUS INDICATOR

Indicates the [SELECTOR]active status;

“

[[VVOOLL]]

” appears when [SELECTOR]as the audio volume.

“

[[SSQQLL]]

” appears when [SELECTOR]as the noise squelch

controller.

“

[[CCHH]]

” appears when [SELECTOR]as the channel selector.

yPOSITION INDICATOR

➥Shows the GPS position data.

•“

????

” may blink every 2 sec. instead of position data when

the GPS position data is invalid. In this case, the last position

data is held for up to 23.5 hours.

•“

????

” may blink every 2 sec. instead of position data 4 hours

after the position data is input manually, up until 23.5 hours

have past.

➥“

NNooPPoossiittiioonn

” appears when no GPS receiver is con-

nected and no position data is input manually.

uTIME ZONE INDICATOR

➥“

LLooccaall

” appears when the offset time data in the ‘Set

up’menu is entered.

➥“

NNooTTiimmee

” appears when no GPS receiver is connected

and no time data is input manually.

iCHANNELCOMMENT INDICATOR

Channel comment appears, if programmed.

oCHANNELNUMBER READOUT

Indicates the selected operating channel number.

!0KEYLOCK INDICATOR

➥Appears while the Key Lock function is in use.

➥Blinks while the All Key Lock function is in use.

!1LOW BATTERYINDICATOR

“” blinks when the battery voltage drops to approx. 10V

DC or below.

!2CALLCHANNELINDICATOR

➥

“

CCAALLLL

” appears when the call channel is selected.

➥“

AALLEERRTT

” appears when the Weather Alert function is in

use; blinks when an alert tone is received.

!3CHANNELGROUPINDICATOR

Indicates whether an International “

IINNTT

,” U.S.A. “

UUSSAA

,”

Canadian “

CCAANN

” or weather “

WWXX

” channel is selected.

!4DUPLEX INDICATOR

Appears when a duplex channel is selected.

•Duplex channel has a different TX and RX frequency.

!5TAG CHANNELINDICATOR

Appears when a tag channel is selected.

!6POWER INDICATOR

➥“

2255WW

” appears when high power is selected.

➥“

11WW

” appears when low power is selected.

!7RX SPEAKER INDICATOR

Appears when an RX speaker function is activated.

BUSYBUSY-25W25W------INTINT------CALLCALL

LOCLOC--- -- DUPDUP

SCRAMSCRAM--TAGTAG

NORMALNORMAL-SCANSCAN

-3434°34.506N34.506N

123123°23.236W23.236W

LocalLocal----1:101:10- - CALLINGCALLING

RXRX

[VOL]

w

q

e

y

u

r

t

!6!7!4!5!3!2

o

!0

!1

i

Accessories included with the HM-162B/SW: Qty.

qConnection cable (OPC-1540*: 6m; 20 ft) .......................1

wMounting base ..................................................................1

eConnector cap ..................................................................1

rMicrophone hanger ..........................................................1

tScrews (M3 ×16; tapping) ...............................................5

*: OPC 1540 has external speaker leads as illustrated at right.

(Yellow: Audio, Black: Speaker ground)

These instructions are described when the HM-162 is connected to the IC-M604. Some operations or indications may be dif-

ferent as these instructions depending on the connecting transceiver.

xFunction display

zHM-162B/SW supplied accessories

qwe

r

t

Yellow

Black
