INSTRUCTION MANUAL

UHF TRANSCEIVER

iF4029SDR

EXPLICIT DEFINITIONS

PRECAUTIONS

WORD DEFINITION

RWARNING Personal injury, ﬁre hazard or electric shock

may occur.

CAUTION Equipment damage may occur.

NOTE If disregarded, inconvenience only. No risk

of personal injury, ﬁre or electric shock.

READ ALL INSTRUCTIONS carefully and com-

pletely before using the transceiver.

SAVE THIS INSTRUCTION MANUAL — This

instruction manual contains important operating instructions

for the IC-F4029SDR UHF TRANSCEIVER.

IMPORTANT

Icom, Icom Inc. and the logo are registered trademarks of Icom

Incorporated (Japan) in the United States, the United Kingdom, Germany,

France, Spain, Russia and/or other countries.

All other products or brands are registered trademarks or trademarks of their

respective holders.

RCAUTION! NEVER hold the transceiver so that the

antenna is very close to, or touching exposed parts of the

body, especially the face or eyes, while transmitting. The

transceiver will perform best if the microphone is 5 to 10 cm

away from the lips and the transceiver is vertical.

RCAUTION! NEVER operate the transceiver with a

headset or other audio accessories at high volume levels.

RCAUTION! NEVER short the terminals of the bat-

tery pack.

DO NOT push PTT when not actually desiring to transmit.

AVOID using or placing the transceiver in direct sunlight or

in areas with temperatures below –25°C or above +55°C.

The basic operations, transmission and reception of the trans-

ceiver are guaranteed within the speciﬁed operating temper-

ature range. However, the LCD display may not be operate

correctly, or show an indication in the case of long hours of

operation, or after being placed in extremely cold areas.

DO NOT modify the transceiver for any reason.

Optional unit installation should be done at authorized Icom

service center only.

KEEP the transceiver from the heavy rain, and Never

immerse it in the water. The transceiver construction is water

resistant, not waterproof.

The use of non-Icom battery packs/chargers may impair

transceiver performance and invalidate the warranty.

TABLE OF CONTENTS

IMPORTANT .................................................................................... i

EXPLICIT DEFINITIONS ................................................................. i

PRECAUTIONS ............................................................................... i

TABLE OF CONTENTS .................................................................. ii

1 ACCESSORIES ..................................................................... 1–2

■Supplied accessories ............................................................. 1

■Accessory attachments .......................................................... 1

2 PANEL DESCRIPTION ......................................................... 3–8

■Front panel ............................................................................. 3

■Function display ..................................................................... 5

■ Programmable function keys .................................................. 6

3 BASIC OPERATION ............................................................ 9–11

■ Receiving and transmitting ..................................................... 9

■Lock function ........................................................................ 10

■ Monitor function .................................................................... 10

■All channel mode and Select channel mode ........................ 10

■Select channel setting .......................................................... 11

■“My Name” function .............................................................. 11

■Battery type selection ............................................................ 11

4 SCAN OPERATION ........................................................... 12–13

■ Scan types ........................................................................... 12

■Scan list setting .................................................................... 12

■Starting a scan ..................................................................... 13

5 RINGER FUNCTION (Analog mode operation only) ......... 14–15

■Smart-Ring operation ........................................................... 14

■ Call-Ring operation .............................................................. 15

■ Auto channel function ........................................................... 15

6 TONE SQUELCH OPERATION

(Analog mode operation only) ........................................... 16–18

■Operation ............................................................................. 16

■ Tone scan operation ............................................................. 18

7 DIGITAL OPERATION ....................................................... 19–24

■Transmitting a call ................................................................ 19

■Receiving a call .................................................................... 20

■ Ringer operation ................................................................... 20

■ Break-in request call ............................................................ 21

■ Status message ................................................................... 23

■Digital mode indication ......................................................... 24

8 SET MODE ........................................................................ 25–28

■ Set mode programming ........................................................ 25

■Set mode items .................................................................... 26

9 BATTERY CHARGING ...................................................... 29–33

■Caution ................................................................................. 29

■ Battery chargers ................................................................... 31

10 BATTERY CASE ..................................................................... 34

■ Optional battery case (BP-240) ............................................ 34

11 SWIVEL BELT CLIP .......................................................... 35–36

■MB-93 contents .................................................................... 35

■ To attach ............................................................................... 35

■ To detach .............................................................................. 36

12 SPECIFICATIONS ............................................................. 37–39

■Speciﬁcations ....................................................................... 37

■ Channel frequency lists ........................................................ 38

13 OPTIONS ................................................................................. 40

14 DOC ................................................................................... 41–42

15 ABOUT VOICE CODING TECHNOLOGY .............................. 43
