Sida 1/1
1. RCA Line Output
To amplifier, receiver, HiFi system.
2. 3.5mm Headphone jack
Connect headphone.
3. Analogue Volume Control
For controlling the volume level from
the 3.5mm output.
Tip: If the RCAs are used, then there will
be a fixed level output. The volume
control only controls the 3.5mm output.
The RCA outputs and 3.5mm output
may be used simultaneously with no
adverse sonic impact.
ifi-audio.com
4. Filter switch
On the iDAC2, using the True Native®
Burr-Brown chipset, it is possible to
enjoy music on the following filter
options under PCM/DSD/DXD formats.
On the casework, the filters are marked
according to the PCM convention but
for DSD they are in the same order as
above so ‘Bit-Perfect’ = ‘Extreme’ and so
on.
For DXD, the filter setting is fixed at Bit-
Perfect.
For best sonics, with PCM music, we
recommend ‘Bit-Perfect’ and for DSD
music files, ‘Extreme’. But please try the
different settings and see which you
prefer as music is a matter of personal
choice.
Ver1.1
Terms & Conditions
iFi guarantees that this iFi product shall be free from defects in
materials and workmanship for a period of 1 year for parts and labour.
The warranty period begins at the date of retail sale by an authorized
iFi distributor/dealer and is subject to the following requirements and
understandings:
• It is the responsibility of the buyer within 30 days from the original
sale, to register and activate the product warranty with the iFi
website.
• The original invoice must be produced for authentication prior to
any warranty claim.
• The iFi product must not have been modified in any manner
whatsoever, or the warranty will immediately become void.
• The iFi warranty is only valid in the country of original sale.
• The product must not have been stored in a humid environment;
nor subjected to weather, water, or saltwater spray.
• iFi shall not, under any circumstances, be liable for any
incidental or consequential damages arising from the loss of property
or other damage or losses due to the failure of an iFi product. iFi is not
liable for loss of use or inconvenience caused by the failure of an iFi
product. iFi is not liable for damage caused to other audio
components because of the failure of an iFi product.
• During the warranty period, iFi will repair the product to
working order, or, at iFi's option, replace the defective module with a
similar available product.
• All repairs performed after expiry of the warranty period will be
charged to the owner and will carry a 180-day warranty on parts and
labour. The customer is responsible for shipping the unit to the iFi
distributor in the original packaging. This includes the payment of any
shipping charges and related taxes.
• Should any warranty issues arise, the decision of iFi is full and
final.
- PCM
Bit-Perfect Processing
Minimum Phase
Standard
Digital filters
selectable
- DSD
Extreme
Extended
Standard Range
Analogue filters
selectable
- DXD
Bit-Perfect Processing
Fixed analogue
filter
5. USB Input
From computer or iDevice. As long as
the computer software and a
respectable USB cable is used, PCM up
to 384KHz and DSD up to Quad
DSD256 are supported by the iDAC2.
As the iDAC2 draws its power from the
USB power line, for portable devices,
depending upon the manufacturer,
some products will ‘allow’ the iDAC2
to draw power and some may not. For
those that do (eg Android tablets),
then the iDAC2 can also be used ‘on
the go’.
For further assistance and FAQs:
http://support.ifi-audio.com/index.php
Tip: MAC OSX (10.6 or later) has built-in
native support for the iDAC2. MS
Windows (XP or later), please download
and install the driver software BEFORE
connecting the iDAC2 to the computer
(www.ifi-audio.com).
Tip: For the best sound quality, always
set the volume control on the computer
and the playback software to 100%, and
use the Analogue Volume Control on the
iDAC2 to control the volume.
Tip: When using iPAD/SqueezeBox
Touch or similar, ALWAYS connect and
power on ALL other devices before
connecting the USB cable to the iDAC2
as the final step.
6. Digital Output
With a host device feeding a USB
signal into the USB input port,
micro
iDAC2
warranty
In order to activate the warranty for this iFi
product, you must register with the iFi
website.
Component :
Serial no:
ifi-audio.com
Specifications
Ÿ Input: USB 3.0 (compatible with
iPhone, iPod, iPad and Android
Devices, camera kit or USB-OTG
cable required.)
Ÿ
Outputs: Audio RCA (2.1V @ 0dBFs,
Load > 600Ω)
3.5mm Headphone (max
350mW/16Ω, 8Ω - 600Ω)
SPDIF RCA (PCM up 192kHz,
DoP DSD)
Ÿ
Power Source: USB Bus power
Ÿ
Power consumption: <1.5W
Ÿ
Dimensions: 158(l)x68(w)x28(h)mm
Ÿ
Weight: 249g(0.55 lbs)
the Digital Output will also output an
SPDIF signal.
Therefore, it is possible to use the
iDAC2 as a high-quality USB-to-SPDIF
converter.
PCM is fully-supported up to 24/192
but will depend upon other factors
such as the source and the cable and
connectors.
For DSD, as it was not designed to be
within the SPDIF protocol, it may work
or it may not work.
3
2
1
OU TP UT
R
L
4 5
6
DI GITAL I NP UT
DI GITAL
OU TPU T
BI T-P ERF ECT
STAN DAR D
MI N
PH ASE
LED
Power ON:
LED Color
Green
Yellow
Cyan
White
Blue
Magenta
Green(Flashing)
Mode
44/48kHz
88/96kHz
176/192kHz
DXD352/384kHz
DSD2.8/3.1MHz
DSD5.6/6.2/11.2/12.2MHz
Awaiting USB Connection
