Sida 1/1
To connect the signal output from the host (Apple TV,
Google Chromecast, CD transport etc).
Tip: With USB connection selected, the SPDIF automatically
becomes output.
7. USB Input
For connection from a USB source, such as a laptop.
Specifications:
Power Source: USB Bus power, embedded AMR
Active Noise Cancellation®
technology
Formats: 44.1/48/88.2/96/176.4/
192kHz PCM
2.8/3.1/5.6/6.2/11.2/
12.4MHz DSD
352/384kHz DXD
DAC System: Bit-Perfect DSD & DXD DAC by
Burr Brown (1-DAC Chip; 2-
Channel; 4-Signals)
Filter: PCM: Measure/Listen digital
(selectable)
DSD:
Measure/Listen analogue
(selectable)
DXD: Bit-Perfect Processing, fixed filter
Input: USB 3.0 compatible with USB 2.0
Bluetooth (TM) with aptX & AAC
Codec
SPDIF RCA & Optical Combo
Output: SPDIF RCA for BT & USB (PCM up
to192kHz)
Audio RCA L/R
Frequency Response: 20Hz - 20kHz <+0/-0.5dB
(44.1kHz SR, Measure Filter)
1Hz - 44khz <+0/-3.0dB
(>= 88.2kHz SR, Measure Filter)
Output Voltage @ 0dBFS: 2.05V (+/-0.05V)
Dynamic Range: 109dB (A)
Signal/Noise ratio: 109dB (A) @ 0dBFS
THD & N @ 0dBFS: < 0.0015% 10k Load
Output Impedance: < 50Ω
Power Consumption: < 2.5W
Dimensions: 100 (l) x 64 (w) x 25.5 (h) mm
Weight: 122g (0.27lbs)
Warranty period: 12 months
Specifications are subject to change without notice.
Ver.1.5
1. Bluetooth Pairing Button
Long press to enter Bluetooth pairing mode.
2. LED
LED Color
Blue
Cyan
White
Yellow
Green
Purple
Red
Bluetooth
Blue
Blue/Red (flashing)
Blue (flashing)
3. Input selection switch
Use this to select the input.
Note: Multiple sources can be connected, use the switch to
select the input.
4. Digital Filter
Listen:
Measure:
5. RCA output
To connect RCA interconnect cables from the iOne to
the desired amplifier.
6. SPDIF Input/Output
(Coaxial Input/Output, Optical Input)
iOne
1
3
2
4
5 6 7
Mode
DSD256 (11.2/12.2MHz)
DSD128(5.6/6.2MHz)
/DSD64(2.8/3.1MHz)
DXD384/352kHz
192/176kHz
96/88/48/44kHz
MQA
Unlock
Connected
Pairing
Not Connected
ifi-audio.com
PAIRING
INPUT
USB
SPDIF
BT
MEASURE
LISTEN
FILTER
OUTPUT
USB INPUT
SPDIF
IN/OUT
R
L
Recommended for listening.
(Minimum Phase Digital Filter)
Recommended for taking measurements.
(Standard Digital Filter)
Terms and Conditions
iFi guarantees that this iFi product shall be free from defects in materials and
workmanship for a period of 1 year for parts and labour.
The warranty period begins at the date of retail sale by an authorized iFi
distributor/dealer and is subject to the following requirements and
understandings:
• It is the responsibility of the buyer within 30 days from the original sale, to
register and activate the product warranty with the iFi website.
• The original invoice must be produced for authentication prior to any
warranty claim.
• The iFi product must not have been modified in any manner whatsoever,
or the warranty will immediately become void.
• The iFi warranty is only valid in the country of original sale and is not
transferable.
• The product must not have been stored in a humid environment; nor
subjected to weather, water, or saltwater spray.
• iFi shall not, under any circumstances, be liable for any incidental or
consequential damages arising from the loss of property or other damage
or losses due to the failure of an iFi product. iFi is not liable for loss of use or
inconvenience caused by the failure of an iFi product. iFi is not liable for
damage caused to other audio components because of the failure of an iFi
product.
• During the warranty period, iFi will repair the product to working order, or,
at iFi's discretion, replace the defective module with a similar available
product.
• All repairs performed after expiry of the warranty period will be charged to
the owner and will carry a 180-day warranty on parts and labour. The
customer is responsible for shipping the unit to the iFi distributor in the
original packaging. This includes the payment of any shipping charges and
related taxes.
• Should any warranty issues arise, iFi’s decision is full and final.
