Operating instructions
Ultrasonic flow meter
SUH200
SUH201
SUH400
SUH401
11577878 / 0011 / 2023
GB
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
2
Table of contents
1 Preliminary note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Warnings.............................................................. 4
2 Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Intended use................................................................ 6
3.1 Application area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Function ................................................................... 7
4.1 Options for output OUT1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Options for output OUT2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3 IO-Link ............................................................... 8
5 Installation.................................................................. 9
5.1 Process connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.1.1 Clamp............................................................ 9
5.2 Interference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.3 Installation position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.3.1 Recommended installation position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.3.2 Non recommended installation position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Operating and display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Menu...................................................................... 15
8.1 Main menu and submenus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8.2 Available parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
9 Set-up..................................................................... 22
9.1 Guided installation via an installation wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10 Parameter setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10.1 Parameter setting via the unit keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10.2 Parameter setting via IO-Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10.3 Output configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10.3.1 Switching signal for limit value monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10.3.2 Switching signal Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
10.3.2.1 Switching signal for flow direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10.3.2.2 Switching signal for signal quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10.3.3 Consumed quantity monitoring (totaliser function). . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10.3.3.1 Switching signal totaliser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
10.3.3.2 Pulse signal totaliser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
10.3.4 Analogue signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
10.3.5 Frequency signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
10.3.6 Error behaviour of the outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
10.3.7 Output off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
10.4 Application configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
10.4.1 Guided installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
10.4.2 Standard unit of measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
10.4.3 Process value for OUT1 and OUT2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
10.4.4 Damping.......................................................... 36
10.4.5 Output polarity of the switching outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.4.6 Low flow cut-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.4.7 Flow direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
10.4.8 Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
10.4.9 Totaliser reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
10.4.10 Counting method of the totalisers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
10.4.11 Lock / unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.4.12 Reset the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.5 Display ............................................................... 42
10.5.1 Display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
10.5.2 Display rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
3
10.5.3 Display brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
10.5.4 Display update rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
10.5.5 Display layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
10.5.6 Display colour setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
10.6 Diagnostic functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
10.6.2 Memory........................................................... 47
10.6.3 Operating hours counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
10.6.4 Internal temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.6.5 Signal quality. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.6.6 Operating status LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
10.6.7 Simulation......................................................... 49
10.7 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
10.7.1 Device information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
10.7.2 Optical localisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
11 Operation .................................................................. 52
11.1 Process value display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
12 Troubleshooting ............................................................. 53
12.1 Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
12.2 Error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
13 Maintenance, repair and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
14 Factory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
4
1 Preliminary note
You will find instructions, technical data, approvals and further information using the QR code on the
unit / packaging or at .documentation.ifm.com
1.1 Symbols used
Requirement
Instructions
Reaction, result
[...] Designation of keys, buttons or indications
Cross-reference
Important note
Non-compliance may result in malfunction or interference.
Information
Supplementary note
1.2 Warnings
Warnings indicate the possibility of personal injury and damage to property. This enables safe product
handling. Warnings are graded as follows:
WARNING
Warning of serious personal injury
wIf the warning is not observed, fatal and serious injuries are possible.
CAUTION
Warning of minor to moderate personal injury
wIf the warning is not observed, minor to moderate injuries are possible.
ATTENTION
Warning of damage to property
wIf the warning is not observed, damage to property is possible.
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
5
2 Safety instructions
• The unit described is a subcomponent for integration into a system.
– The system architect is responsible for the safety of the system.
– The system architect undertakes to perform a risk assessment and to create documentation in
accordance with legal and normative requirements to be provided to the operator and user of
the system. This documentation must contain all necessary information and safety instructions
for the operator, the user and, if applicable, for any service personnel authorised by the
architect of the system.
• Read this document before setting up the product and keep it during the entire service life.
• The product must be suitable for the corresponding applications and environmental conditions
without any restrictions.
• Only use the product for its intended purpose ( Intended use).Ò
• Only use the product for permissible media.
• If the operating instructions or the technical data are not adhered to, personal injury and/or damage
to property may occur.
• The manufacturer assumes no liability or warranty for any consequences caused by tampering with
the product or incorrect use by the operator.
• Installation, electrical connection, set-up, operation and maintenance of the product must be
carried out by qualified personnel authorised by the machine operator.
• Protect units and cables against damage.
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
6
3 Intended use
The unit monitors liquid media.
The unit detects the flow velocity, the volume flow (volumetric flow quantity/time), the consumed
quantity and the medium temperature.
3.1 Application area
Liquids with the following properties:
• conductive water-based media with 90% water content.
• non-conductive water.
Pressure Equipment Directive (PED):
The units comply with the Pressure Equipment Directive and are designed and manufactured
for group 2 fluids in accordance with the sound engineering practice. Use of media from group 1
fluids on request.
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
7
4 Function
• The unit detects the volumetric flow based on the measuring principle of ultrasonic transit time
difference.
• As additional process value the unit detects the medium temperature.
• The unit displays the current process values.
• The unit can be operated in SIO mode (standard input-output ) or in IO-Link mode.
• The unit has many self-diagnostic options.
– Monitoring of the flow direction
– Monitoring of the signal quality
– Indication of warnings and error messages
• The unit indicates all self-diagnostic options through the colour signal of an operating status LED.
In addition, the diagnostic information is provided via the outputs and the IO-Link interface.
• A simulation mode allows simplified set-up of the sensor.
4.1 Options for output OUT1
• Switching signal flow
• Switching signal temperature
• Switching signal diagnosis
– Direction of flow
– Signal quality
• Switching signal totaliser
• Pulse signal totaliser
• Frequency signal flow
• Frequency signal temperature
• IO-Link
• OFF (output switched to high impedance)
4.2 Options for output OUT2
• Switching signal flow
• Switching signal temperature
• Switching signal diagnosis
– Direction of flow
– Signal quality
• Switching signal totaliser
• Pulse signal totaliser
• Analogue signal flow
• Analogue signal temperature
• Input for external totaliser reset
• OFF (output switched to high impedance)
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
8
4.3 IO-Link
IO-Link is a communication system for connecting intelligent sensors and actuators to automation
systems. IO-Link is standardised in the IEC 61131-9 standard.
General information on IO-Link at io-link.ifm
Input Output Device Description (IODD) with all parameters, process data and detailed
descriptions of the device at documentation.ifm.com
IO-Link offers the following advantages:
• Interference-free transmission of all data and process values
• Parameter setting in the running process or presetting outside the application
• Parameters for identifying the connected devices in the system
• Additional parameters and diagnostic functions
• Automatic backup and restore of parameter sets in case of device replacement (data storage)
• Logging of parameter sets, process values and events
• Device description file (IODD - Input Output Device Description) for easy project planning
• Standardised electrical connection
• Remote maintenance
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
9
5 Installation
CAUTION
If the medium temperature is above 50 °C (122 °F), parts of the housing can increase in
temperature to over 65 °C (149 °F).
wRisk of burns.
uProtect the housing against contact with flammable substances and unintentional
contact.
uEnsure that the system is free of pressure during installation.
uThe rules and regulations for the installation and operation of compressed air equipment
must be observed.
ATTENTION
No functional earthing when installed in an ungrounded pipe system (e.g. plastic pipes).
wDeficient operating function.
uGround the device. Ground brackets for the M12 connector are available as accessories,
see .documentation.ifm.com
After installation, air bubbles in the system can affect the measurement.
uRinse the system after installation for ventilation.
5.1 Process connection
The SUHxxx device series has hygienic process connections located directly on the device.
5.1.1 Clamp
The SUH2xx and SUH4xx devices have a clamp connection in accordance with ISO2852 (DIN32676)
as a process connection.
A suitable sealing ring and a hinge clamp or high-pressure clamp are required for installation. Sealing
ring and clamp are not included in the scope of delivery.
1 12 23 34 4
Fig.1: Process connection Clamp
1: Clamp 2: Clamp connection of the pipe or adapter
3: Sealing ring 4: Clamp connection of the sensor
uIf necessary, install the clamp adapter in the pipe.
uInsert the sealing rings and secure the device with a clamp. Observe the direction of flow ( FlowÒ
direction 37)/.
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
10
uAvoid edge formation at the transition between the sensor and the pipe, as this can affect the
flow profile and the measuring accuracy ( Figure).Ò
u ÒObserve information on suitable pipe standards ( ).documentation.ifm.com
SUHxxx SUHxxx
Fig.2: Avoid edge formation in the process connection
5.2 Interference
Structures in the pipe, bends, valves, reducing pieces and the like affect the function of the unit.
uAdhere to the distances between sensor and interference.
FSS
5 x D 1 x D
Fig.3: Interference
D: Outside diameter of the pipe
S: Interference
5.3 Installation position
5.3.1 Recommended installation position
uInstall the unit so that the measuring pipe is always completely filled.
uInstall in front of or in a rising pipe.
If air bubbles can form in the pipe system:
uIn case of horizontal installation, mount the sensor with the display on the side of the pipe
(A).
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
11
A B
C
F
F
F
Fig.4: recommended installation position
F: direction of flow
A: horizontal installation, display on the side of the pipe.
B: horizontal installation, display on top of the pipe.
C: vertical installation.
The unit can be installed independently of the orientation if the following is ensured:
- No air bubbles can form in the pipe system.
- The pipes are always completely filled.
5.3.2 Non recommended installation position
• Directly in front of a falling pipe.
• In a falling pipe.
• Directly in front of the spout of a pipe.
• Directly in front of a valve.
• On the suction side of a pump.
• At the highest point of the pipe system.
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
12
6 Electrical connection
The unit must be connected by a qualified electrician.
Observe the national and international regulations for the installation of electrical equipment.
Voltage supply according to SELV, PELV.
uDisconnect power.
uConnect the unit as follows:
43
2 1
L
1 BN
2 WH
4 BK
3 BU
OUT1/ IO-Link
OUT2
L+
Fig.5: Wiring diagram (colours to DINEN60947-5-2)
BN: Brown
WH: White
BK: Black
BU: Blue
Pin Connection
1 L+
3 L-
4 (OUT1) • Switching signal flow
• Switching signal temperature
• Switching signal diagnosis
• Switching signal totaliser
• Pulse signal totaliser
• Frequency signal flow
• Frequency signal temperature
• IO-Link
• OFF (output switched to high impedance)
2 (OUT2/InD) • Switching signal flow
• Switching signal temperature
• Switching signal diagnosis
• Switching signal totaliser
• Pulse signal totaliser
• Analogue signal flow
• Analogue signal temperature
• Input for external totaliser reset
• OFF (output switched to high impedance)
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
13
1 2
3 4
Fig.6: Circuit examples
1: 2 x positive switching
2: 2 x negative switching
3: 1 x positive switching / 1 x analogue
4: 1 x negative switching / 1 x analogue
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
14
7 Operating and display elements
2
3
4
4a
4b
1
5
Fig.7: operating and display
elements
1: switching status LED for OUT1
(lights yellow if output 1 is switched).
2: switching status LED for OUT2
(lights yellow if output 2 is switched).
3: operating status LED (green/ blue/ red).
See also: .Operating status LED ( 49)Ò/
4: TFT display
See also: .Display layout ( 44)Ò/
4a: title line
4b: process value line
5: keys for changing views and parameter setting.
If the unit measures a high internal temperature, the display brightness is automatically
adjusted:
Internal temperature of the unit>64°C: brightness is reduced to 25%.
Internal temperature of the unit≥90°C: display is automatically switched off.
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
15
8 Menu
The figures in which the menus are displayed show the parameters that can be set on the unit by key
input. These parameters and other functions are also available via the IO-Link interface.
Process value display
Main menu
Extended functions
[EF]
Totaliser [TOTL]
Display settings [DIS]
OUT1 configuration [OUT1]
Basic settings [CFG]
OUT2 configuration [OUT2]
Diagnostic indicators [DIAG]
Simulation mode [SIM]
Device info [d.InF]
Reset device [rES]
Fig.8: menu overview
8.1 Main menu and submenus
The displayed parameters change when the factory setting is changed. The following menu
displays show the maximum available parameters.
Process value display
EF
rP1
SP1 FH1
FL1
OUT1, OUT2, CFG, TOTL, D S, D AG, S M, d. nF, I I I I
rES
ImPS1
ImPR1
FSP1
FEP1
FrP1
AEP2
BACK
ASP2 SP2
rP2
FH2
FL2
ImPS2
ImPR2
D n2I
Fig.9: main menu [SU]
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
16
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
d. nFI
rES
BACK
EF
SEL1
ou1
BACK
FOU1
OUT1
OU ON OFF
Hno Hnc Fno FncImP FRQ dOU
TEMP OFFFLOW
Fdir Sig.Q
rP1
SP1 FH1
FL1
ImPS
ImPR
FSP1
FEP1
FrP1
Main menu
Fig.10: output 1 configuration menu [OUT1]
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
d. nFI
rES
BACK
EF
SEL2
ou2
BACK
FOU2
OUT2
OU ON OFF
Hno Hnc Fno FncI ImP n.D dOUI
TEMP OFFFLOW
rP2
SP2
AEP2
ASP2 FH2
FL2
I ImPS D n2
ImPR
Fdir Sig.Q
Main menu
Fig.11: output 2 configuration menu [OUT2]
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
17
Main menu
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
BACK
EF
uni.F
uni.T
dAP.F
P-n
Fdir
CFG
°C
---
PnP nPn
---
YES NO
-+
°F
LFC
CGA
BACK
---
Guide
m3/h m/sl/min l/h
gal/min gal/h ft/s
d. nFI
rES
Fig.12: basic settings menu [CFG]; * Additionally for unit type SUxxx1
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
BACK
EF
TOTL
FPro1
FPro2
Vol.1
Vol.2
Vol.L
BACK
...
...
...
...
WEEK
...
DAY
...
HOUR
OFF
rTo2 Reset
...
WEEK
...
DAY
...
HOUR
OFF
rTo1 Reset
-+ 0 + ++
-+
- 0
- 00+ ++
d. nFI
rES
Main menu
Fig.13: totaliser menu [TOTL]
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
18
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
BACK
EF
COLR
D SI
LanG EN FR ...DE
diS.U d1 d2 d3
diS.R 0 90 180 270
diS.B 25OFF 50 75 100
---
cFH.T
cFH.F ---
---
cFL.F
---
cFL.T
coL.F bk/wh red green r-cF G-cFyellow
bk/wh red green r-cF G-cFyellow
coL.T
coL.V bk/wh red green
LED.M On OFF Noti
yellow
diS.L L2.Tem L2.Totl L3 L4L1
BACK
d. nFI
rES
Main menu
Fig.14: display settings menu [DIS]
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
BACK
EF
DIAG
d. nFI
rES
Main menu
Flow min
Internal temperature
Signal quality
Operating hours
Flow max
Temperature min
Temperature max
Fig.15: diagnostic indicators menu [DIAG]
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
19
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
BACK
EF
S.TMP
S.Tim
S MI
---
---
---
S.FLW
S.On
BACK
---
d. nFI
rES
Main menu
Fig.16: simulation mode menu [SIM]
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
BACK
EF
d.InF
d. nFI
rES
Main menu
Product name
Device ID
Serial number
Hardware revision
Application-Specific Tag
Function Tag
Software revision
Location Tag
Fig.17: device information menu [d.InF]
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
20
OUT1
OUT2
CFG
TOTL
D SI
D AGI
S MI
BACK
EF
d. nFI
rES
APPL
Back
BtB
---
---
Main menu
Fig.18: reset menu [rES]
8.2 Available parameters
Parameter Explanation
AEPx Analogue end point for OUTx = process value at which the output signal is 20 mA.
ASPx Analogue start point for OUTx = process value at which the output signal is 4 mA.
cFH.F Upper limit value for colour change (flow)
cFH.T Upper limit value for colour change (temperature)
cFL.F Lower limit value for colour change (flow)
cFL.T Lower limit value for colour change (temperature)
CGA Calibration factor in % for adapting the measured value curve to the application
coL.F Font colour for flow
col.T Font colour for temperature
col.V Font colour for totaliser indication
dAP.F Damping time in seconds for flow measurement
dOU Switching signal for diagnostic messages
DIn2 Totaliser reset via external signal
diS.B Brightness of the display
diS.L Display layout
diS.R Orientation of the display
diS.U Update rate of the display
Fdir • Flow direction setting (in menu CFG)
• Switching signal for flow direction (in menu OUTx)
FEPx Frequency end point for OUTx = Upper measured value at which the frequency signal set under
FrPx is output.
FHx Upper limit for switching signal OUTx with window function
FLx Lower limit for switching signal OUTx with window function
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
21
Parameter Explanation
FOUx Behaviour of output OUTx in case of an error
FProx Counting method of the totaliser: consideration of the direction of flow
FrPx Frequency signal that is output when the upper measured value (MEW or FEPx) is reached.
FSPx Frequency start point for OUTx = Lower measured value from which a frequency signal is output
(only for temperature measurement).
Guide Activation of the guided installation (wizard)
ImPRx Totaliser function: pulse signal (ImPR = YES) or switching signal (ImPR = NO)
ImPSx Pulse value (= flow value at which 1 pulse is provided)
LanG Language selection for the display
LED.M Setting of the operating status LED
LFC Low flow cut-off (= flow value below which flow is evaluated as standstill)
oux Output configuration for output OUTx (e.g. switching output with hysteresis function)
P-n Output polarity for the switching outputs
rES Reset to factory settings (Back to Box) or reset of parameter settings (application reset).
rPx Reset point for switching output OUTx with hysteresis function
rTo Setting of the totaliser reset (manually or time-controlled)
S.FLW Simulated flow value in simulation mode
Sig.Q Switching signal for signal quality monitoring
S.On Starts the simulation mode
S.Tim Duration of the simulation in minutes
S.TMP Simulated temperature value in simulation mode
SELx Process value for output OUTx
SPx Switch point for switching output OUTx with hysteresis function
uni.F Standard unit of measurement for flow
uni.T Standard unit of measurement for temperature
Vol.L Current counter reading for totaliser Vol.L over the whole lifetime
Vol.x Current counter reading for totaliser Vol.x
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
22
9 Set-up
After power on and expiry of the power-on delay time, the unit is in the normal operating mode. It
carries out its measurement and evaluation functions and generates output signals according to the
set parameters.
During the power-on delay time the outputs are switched as programmed:
• ON with normally open function (Hno / Fno)
• OFF with normally closed function (Hnc / Fnc)
• ON for detection of direction (dir.F)
• OFF for frequency output (FRQ)
• OFF for consumed quantity monitoring (ImP)
• 20 mA for analogue output (I)
9.1 Guided installation via an installation wizard
New unboxed and factory reset devices – setup via main menu. When changing from process value
display to main menu you will be given the option to use the guided installation wizard.
uSelect [Yes] or [No].
wIf [Yes] is selected, parameters, questions and instructions appear in succession. Use the [▲] and
[▼] keys to choose from the available options and the [●] key to confirm the selection.
wIf [No] is selected, the main menu appears and the sensor functions according to the factory
settings. If necessary, change the parameter settings, see chapter Parameter setting.
The guided installation can be called up again at any time via the parameter [EF] > [CFG] >
[Guide].
During guided installation, the following setting options appear in succession:
1. [diS.R]: display rotation
2. [LanG]: display language
3. [Fdir]: flow direction
4. Output OUT1:
– [SEL1]: process value (flow or temperature) or diagnosis (flow direction or signal quality).
– [uni.T] / [uni.F]: standard unit of measurement
– [ou1]: switching signal (Hno, Hnc, Fno, Fnc), pulse signal/switching signal totaliser, frequency
signal
– configuration of the parameters according to the function selected for [ou1]:
limit values for switching signal: SP1, rP1, FH1, FL1
pulse value for totaliser: ImPS
switch point and reset for totaliser: ImPS1, rTo1
limit values for frequency signal: FSP1 (only for temperature), FEP1, FrP1
– [FOU1]: error behaviour of the output
5. Output OUT2:
– [SEL2]: process value (flow or temperature) or diagnosis (flow direction or signal quality).
– [uni.T] / [uni.F]: standard unit of measurement
– [ou2]: switching signal (Hno, Hnc, Fno, Fnc), pulse signal/switching signal totaliser, analogue
signal
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
23
– configuration of the parameters according to the function selected for [ou2]:
limit values for switching signal: SP2, rP2, FH2, FL2
pulse value for totaliser: ImPS2
switch point and reset for totaliser: ImPS2, rTo2
limit values for analogue signal: ASP2, AEP2
– [FOU2]: error behaviour of the output
6. [diS.L]: display layout
After the message that the guided installation is completed, you are asked whether you want to start
the measurement.
uSelect [Yes] or [No] or [Device info].
wIf [Yes] is selected, the installation process is completed and the unit changes to the process value
display.
wIf [No] is selected, the parameters for the flow direction, OUT1/OUT2 and the display layout (steps
3...6) can be modified again, or the guided installation can be restarted from the beginning using
the [Restart Guide] command.
wIf [Device info] is selected, the unit displays the previously set unit configuration.
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
24
10 Parameter setting
Parameter setting can be carried out via the IO-Link interface or via the operating elements on the
unit.
Parameters can be set before installation or during operation.
If you change parameters during operation, this will influence the function of the plant.
uEnsure that there will be no malfunctions in your plant.
During parameter setting the unit remains in the operating mode. It continues to monitor with the
existing parameter until the parameter setting has been completed.
Depending on the parameter setting, the parameters available in the menu may change.
10.1 Parameter setting via the unit keys
CAUTION
If the medium temperature is above 50 °C (122 °F), parts of the housing can increase in
temperature to over 65 °C (149 °F).
wRisk of burns
uDo not touch the device with your hands.
uIf necessary, use a blunt object to make settings on the device.
Intention Action
Change from the process value display to the main menu [●]
Change to the submenu Use [▼] to navigate to the submenu,
e.g. [EF], then [●]
Select the required parameter [▲] or [▼]
Change to the setting mode [●]
Modify the parameter value [▲] or [▼]
Apply the set parameter [●]
Exit parameter setting without saving [▲] + [▼]
Return to the next higher menu level
(repeat several times to reach process value display)
[▲] + [▼]
- or -
Use [▲] or [▼] to navigate to [Back],
then [●]
Return to the process value display > 30 seconds (timeout)
When changing from the process value display to the main menu or after resetting the unit, the
guided installation option is automatically displayed. You are asked whether you want a guided
installation.
See also: .Guided installation via an installation wizard ( 22)Ò/
10.2 Parameter setting via IO-Link
Requirements for parameter setting via the IO-Link interface:
üA suitable parameter setting software, e.g. ifm moneo|configure
üThe Input Output Device Description (IODD) for the device, see documentation.ifm.com
üOne IO-Link master
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
25
uConnect the IO-Link master to a parameter setting software.
uSet the port of the master to the IO-Link operating mode.
uConnect the device to a free port of the IO-Link master.
wThe unit switches to IO-Link mode.
uChange parameter settings in the software.
uWrite parameter settings to the unit.
Notes on parameter setting Manual of the parameter setting softwareÒ
10.3 Output configuration
This chapter describes the options for the output signals at OUT1 and OUT2.
10.3.1 Switching signal for limit value monitoring
A switching signal can be output for process value monitoring. OUTx changes its switching state when
the set switching limits are exceeded or not reached. You can choose between hysteresis and window
function.
Hysteresis function:
SP
t
Hno
HY
Hnc
rP
1
0
1
0
1
Fig.19: Hysteresis function
1: Process value
t: Time
SP: Set point
rP: Reset point
HY: Hysteresis
Hno: Hysteresis function NO (normally open)
Hnc: Hysteresis function NC (normally closed)
When the hysteresis function is set, the set point [SP] and the reset point [rP] are set. The rP
value must be lower than the SP value. The difference between SP and rP is at least 0.5 % of
the final value of the measuring range (= hysteresis). If only the set point is changed, the reset
point is changed automatically; the difference remains constant.
Window function:
FE FE
FH HY
HY
t
Fno
Fnc
FL
1
0
1
0
1
Fig.20: Window function
1: Process value
t: Time
FH: Upper limit value
FL: Lower limit value
HY: Hysteresis
FE: Window area
Fno: Window function NO (normally open)
Fnc: Window function NC (normally closed)
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
26
When set to the window function, the window high [FH] and the window low [FL] are set. The
difference between FH and FL is at least 0.5% of the final value of the measuring range. FH and
FL have a fixed hysteresis of 0.25% of the final value of the measuring range. This helps keep
the switching status of the output stable if the flow rate varies slightly.
10.3.1.1 Parameter setting via unit keys: Switching signal
üStandard unit of measurement is selected: [EF] > [CFG] > [uni.x].
uGo to [EF] > [OUTx] to configure output OUTx.
uSelect [SELx] and set the process value: [FLOW] or [TEMP].
Hysteresis function:
uSelect [ou] and set the switching signal: [Hno] or [Hnc].
uSelect [SPx] and set the measured value at which the output switches.
uSelect [rPx] and set the measured value at which the output switches back.
Window function:
uSelect [ou] and set the switching signal: [Fno] or [Fnc].
uSelect [FHx] and set the upper limit of the window.
uSelect [FLx] and set the lower limit of the window.
The parameter settings for [SP], [rP], [FH] and [FL] can be changed subsequently in the main
menu.
10.3.1.2 Parameter setting via IO-Link: Switching signal
üStandard unit of measurement is selected: [Parameter] > [Basic settings] > [uni.x].
uGo to [Parameter] > [Output configuration].
uSelect [SELx] and set the process value: [FLOW] or [TEMP].
Hysteresis function:
uSelect [oux] and set the switching signal: [Hno] or [Hnc].
uCall up [Parameters] > [Digital Output x].
uCall up [flow] or [temperature].
uSelect [SPx (FHx) - FLOW] or [SPx (FHx) - TEMP] and set the measured value at which the output
switches.
uSelect [rPx (FLx) - FLOW] or [rPx (FLx) - TEMP] and set the measured value at which the output
switches off.
Window function:
uSelect [oux] and set the switching signal: [Fno] or [Fnc].
uCall up [Parameters] > [Digital Output x].
uCall up [flow] or [temperature].
uSelect [SPx (FHx) - FLOW] or [SPx (FHx) - TEMP] and set the upper limit for the switching signal.
uSelect [rPx (FLx) - FLOW] or [rPx (FLx) - TEMP] and set the lower limit for the switching signal.
10.3.2 Switching signal Diagnosis
The unit features an integrated diagnostic function. When using the diagnostic function, the output is
used exclusively for diagnostic message output, which it indicates by a switched signal.
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
27
The switching output is switched on in normal operation (normally closed) and the switching status
LED lights yellow.
If the unit detects a diagnostic case, the output is switched off and the switching status LED goes out.
Diagnostic cases are:
• reversal of the flow direction ( Switching signal for flow direction 27)Ò/
• low signal quality/ no signal ( Switching signal for signal quality 27)Ò/
10.3.2.1 Switching signal for flow direction
A flow direction change can be monitored by providing a switching signal.
An arrow with the text “flow direction” on the device indicates the positive flow direction. The direction
of the flow measurement can be reversed using the parameter [Fdir].
See Flow direction.
The output is switched on until the volumetric flow falls below the set minimum volumetric flow quantity
in negative flow direction (-LFC)(1).
Then the following applies:
• The output switches ON when volumetric flow is above +LFC (2).
• The output switches OFF when volumetric flow is below -LFC (3).
LFC = low flow cut-off: .Low flow cut-off ( 37)Ò/
+ LFC
+ Q
t
- Q
- LFC
1
0
1 2 3
Fig.21: Monitoring of the flow direction by switching signals
+Q Volumetric flow in positive flow direction
-Q Volumetric flow in negative flow direction
+LFC Minimum volumetric flow (low flow cut-off) in positive flow direction
-LFC Minimum volumetric flow (low flow cut-off) in negative flow direction
Parameter setting via unit keys: switching signal for flow direction
uGo to the [EF] > [OUTx] menu.
uSelect [oux] > [dOU] and set [Fdir].
Parameter setting via IO-Link: switching signal for flow direction
uCall up [Parameters] > [Output Configuration].
uSelect [oux] and set [dOU].
uSelect [dFUx] and set [Flow direction].
10.3.2.2 Switching signal for signal quality
The unit can provide a switching signal when the signal quality deviates from normal operation.
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
28
The signal quality of the sensor can be affected by irregularities in the medium (e.g. strong
turbulences, air bubbles, particles or build-up).
The unit detects the signal quality in three stages:
Signal quality Explanation Operating status
LED Switching output
Normal The unit operates without restrictions (normal operation). Lights green On
Low The signal quality is disturbed, but the unit is still work-
ing within its specifications.
Lights blue OFF
No signal No medium is present or no signal can be created. Flashes red OFF
Parameter setting via unit keys: switching signal for signal quality
uGo to the [EF] > [OUTx] menu.
uSelect [oux] > [dOU] and set [Sig.Q].
Parameter setting via IO-Link: switching signal for signal quality
uCall up [Parameters] > [Output Configuration].
uSelect [oux] and set [dOU].
uSelect [dFUx] and set [Signal quality detection]
10.3.3 Consumed quantity monitoring (totaliser function)
The unit has 3 internal quantity meters (totalisers Vol.1, Vol.2 and Vol.L). The totalisers continuously
sum up the consumed quantity and provide this process value both on the display and via the IO-Link
interface.
Totaliser Process value Read access via IO-Link
Vol.1 Consumed quantity 1
(This value is used for consumed quantity monitoring by
switching or pulse signals)
Cyclic
Vol.2 Consumed quantity 2 Acyclic
Vol.L Consumed quantity over the whole lifetime (lifetime totalis-
er)
Acyclic
The totalisers Vol.1 and Vol.2 take account of the flow direction when totalising the consumed
quantity: .Counting method of the totalisers ( 40)Ò/
OUT1 and OUT2 cannot be used simultaneously for the consumed quantity monitoring.
In addition to the current consumed quantity, the value before the last reset is saved. This value and
the time since the last reset can also be displayed.
The totaliser saves the totalled volumetric flow quantity at regular intervals. After a power failure
this value is available as the current meter reading. If a time-controlled reset is set, the elapsed
time of the set reset interval is also saved. This means that the possible data loss can amount
to one minute.
See also: .Read totaliser values ( 46)Ò/
The accuracy of the consumed quantity measurement depends on the accuracy of the volumetric flow
measurement.
A switching signal or pulse signals can be provided for consumed quantity monitoring.
• See Switching signal totaliser ( 29)Ò/
• See Pulse signal totaliser ( 30)Ò/
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
29
10.3.3.1 Switching signal totaliser
A switching signal can be provided for consumed quantity monitoring.
When the Vol.1 totaliser has totalled the volumetric flow quantity set under [ImPS], the output provides
a switching signal. The output remains switched until a totaliser reset is carried out.
The totaliser reset for the totalisers Vol.1 and Vol.2 can be set via the parameter [rTo1] or [rTo2].
When the totaliser has been reset, metering starts again.
• [rTox] = OFF:
automatic reset of totaliser switched off.
A reset is done manually or in case of overflow.
• [rTox] = …h/d/w (hours/days/weeks):
automatic reset of the totaliser after the set time.
– If totaliser Vol.1 reaches the volumetric flow quantity [ImPS] before the set time, no automatic
reset occurs. The output remains switched until totaliser Vol.1 is reset manually or via overflow.
– Totaliser Vol.2 is independent of the settings of [ImPS]. Its count is not taken into account for
the switching and pulse signals.
The totalisers can be reset manually at any time via the [rTox] parameter. Totaliser Vol.1 can
additionally be reset via an external signal at pin 2.
See also: .Totaliser reset ( 38)Ò/
Parameter setting via unit keys: Switching signal totaliser
üStandard unit of measurement is selected: [EF] > [CFG] > [uni.x].
ü[rTox] is set: [EF] > [TOTL] > [rTox].
uGo to [EF] > [OUTx] to configure output OUTx.
uSelect [SELx] and set the process value: [FLOW].
uSelect [ou1] or [ou2] and set [ImP].
uSelect [ImPSx] and set the volumetric flow quantity at which the output switches.
• Press ▲ or ▼ to select the setting range.
• Briefly press ● to confirm the setting range.
• Press ▲ or ▼ to set the requested numeric value.
• Briefly press ● to apply the value.
uSelect [ImPRx] and set [No].
The parameter settings for [ImPS] and [ImPR] can be changed subsequently in the main menu.
Parameter setting via IO-Link: Switching signal totaliser
üStandard unit of measurement is selected: [Parameter] > [Basic settings] > [uni.x].
ü[rTox] is set: [Parameter] > [Totaliser] > [rTox].
uGo to [Parameter] > [Output configuration].
uSelect [SELx] and set the process value: [FLOW].
uSelect [ou1] or [ou2] and set [ImP].
uSelect [Parameter] > [Pulse output x].
uSelect [ImPSx] and set the volumetric flow quantity at which the output switches.
uSelect [ImPRx] and set [No].
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
30
10.3.3.2 Pulse signal totaliser
Pulse signals can be provided for consumed quantity monitoring.
Every time the volumetric flow quantity (pulse value) set under [ImPS] has been reached, the output
provides a pulse signal.
The pulse signal consists of a short switching on and off of the output. The switching status LEDs on
the unit do not display the switching operation.
Pulse signals are not available via the IO-Link interface.
Parameter setting via unit keys: Pulse signal totaliser
üStandard unit of measurement is selected: [EF] > [CFG] > [uni.x].
uGo to [EF] > [OUTx] to configure output OUTx.
uSelect [SELx] and set the process value: [FLOW].
uSelect [ou1] or [ou2] and set [ImP].
uSelect [ImPSx] and set the volumetric flow quantity at which 1 pulse is provided (pulse value).
• Press ▲ or ▼ to select the setting range.
• Briefly press ● to confirm the setting range.
• Press ▲ or ▼ to set the requested numeric value.
• Briefly press ● to apply the value.
uSelect [ImPRx] and set [Yes].
The parameter settings for [ImPS] and [ImPR] can be changed subsequently in the main menu.
Parameter setting via IO-Link: Pulse signal totaliser
üStandard unit of measurement is selected: [Parameter] > [Basic settings] > [uni.x].
uGo to [Parameter] > [Output configuration].
uSelect [SELx] and set the process value: [FLOW].
uSelect [ou1] or [ou2] and set [ImP].
uSelect [Parameter] > [Pulse output x].
uSelect [ImPSx] and set the volumetric flow quantity at which 1 pulse is provided (pulse value).
uSelect [ImPRx] and set [Yes].
10.3.4 Analogue signal
The unit provides an analogue signal of 4…20mA proportional to the process value.
The measuring range is scalable:
• [ASP] determines at which measured value the output signal is 4 mA.
• [AEP] determines at which measured value the output signal is 20 mA.
Minimum distance between ASP and AEP = 20 % of the final value of the measuring range.
If the measured value is outside the measuring range or in the event of an internal error, the current
signal indicated in the following figure is provided.
For measured values outside the display range or in case of an error, messages are displayed (cr.UL,
UL, OL, cr.OL, Err).
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
31
Fig.22: Characteristics of the analogue output according to the standard IEC 60947-5-7
1: Analogue signal MAW: Initial value of the measuring range
2: Measured value MEW: Final value of the measuring range
3: Detection zone ASP: Analogue start point
4: Display range AEP: Analogue end point
5: Measuring range UL: Under limit
6: Scaled measuring range cr.UL: Critical under limit
Q: Flow OL: Over limit
T: Temperature Cr.OL: Critical over limit
A negative flow value means flow against the flow direction set under [Fdir]. See Flow direction
( 37)Ò/.
10.3.4.1 Parameter setting via unit keys: Analogue signal
üStandard unit of measurement is selected: [EF] > [CFG] > [uni.x].
uGo to [EF] > [OUT2] to configure output OUT2.
uSelect [SEL2] and set the process value. [FLOW] or [TEMP].
uSelect [ou2] and set the function: [I] (analogue signal 4...20 mA.).
uSelect [ASP2] and set the measurement value at which the output signal is 4 mA.
uSelect [AEP2] and set the measurement value at which the output signal is 20 mA.
The parameter settings [ASP] and [AEP] can be changed subsequently in the main menu.
10.3.4.2 Parameter setting via IO-Link: Analogue signal
üStandard unit of measurement is selected: [Parameter] > [Basic settings] > [uni.x].
uGo to [Parameter] > [Output configuration].
uSelect [SEL2] and set the process value. [FLOW] or [TEMP].
uSelect [ou2] and set the function: [I] (analogue signal 4...20 mA.).
uSelect [Parameter] > [Analog output2].
uCall up [flow] or [temperature].
uSelect [ASP2_FLOW] or [ASP2_TEMP] and set the measurement value at which the output signal
is 4mA.
uSelect [AEP2_FLOW] or [AEP2_TEMP] and set the measurement value at which the output signal
is 20mA.
SUH200 SUH201 SUH400 SUH401 Ultrasonic flow meter
32
10.3.5 Frequency signal
The device provides a frequency signal proportional to the process value.
The frequency signal is scalable:
• [FrPx] defines the frequency signal in Hz that is provided when the upper measured value is
reached.
The measuring range is scalable:
• [FSPx] defines the lower measured value from which a frequency signal is provided.
• [FEPx] defines the upper measured value at which the output signal has the frequency set under
[FrPx].
[FSPx] is only available for temperature measurement. Minimum difference between [FSPx] and
[FEPx] = 20 % of the final value of the measuring range.
If the measured value is outside the measuring range or in the event of an internal error, the frequency
signal indicated in the following figure is provided.
For measured values outside the display range or in case of a fault, messages are displayed (UL, OL,
Err).
Frequency signal flow:
FOU = OFF 0
2
1
3
4
5
FOU = ON 130
120
100
Err
= FrPx
MAW MEWFEPx OL
100 200 [% MEW]
[% FrPx]
Fig.23: Output characteristics frequency output, flow
1: Frequency signal MAW: Initial value of the measuring range
2: Flow MEW: Final value of the measuring range
3: Display range FEPx: Frequency end point
4: Measuring range FrPx: Frequency signal (Hz) for upper measured value
5: Scaled measuring range OL: Above the display range
Err: Error
Ultrasonic flow meter SUH200 SUH201 SUH400 SUH401
33
Frequency signal temperature:
FOU = OFF 0
2
1
3
4
5
FOU = ON 130
120
100
UL
Err Err
= FrPx
MAW MEWFSPx FEPx OL
100 120 [% MEW]
[% FrPx]
Fig.24: Output characteristics frequency output, temperature
1: Frequency signal MAW: Initial value of the measuring range
2: Temperature MEW: Final value of the measuring range
3: Display range FSPx: Frequency start point
4: Measuring range FEPx: Frequency end point
5: Scaled measuring range FrPx: Frequency signal (Hz) for upper measured value
Err: Error OL: Over limit
10.3.5.1 Parameter setting via unit keys: Frequency signal
üStandard unit of measurement is selected: [EF] > [CFG] > [uni.x].
uGo to [EF] > [OUT1] to configure output OUT1.
uSelect [SEL1] and set the process value: [FLOW] or [TEMP].
uSelect [ou1] and set [FRQ].
uSelect [FSP1] and set the lower measured value at which 0 Hz is output.
[FSP1] is only available for temperature measurement.
uSelect [FEP1] and set the upper measured value at which the frequency set at [FrP1] (= 100 %) is
output.
uSelect [FrP1] and set the frequency for the upper measured value in Hz.
The parameter settings for [FSP], [FEP] and [FrP] can be changed subsequently in the main
menu.
10.3.5.2 Parameter setting via IO-Link: frequency signal
üStandard unit of measurement is selected: [Parameter] > [Basic settings] > [uni.x].
uGo to [Parameter] > [Output configuration].
uSelect [SEL1] and set the process value: [FLOW] or [TEMP].
uSelect [ou1] and set [FRQ].
uCall up [Parameters] > [Frequency Output 1].
uSelect [FrP1] and set the frequency for the upper measured value in Hz.
uCall up [flow] or [temperature].
uSelect [FEP1_FLOW] / [FEP1_TEMP] and set the upper measured value at which the frequency
set at [FrP1] (= 100 %) is output.
uSelect [FSP1 - TEMP] and set the lower measured value at which 0 Hz is output.
Produktspecifikationer
| Varumärke: | IFM |
| Kategori: | Inte kategoriserad |
| Modell: | SUH201 |
Behöver du hjälp?
Om du behöver hjälp med IFM SUH201 ställ en fråga nedan och andra användare kommer att svara dig
Inte kategoriserad IFM Manualer
8 April 2025
8 April 2025
8 April 2025
2 April 2025
2 April 2025
1 April 2025
1 April 2025
1 April 2025
31 Mars 2025
12 Mars 2025
Inte kategoriserad Manualer
- Inte kategoriserad Metz
- Inte kategoriserad WilTec
- Inte kategoriserad JIMMY
- Inte kategoriserad Computherm
- Inte kategoriserad Unicol
- Inte kategoriserad Diana
- Inte kategoriserad Datalogic
- Inte kategoriserad Neutrik
- Inte kategoriserad Cabstone
- Inte kategoriserad Malmbergs
- Inte kategoriserad Edbak
- Inte kategoriserad Audix
- Inte kategoriserad SmallRig
- Inte kategoriserad Ilford
- Inte kategoriserad Bintec-elmeg
Nyaste Inte kategoriserad Manualer
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
