Sida 1/17

Operating instructions
Long-term stable, self-monitoring
temperature transmitter
TADx61
706044/00 06/2006
UK

2
Contents
1 Preliminary note 3 ���������������������������������������������������������������������������������������������������
1�1 Symbols used 3 ������������������������������������������������������������������������������������������������
2 Safety instructions 3 �����������������������������������������������������������������������������������������������
3 Functions and features 3 ����������������������������������������������������������������������������������������
3�1 Application ����������������������������������������������������������������������������������������������������� 3
4 Function ��������������������������������������������������������������������������������������������������������������� 4
4�1 Monitoring and diagnostic functions 4 ��������������������������������������������������������������
4�1�1 Drift / fault monitoring 4 ��������������������������������������������������������������������������
4�1�2 Sensor backup / redundancy switching 5 ������������������������������������������������
4�1�3 Response of the outputs in case of a fault 5 �������������������������������������������
4�2 Analogue function 7 ������������������������������������������������������������������������������������������
5 Installation������������������������������������������������������������������������������������������������������������ 8
6 Electrical connection 10 ������������������������������������������������������������������������������������������
7 Parameter setting 10 ����������������������������������������������������������������������������������������������
7�1 Adjustable parameters 10 ���������������������������������������������������������������������������������
7�2 Service functions 13 �����������������������������������������������������������������������������������������
8 Operation ����������������������������������������������������������������������������������������������������������� 13
8�1 Fault indication 13 ��������������������������������������������������������������������������������������������
9 Scale drawing 15 ����������������������������������������������������������������������������������������������������
10 Technical data 16 ��������������������������������������������������������������������������������������������������
10�1 Temperature resistance 17 �����������������������������������������������������������������������������
11 Factory setting 17 �������������������������������������������������������������������������������������������������

3
UK
1 Preliminary note
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of pushbuttons, buttons or indications
→Cross-reference
Important note
Non-compliance can result in malfunctions or interference�
2 Safety instructions
• Please read this document prior to set-up of the unit� Ensure that the product is
suitable for your application without any restrictions�
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property can occur�
• Checkthecompatibilityoftheproductmaterials(→chapter10Technicaldata)
with the media to be monitored in all applications�
3 Functions and features
The unit detects the system temperature in installations�
3.1 Application
To ensure long-term stability and high accuracy of the unit during operation,
please note:
• The probe must be inserted into the measured medium up to the sealing
chamfer�
• Minimum installation depth of the measuring probe: 25 mm�
• The following limit values must be observed:
Measuring range -25 ��� +150 °C -13 ��� 302 °F
Operating temperature process connection -32 ��� +170 °C -25�6 ��� 338 °F
Operating temperature electronics -25 ��� +70 C -13 ��� 158 °F
Storage temperature -40 ��� +85 °C -40 ��� 185 °F
Operating pressure of the medium ≤50bar ≤725PSI
Numberoftemperaturecycles(135K/7s) < 3000
