5019 501 05004

Ignis is a registered trademark of Whirlpool USA.

Programme

Care

Labels

Type of wash/Notes

Max

Load

Detergents and additives Special options Temperature

Selector

°C

Programme

Selector

Softener Main

Wash

Pre-

wash

Rinse

Hold

Spin Speed

Reduction

Cotton

with prewash

Heavily soiled, long wearing and temperature stable textiles in cotton and linen (bed linen, table linen,

underwear, shirts etc.).

4.5

❉

Yes Yes

❉ ❉

Max. 95°

Synthetics

with prewash

Heavily soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira), polyamide (Perlon,

Nylon) or blends with cotton.

2.5

❉

Yes Yes

❉

Max. 60°

Delicates

with prewash

Heavily soiled curtains and delicate clothing, dresses skirts, shirts and blouses.

1.5

❉

Yes Yes

❉

Max. 40°

Cotton

Slightly to normally soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and

linen.

4.5

❉

Yes

—

❉ ❉

Max. 95°

Cotton

short

Slightly soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and linen.

4.5

❉

Yes

—

❉ ❉

Max. 60°

Synthetics

Slightly to normally soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira), polyamide

(Perlon, Nylon) or blends with cotton.

2.5

❉

Yes

—

❉

Max. 60°

Synthetics

short

Slightly soiled overalls and sports wear made of cotton, polyester, polyamide and blends with cotton.

2.5

❉

Yes

—

❉

Max. 60°

Delicates

Curtains and delicate clothing, dresses skirts, shirts and blouses.

1.5

❉

Yes

—

❉

Max. 40°

Wool

Only woollens with a felt-free finish, labelled with the woolmark and identified as machine washable.

If you select “Rinse Hold” do not leave items to soak for too long.

1.0

❉

Yes

—

❉

Max. 40°

Silk

Textiles made of linen, silk, wool and viscose marked as “handwashable”.

If you select “Rinse Hold” do not leave items to soak for too long. No spinning.

1.0

❉

Yes

—

❉

—

Max. 30°

Rinse + spin

—

With this programme you can add starch and/or fabric softener.

The programme ends with an intensive spin cycle.

4.5

❉

— —

❉ ❉

—

Spin

—

In this programme spinning is intensive. Same as the spin cycle in the “Cotton” programme.

4.5

— — — —

❉

—

Gentle spin

—

In this programme spinning is gentle. Same as the spin cycle in the “Wool” programme.

1.5

— — — —

❉

—

Drain

—

Drain only - no spinning. Alternative method of terminating programme the synthetic, delicate and wool

programme and for premature removal of the laundry.

— — — — — — —

❉

: optional / Yes : dosing required

For improved garment care spin speed is restricted to

900 rpm in this programme.

For improved garment care spin speed is null in this

programme.

During the selected washing programme the

programme selector knob moves by steps

clockwise through the phases

prewash

main wash

rinse and spin

. Each step takes from some seconds

to several minutes.

A. “On/Off” Button

Cotton

Synthetics

Delicates

AWP 061

5gb05004.fm5 Page 1 Monday, July 2, 2001 7:05 PM

Black Process Plate

5019 501 05004

Ignis is a registered trademark of Whirlpool USA.

Prewash cycle increases programme duration approximately 15 min. Consumption values were measured in normalized

conditions in compliance with Standard IEC 60 456. Consumption data in the home may vary with respect to the values in the

table in relation to the water supply pressure and temperature, the load and the type of wash.

Add the detergents as described in the programme

table or in the chapter “Detergents and Additives” in

the booklet.

1. Open the tap.

2. Set the

programme selector

to the desired

programme.

3. Set the

temperature selector

to the desired

temperature.

Special options

can be selected.

5. Check that the door is well closed and turn on the

washing machine by pressing the

“ ”ON/OFF

button.

“ ”Rinse Hold button

•The laundry remains in the last rinse water

without progressing to the final spin cycle to avoid

creasing and prevent colours from changing.

•This option is particularly recommended for the

programme “Synthetics” or “Delicates”.

•This function is particularly useful if you want to

postpone spinning to a later time, or if you want to

drain only.

Terminate the “Rinse Hold” option:

• “ ”Press the Rinse Hold button again; the

programme will terminate automatically with the

final spin cycle for the present wash programme.

If you do not wish to spin the clothes, turn the

programme selector knob to the “Drain”

programme.

“ ”Spin Speed Reduction button

•Reduces the predetermined automatic maximum

spin speed.

In some programmes the maximum final spin

speed is limited to go easy on your laundry items.

Selection of a higher spin speed is not possible.

To reselect a programme when a cycle has already

begun:

1. Switch off the appliance by pressing the

“

ON/OFF

” button.

2. Select the new programme.

3. Start the programme by pressing the “

ON/OFF

”

button.

CONSUMPTION DATA

Programme

Temperature

Selector

(°C)

Load

(kg)

Water

(l)

Energy

(kWh)

Approx.

Programme

Duration

(hours : minutes)

Cotton 95 4.5 48 1.60 1:55

Cotton 60 4.5 44 0.85 2:00

Cotton 40 4.5 44 0.55 1:45

Synthetics 60 2.5 55 0.80 1:25

Synthetics 40 2.5 50 0.60 1:20

Delicates 40 1.5 50 0.50 0:45

Wool 40 1.0 50 0.50 0:40

Silk 30 1.0 35 0.40 0:40

ADD DETERGENTS, CLOSE THE DOOR AND

SELECT THE PROGRAMME

SELECT ANY DESIDERED OPTION

PROGRAMME CHANGE

1. At the end of the programme the programme

selector moves to the stop position.

2. To unload the machine wait for the door to

unlock (about 1 minute).

3. Switch off the appliance, open the door and

take out the laundry.

4. Close the tap and leave the door ajar to allow

the drum to dry out.

•

WATER LEVEL

It may not be visible as the cycle is optimised

for a minimum water consumption without

compromising washing results.

•

SPIN SPEED CONTROL

Spin speed may be reduced automatically or

may even be excluded in the case of small

loads with highly absorbent garments (e.g.

bathrobes, bathmat).

This control avoids cloth and machine damage

and excessive vibrations and consequent noise

produced by the machine due to load

unbalance: by selecting high spin speeds the

noise level increases.

•

MOTOR NOISE

The running noises of the new, electronically-

controlled motor are not the same as the

ones you are used to from your old appliance.

Don’t be surprised - modern technology has a

modern sound.

•

CLEANING THE FILTER

To ensure an impeccable function of the

pump, check the filter regular and clean it if

necessary.

PROGRAMME END NOTES AND INDICATIONS FOR USE

5gb05004.fm5 Page 2 Monday, July 2, 2001 7:05 PM
