LED Light Strip
User’s Guide for Model IAT151 v2799-01
Back of TV or Monitor
Fold at corners as shown.
Features
• Length: 15 ft/4.5M
• Width: .4 in/10mm
• 90 LEDs total (5050 RGB LED)
• 5V USB power input
• Self adhesive, double sided backing
Includes
• USB cable with built-in remote receiver
• Remote control with CR 2025 battery included
Installation
1. Clean the surface to which you’re going to attach the light strip. The example shown below represents the
back of a TV or computer monitor.
2. Peel the backing strip o the adhesive tape on the LED strip.
3. Press and hold the LED strip to the surface.
4. Connect the USB cable to a USB port on the TV or monitor, or a USB power adapter (not Included).
5. Use the remote to change LED color, brightness, and ash settings.
• The remote receiver does not need to be visible or have direct line of sight with the remote, and can be
fully hidden behind your TV, monitor, etc.
• You may cut the strip to t smaller areas. Using scissors, cut on the visible line between LEDs.
Connect USB plug
to an available USB
outlet or a USB power
adapter (not included)
The remote receiver is built
into the USB power cable.
