Sida 1/8
LSA-BAS Series
Baby Boom Arm with Baby
Receiver, 86 in.
B-EBPS and B-EBPA Series
Baby Boom Arm with Ear, 86 in
INSTRUCTIONS
2
Thank you for choosing Impact.
Impact’s boom arms are essential light stand accessories
that are a perfect match for steel roller stands and C-stands.
These boom arms feature telescoping extensions that extend
the boom’s length to approximately 7 feet, and the beefy
construction and oversized locking knobs will securely hold
lights and strobes at enough distance to stay out of the picture
frame. The LSA series boom arms are made with a built-in
ratcheting pivot clamp with a baby receiver, and the B-EBPS and
B-EBPA series boom arms are made with a steel mounting ear
that ts perfectly into any 2.5-inch grip head. Adjustable sleeves
and heavy-duty counterbalance hooks let you quickly and
effortlessly nd perfect balancing points for your gear.
• Please read and follow
these instructions, and
keep this manual in a safe
place.
• Clean the unit with only a
soft, dry cloth.
• Make sure everything is
secure before proceeding.
• Make sure that this
product is intact and that
there are no missing parts.
• Do not exceed the
maximum load capacity.
• Make sure the boom is
balanced with enough
counterweight
• All images are for
illustrative purposes only.
3
1. Sleeve locking knob
2. Boom
3. Telescoping extension
locking knob
4. Telescoping extension
5. Baby pin
6. Mounting ear
7. Hook
1. Boom
2. Telescoping extension
3. Baby pin
4. Telescoping extension
locking knob.
5. Sleeve locking knob
6. Pivot mount
7. Baby receiver locking
knob
8. Baby receiver
9. Pivot locking knob
10. Hook
B-EBPS / B-EBPA Series
Grip Head *required - not included
LSA-BAS Series
1 212 3 34
4
5
6
7
8
9
10
5
2
1
1. Grip head main handle
(pivot locking knob)
2. Grip head baby receiver
locking knob
