Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 4

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 5

General safety

Disposal

Description of the washing machine

and starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the spin speed

Functions

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Garments requiring special care

Load balancing system

Troubleshooting, 11

Service, 12

IWD 71051

Instructions for use

WASHING MACHINE

English,1

Polski,25

Français,13

Magyar,61

Česky,49

Espańol,37

ΕΛΛΗΝΙΚΑ,73

Installation

! This instruction manual should be kept in a safe

place for future reference. If the washing machi-

ne is sold, transferred or moved, make sure that

the instruction manual remains with the machine

so that the new owner is able to familiarise him-

self/herself with its operation and features.

! Read these instructions carefully: they con-

tain vital information relating to the safe instal-

lation and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its

packaging.

2. Make sure that the washing machine has

not been damaged during the transportation

process. If it has been damaged, contact the

retailer and do not proceed any further with

the installation process.

3. Remove the 3 pro-

tective screws and

the rubber bush with

the respective spacer,

situated on the rear of

the appliance (see also

the installation leaflet).

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the washing machine ne-

eds to be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washing machine on a flat sturdy

floor, without resting it up against walls, furni-

ture cabinets or anything else.

2. If the floor is not

perfectly level, com-

pensate for any une-

venness by tightening

or loosening the

adjustable front feet

(see figure); the angle

of inclination, measu-

red in relation to the

worktop, must not

exceed 2°.

Levelling the machine correctly will provide

it with stability, help to avoid vibrations and

excessive noise and prevent it from shifting

while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow

a sufficient ventilation space underneath the

washing machine.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to

a cold water tab using

a ¾ threaded connec-

tion (see figure).

Before performing the

connection, allow the

water to run freely un-

til it is perfectly clear.

2. Connect the inlet

hose to the washing

machine by screwing

it onto the correspon-

ding water inlet of the

appliance, which is

situated on the top

right-hand side of the

rear part of the ap-

pliance (see figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the values indicated in the Technical details

table (see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Produktspecifikationer

Varumärke:	Indesit
Kategori:	tvättmaskin
Modell:	IWD 71051 C ECO
Inbyggd display:	Ja
Vikt:	67000 g
Bredd:	595 mm
Djup:	535 mm
Höjd:	850 mm
Förpackningens bredd:	640 mm
Energieffektivitetsklass (gammal):	A+
Ljudnivå (tvätt):	60 dB
Maximal centrifugeringshastighet:	1000 RPM
Cykeltid (max):	192 min
Antal tvättprogram:	16
Tvättprogram:	Hygiene/anti-allergy, Black
Nominell kapacitet:	- kg
Produktens färg:	Vit
Skärmtyp:	LED
Kontrolltyp:	Buttons, Rotary
Låddjup:	585 mm
Årlig vattenförbrukning tvätt:	9039 l
Apparatens placering:	Fristående
Gångjärnssida:	Vänster
Laddning:	Frontmatad
Drum volym:	52 l
Dörr färg:	Vit
Fördröjd start timer:	Ja
Centrifugering klass:	C
Ljudnivå (spinn):	74 dB
Fördröjd start:	24 h
Vattenförbrukning per omgång:	- l
Energiförbrukning vid tvätt:	1.26 kWh
Årlig energiförbrukning tvätt:	212 kWh
