Sida 1/40

FREEZER

Contents

Installation, 2

Positioning and connection

Reversible doors

Description of the appliance, 3

Overall view

Start-up and use, 4

Starting the appliance

Using the freezer to its full potential

Maintenance and care, 5

Switching the appliance off

Cleaning the appliance

Avoiding mould and unpleasant odours

Precautions and tips, 6

General safety

Disposal

Respecting and conserving the environment

Troubleshooting, 7

Assistance, 8

Operating Instructions

UFAN 400 NF

Français, 9English, 1

GB F

Espanol, 25

Nederlands, 17

Polski, 33

Installation

Reversible doors

! Before placing your new appliance into operation please

read these operating instructions carefully. They contain

important information for safe use, for installation and for

care of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to possible new owners of the

appliance.

Positioning and connection

Positioning

1. Place the appliance in a well-ventilated humidity-free

room.

2. Do not obstruct the rear fan grills. The compressor and

condenser give off heat and require good ventilation to

operate correctly and save energy.

3. Leave a space of at least 10 cm between the top part of

the appliance and any furniture above it, and at least 5

cm between the sides and any furniture/side walls.

4. Ensure the appliance is away from any sources of heat

(direct sunlight, electric stove, etc.).

5. In order to maintain the correct distance between the

appliance and the wall behind it, fit the spacers supplied

in the installation kit, following the instructions provided.

Levelling

1. Install the appliance on a level and rigid floor.

2. If the floor is not perfectly horizontal, adjust the

refrigerator by tightening or loosening the front feet.

Electrical connections

After the appliance has been transported, carefully place it

vertically and wait at least 3 hours before connecting it to

the electricity mains. Before inserting the plug into the

electrical socket ensure the following:

 The appliance is earthed and the plug is compliant with

the law.

 The socket can withstand the maximum power of the

appliance, which is indicated on the data plate located on

the bottom left side of the fridge (e.g. 150 W).

 The voltage must be in the range between the values

indicated on the data plate located on the bottom left

side (e.g. 220-240V).

 The socket is compatible with the plug of the appliance.

If the socket is incompatible with the plug, ask an

authorised technician to replace it (see Assistance). Do

not use extension cords or multiple sockets.

! Once the appliance has been installed, the power supply

cable and the electrical socket must be easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced by

authorised technicians only (see Assistance).

! The manufacturer declines any liability should these

safety measures not be observed.

Description of the

appliance

Overall view

The instructions contained in this manual are applicable to different model refrigerators. The diagrams may not

directly represent the appliance purchased. For more complex features, consult the following pages.

 Varies by number and/or position.

POWER

Indicator light

WARNING

Indicator light

SUPER FREEZE

Indicator light

TEMPERATURE

CONTROL Knob

Flap

FREEZING and

STORAGE

compartment

STORAGE

compartment

Levelling FEET

SUPER FREEZE

Button

Ice3 ice tray 
