Indesit WIXXL 146 (EU) Bruksanvisning

Indesit tvättmaskin WIXXL 146 (EU)

Läs nedan 📖 manual på svenska för Indesit WIXXL 146 (EU) (84 sidor) i kategorin tvättmaskin. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF

Sida 1/84

Instruction booklet

WASHING MACHINE

WIXXL 146

English

Contents

Installation, 2-3

Unpacking, 2

Remove the transit fixings, 2

Levelling, 2

Water connections, 2

Drainage and electrical connections, 3

Technical Details, 3

Washing machine description, 4-5

Control panel, 4

LEDs, 5

Starting and programmes, 6

Briefly: starting a programme, 6

Programme table, 6

Personalisations, 7

Setting the temperature, 7

Setting the spin speed, 7

Options, 7

Detergents and laundry, 8

Detergent dispenser, 8

Maximum load size, 8

Precautions and advice, 9

General safety, 9

Disposal, 9

Saving energy and respecting

the environment, 9

Care and Maintenance, 10

Switching off the water or electricity supply, 10

Cleaning, 10

Caring for your appliance door and drum, 10

Cleaning the pump, 10

Checking the water inlet hose, 10

Troubleshooting, 11

Service, 12

Before calling for assistance, 12

Keep this instruction manual in a safe place for future

reference. Should the appliance be sold, transferred or

moved, make sure the instruction manual

accompanies the washing machine to inform the new

owner as to its operation and features.

! Read these instructions carefully: they contain vital

information on installation, use and safety.

Unpacking

1. Unpack the machine.

2. Check whether the machine has been damaged

during transport. If this is the case, do not install it and

contact your retailer.

Remove the transit fixings

IMPORTANT: Follow these instructions to remove the

TWO transit fixings (see Description for location).

Situated on either side of the

rear panel, BOTH transit boltsBOTH transit boltsBOTH transit boltsBOTH transit boltsBOTH transit bolts

MUST be rMUST be r

MUST be rMUST be rMUST be removed beforemoved befor

emoved beforemoved beforemoved before usee use

e usee usee use.

! Failure to do so may cause

damage to your machine.

It is important the transit bolt

and spacer (see pic) come out

intact.

1. Unscrew the bolt using a

13mm spanner.

2. STOP when 3 threads can be

seen.

3. Hold, slide sideways and pull

to remove.

4. For safety, insert one of the

the plastic covers (supplied with

your machine) over the hole.

! Repeat steps 1 to 4 to remove

the second transit bolt.

! Packaging materials are not

children’s toys.

Levelling

Your machine will be noisy if the two front feet are not

adjusted so that the machine stands firm and level.

! The machine should be levelled from side to side and

from front to back.

1. Move your machine into its final location.

- Take care not to trap or kink

the hoses.

2. Turn one or both front feet

anti-clockwise by hand until the

feet cannot be turned any more.

When adjusting the feet, use a

spirit level to check the machine

stands level, from side to side

and from front to back.

- The spring on each foot will stop them coming loose.

! If it is placed on a fitted or loose carpet, adjust the

feet in such a way as to allow enough room for

ventilation beneath the machine.

Water connection

Connecting the water inlet hose.

Remember that this is a cold-fill machine.

! Check that seal is in place

inside the hose end cap.

Before making the water connections to gas ¾ thread,

allow the water to run freely from the supply tap until it

is perfectly clear.

Screw the inlet end with the blue

cap onto the cold water supply

tap.

Turn the taps on and check for leaks: tighten if

necessary.

! Make sure there are no kinks or bends in the hose.

! The water pressure at the tap must be within the

values indicated in the Technical details table (next

page).

! If the water inlet hose is not long enough, contact a

specialist store or an authorised serviceman.

! Always use new hoses.

! Check the water hose at least once a year, replace

any that are cracked as worn hoses could split under

water pressure.

Installation

Drainage connections

A. Connect the drain

hose, without kinking it,

to a draining duct or a

wall drain fixed at a

height between 65 and

100cm from the floor.

B. Alternatively, place it

over the edge of a basin,

sink or tub, fastening the

hose supplied to the tap.

The free end of the hose should not be under water.

! We advise against the use of hose extensions. In

case of absolute need, the extension must have the

same diameter as the original hose and must not

exceed 150cm in length.

Electrical connections

Before plugging the appliance into the mains socket,

make sure that:

• the socket is earthed and in compliance with the

applicable law.

• the socket is able to sustain the appliances

maximum power load indicated in the Technical

Details table (on the right).

• the supply voltage is included within the values

indicated in the Technical Details table (on the right).

• the socket is compatible with the washing machines

plug. If this is not the case, replace the socket or

the plug.

! The washing machine should not be installed in an

outdoor environment, not even when the area is

sheltered, because it may be very dangerous to leave

it exposed to rain and thunderstorms.

! When the washing machine is installed, the mains

socket must be within easy reach and should be

connected to a suitable electrical supply.

! Do not use extensions or multiple sockets.

! The power supply cable must never be bent or

dangerously compressed.

! The power supply cable must only be replaced by an

authorised serviceman.

! The company denies all liability if and when these

norms are not respected.

The first wash cycle

Once the appliance has been installed and before you

use it for the first time, run a wash cycle without

detergent and no laundry, setting the 90°C

programme without a pre-wash cycle.

TECHNICAL DETAILS

Model WIXXL 146

Dimensions

59.5 cm wide

85 cm high

52.5 cm deep

Capacity from 1 to 7 kg

Electric

connections

voltage 220 - 240 volts 50 Hz

absorbed power 1700 – 2100 W

Water

connection

maximum pressure 1 MPa (10 bar)

minimum pressure 0,05 MPa (0,5 bar)

drum capacity 53 litres

Spin speed up to 1400 rpm

Control

programmes

according to

the IEC456

directive

programme 2 with temperature set to

60°C run with a load of 7 kg.

This appliance is compliant with the

following European Community

directives:

- 73/23/CEE of 19/02/73 (Low Voltage)

and subsequent amendments

- 89/336/CEE of 03/05/89

(Electromagnetic Compatibility) and

subsequent amendments

Produktspecifikationer

Varumärke:	Indesit
Kategori:	tvättmaskin
Modell:	WIXXL 146 (EU)
