Sida 1/84

! This symbol reminds you to read this

instruction manual.

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 4

Cutting off the water or electricity supply

Cleaning the Washer-dryerCleaning the detergent dispen-

ser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 5

General safety

Load balancing system

Disposal

Description of the Washer-dryer and

starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Push&Wash+Dry

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the drying cycle

Wash options

Detergents and laundry, 10

Detergent dispenser drawer

Bleach cycle

Preparing the laundry

Garments requiring special care

Troubleshooting, 11

Service, 12

Instructions for use

Washer-dryer

XWDA 751680

English,1

Español,13

Български,37

Magyar,25

Українська,61

CIS

Русский,49

ҚАЗАҚША,73

Levelling the machine correctly will provide

it with stability, help to avoid vibrations and

excessive noise and prevent it from shifting

while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow

a sufficient ventilation space underneath the

Washer-dryer.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the inlet

hose by screwing it

to a cold water tap

using a 3/4 gas thre-

aded connection (see

figure).

Before performing the

connection, allow the

water to run freely un-

til it is perfectly clear.

2. Connect the inlet

hose to the Washer-

dryer by screwing it

onto the correspon-

ding water inlet of the

appliance, which is

situated on the top

right-hand side of the

rear part of the ap-

pliance (see figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the range of values indicated in the Technical

data table (see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Installation

! This instruction manual should be kept in a

safe place for future reference. If the Washer-

dryer is sold, transferred or moved, make sure

that the instruction manual remains with the

machine so that the new owner is able to fa-

miliarise himself/herself with its operation and

features.

! Read these instructions carefully: they con-

tain vital information relating to the safe instal-

lation and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the Washer-dryer from its packaging.

2. Make sure that the Washer-dryer has not

been damaged during the transportation

process. If it has been damaged, contact the

retailer and do not proceed any further with

the installation process.

3. Remove the 4 pro-

tective screws (used

during transportation)

and the rubber wa-

sher with the cor-

responding spacer,

located on the rear

part of the appliance

(see figure).

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the Washer-dryer needs to

be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the Washer-dryer on a flat sturdy flo-

or, without resting it up against walls, furniture

cabinets or anything else.

2. If the floor is not

perfectly level, com-

pensate for any une-

venness by tightening

or loosening the

adjustable front feet

(see figure); the angle

of inclination, measu-

red in relation to the

worktop, must not

exceed 2°.

Connecting the drain hose

Connect the drain

hose, without bending

it, to a drain duct or

a wall drain situated

between 65 and 100

cm from the floor;

alternatively, placed

it over the edge of a

basin, sink or tub, fa-

stening the duct sup-

plied to the tap (see

figure). The free end

of the hose should

not be underwater.

! We advise against the use of hose extensions;

if it is absolutely necessary, the extension must

have the same diameter as the original hose

and must not exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electri-

city socket, make sure that:

• thesocketisearthedandcomplieswithall

applicable laws;

• thesocketisabletowithstandthemaximum

power load of the appliance as indicated in the

Technical data table (see opposite);

• thepowersupplyvoltagefallswithintheva-

lues indicated in the Technical data table (see

opposite);

• thesocketiscompatiblewiththeplugofthe

Washer-dryer. If this is not the case, replace

the socket or the plug.

! The Washer-dryer must not be installed ou-

tdoors, even in covered areas. It is extremely

dangerous to leave the appliance exposed to

rain, storms and other weather conditions.

! When the Washer-dryer has been installed,

the electricity socket must remain within easy

reach.

! Do not use extension cords or multiple sockets.

! The cable should not be bent or compressed.

! The power supply cable must only be repla-

ced by authorised technicians.

65 - 100 cm

Warning! The company shall not be held re-

sponsible in the event that these standards are

not observed.

The first wash cycle

Once the appliance has been installed, and

before you use it for the first time, run a wash

cycle with detergent and no laundry, using the

wash cycle “Auto Clean” (see “Cleaning the

Washer-dryer”).

Technical data

Model

XWDA 751680

Dimensions

width 59.5 cm

height 85 cm

depth 54 cm

Capacity

from 1 to 7 kg for wash

programme

from 1 to 5 kg for the drying

programme

Electrical

connections

please refer to the technical

data plate fixed to the machine

Water con-

nections

maximum pressure

1 MPa (10 bar)

minimum pressure

0.05 MPa (0.5 bar)

drum capacity 58 litres

Spin speed

up to 1600 rotations per

minute

Energy ra-

ted

programmes

according to

regulation

EN 50229

wash: programme 8; tem-

perature 60°C; using a load

of 7 kg.

drying: the smaller load

(2kg) must be dried by se-

lecting the “ ” dryness le-

vel. The load must consist of

2 sheets, 1 pillowcase and 2

hand towels; the remainder

of the load must be dried by

selecting the “ ” dryness

level.

This appliance conforms to

the following EC Directives:

- EMC 2014/30/EU (Electro-

magnetic Compatibility)

- LVD 2014/35/EU (Low

Voltage)

- 2012/19/EU - (WEEE)

Produktspecifikationer

Varumärke:	Indesit
Kategori:	Torktumlare
Modell:	XWDA 751680X W EU
Inbyggd display:	Ja
Vikt:	66500 g
Bredd:	595 mm
Djup:	540 mm
Höjd:	850 mm
Antal torkprogram:	12
Förpackningens bredd:	645 mm
Energieffektivitetsklass (gammal):	A
Ljudnivå (tvätt):	54 dB
Maximal centrifugeringshastighet:	1600 RPM
Ljudnivå (torkning):	- dB
Antal tvättprogram:	16
Tvättprogram:	Hand/wool, Jeans/denim, Quick, Sport, Delicate/silk
Nominell kapacitet (tvätt):	7 kg
Torkprogram:	Wool, Sport, Quick, Delicate/silk, Jeans/denim
Produktens färg:	Vit
Skärmtyp:	LED
Kontrolltyp:	Buttons, Rotary
Låddjup:	590 mm
Årlig vattenförbrukning tvätt:	11800 l
Tvättklass:	A
Apparatens placering:	Fristående
Gångjärnssida:	Vänster
Laddning:	Frontmatad
Drum volym:	52 l
Fördröjd start timer:	Ja
Centrifugering klass:	A
Ljudnivå (spinn):	80 dB
Justerbar centrifugeringshastighet:	Ja
Energiförbrukning vid tvätt:	1.05 kWh
Årlig energiförbrukning tvätt:	210 kWh
Vattenförbrukning tvätt & torkning per cykel:	92 l
Energiförbrukning vid disk och torkning:	4.76 kWh
Vattenförbrukning per tvätt:	59 l
Tork-kapacitet:	5 kg
Årlig energiförbrukning tvätt & torkning:	952 kWh
Årlig vattenförbrukning tvätt & torkning:	18400 l
Cykeltidstvätt:	170 min
