The Innity Furion FX402 Bar is an IP65-rated LED batten with 10 high-power 60-watt RGBW LEDs in
10 tilt heads with zoom and 60 warm and cold white strobe pixel LEDs. It creates unique light effects,
igniting creative ideas for live events, TV shows, club and theatre settings, and more.
The RGBW LEDs can be individually controlled, as can the tilt and zoom of every head, offering exible
and smooth control over light effects and coverage. Each tilt head features 6 individually controllable
CW and 6 individually controllable WW strobe pixels, alternatingly positioned, adding intricate accents
to an already impressive light output. The heads can be tilted over 200 degrees, while the beam
angle can be adjusted between 2.7° and 31.4° for each head individually thanks to the high-precision
motorised zoom.
With Art-Net and sACN, it is easy to integrate the Furion FX402 Bar into any professional infrastructure.
In DMX mode, the xture can be controlled from 29 channels up to a cleverly congured advanced
mode with 255 channels, meaning that two xtures can be controlled from a single DMX universe in the
most advanced DMX mode. The Furion FX402 Bar can be controlled via DMX/RDM, manually, and has
an auto mode, giving you comprehensive options. The refresh rate (PWM) can be adjusted between
600 and 15,000 Hz to suit studio and TV applications, while the high-resolution dimming function offers
precise control over the amount of light output.
The FX402’s forged magnesium and aluminium body is strong and lightweight, ensuring durability and
minimal maintenance. Its IP65 rating provides protection against dust and water, making it suitable for
both indoor and outdoor use. Aligning multiple xtures has been made easy with extendable pins on
one side and matching holes on the other. The seamless edge-to-edge mounting keeps the tilt heads of
different xtures the same distance apart, creating homogeneous runway effects.
With the Furion FX402 Bar, lighting designers have access to an exquisite professional batten light
effect that combines power and creativity with smooth movements in a durable design.
41470 Innity Furion FX402 Bar
10 x 60 W RGBW LED FX Bar with strobe pixels - IP65
Specications:
- Source
Light Source Type
Light Source Quantity
Light Source Power
LED Colour Type
Refresh Rate
Refresh Rate (Max.)
Luminous Flux (Total)
CRI
CCT
- Optical
Beam Angle Minimum (Circular)
Beam Angle Maximum (Circular)
Cutoff angle minimum (Circular)
Cutoff angle maximum (Circular)
Field Angle Minimum (Circular)
Field Angle Maximum (Circular)
Zoom Type
Zoom Ratio
- Control and Programming
Control Mode
DMX Channels
Protocols
Display
Dim Curve
Zone Control (Sections)
Dimmer Resolution
Zoom Resolution
Dimmer
Strobe
- Movement
Pan
Tilt
Pan/Tilt Resolution
- Electrical Specications and Connections
Power Supply
LED
10
60 W
RGBW
600 Hz
15 kHz
8951 lm
83,7
7200 K
2,7 °
26,7 °
3,8 °
31,4 °
3,4 °
30,3 °
Motorised
1:10
Auto / DMX / Manual
29 / 56 / 144 / 255
Art-Net / DMX / RDM / sACN
TFT
Linear / Square / I-Square / S-Curve
10
16 bit
8 bit
0-100 %
0-20 Hz
0 °
200 °
16-bit
200-240 V AC 50/60 Hz
Special features:
- 10 x 60 W RGBW LED
- 60 CW and 60 WW strobe pixels
- 200-degree tilt
- Wide motorised zoom from 2.7° to 31.4°
- Edge-to-edge mounting and easy alignment
Specications:
Technical drawings:
Power Consumption
Fuse
Power Connector In
Power Connector Out
DMX Connector
DMX Connector In
DMX Connector Out
Data Connector
Data Connector In
Data Connector Out
- Mechanical Specications
Length (mm)
Width (mm)
Height (mm)
Weight
IP Rating
Housing
Colour
- Product Properties
Cooling
- Thermal Specications
Maximum Ambient Temperature
Minimum Operating Temperature
- Included Items
Included Cables
Included Rigging
800 W
15 A
Power Pro True
Power Pro True
XLR 5P In/Out
XLR 5P
XLR 5P
etherCON In/Out
RJ45
RJ45
1.000 mm
209 mm
322 mm
31 kg
IP65
Magnesium die-cast
Black
Convection
45 °C
-10 °C
Power Pro True Cable
Quick-Lock Bracket
999
322
138
Ø267
275
260 410 260
209
1000
216
206
