Manual

Power supply

Argus HA-600AA2

Art. 88882239

+49 511 72667830 - [email protected] - www.inter-tech.de

Inter-Tech Elektronik Handels GmbH

Hainhäuser Weg 93 - 30855 Langehagen - Germany

Warranty terms

Inter-Tech grants 24 months warranty by proper use up from the

date of purchase. In case of warranty please contact your local

dealer or the dealer from which you bought the product. Please look

also at our complete warranty terms on our website www.inter-

tech.de.

Contact

The power supply needs no maintenance which requires opening of

the housing or working inside the power supply.

Disposal

Maintenance

Please dispose this device by using the special discharge point for

electronic waste and ask your municipality or disposal company in

case of further questions. Please dispose the cardboard and plastics

by using the appropriate containers of the household garbage.

2. Connect all components with the suitable cables. Please follow

also the instructions of the device manufacturers. A faulty

connection of the components can cause damages. Please ask your

local dealer or our service-hotline in case of discrepancies or

questions.

1. Take out the power supply and check the package content for

completeness or damages. Please contact you local dealer for

replacement in case of missing or damaged parts. Please keep the

original package for shipping in case of warranty claim. Please

connect the power supply to the grid after connecting all other

devices. Fix the power supply with the enclosed screws to the

allocated space of the computer case.

5. Switch on the power supply at the backside of the power supply.

Your computer is ready now.

Package content

1x Power supply

1x power cord

2x manuals

3. Lay all cables in a way to avoid disturbing airflow or any rotating

fan.

4. Connect the power supply with the electric socket. Use only the

original power cord. In case of a damaged cable, please change it

against an approved power cord from your local dealer.

By power-on the power supply it is in Stand-By mode to start the

computer by pressing the power button at the case front. To

separate the computer totally from the electric grid power –off the

power supply directly or remove the power cord from the electric

grid.

Implementing

Technical data

Input:

Output:

Safety:

MTBF:

Environm.:

3.3V + 5V

+12V

Total

200 - 240V~, 50Hz, 8A

+3.3Vmax. 20A

+5Vmax. 20A

+12Vmax. 50A

-12Vmax. 0,3A

+5Vsbmax. 2.5A

max. 100W

max. 600W

max. 600W

OPP Over-Power-Protection

The Power supply will shut down if the output is more than

110% of the nominal output.

OCP Over-Current-Protection

The Power supply will shut down if the current of the output

lines will exceed the tolerance value.

OVP Over-Voltage-Protection

To prevent further damages the power supply will shut down

if a fault causes a higher output voltage.

SCP Short-Circuit-Protection

Power supply will shut down in case of a short circuit on

secondary output lines.

NLP No-Load-Protection

Power supply will shut down in case of no load on secondary

output lines to prevent damages.

100.000h at 25°C

Operating

Storage

Temperature

Humidity

Temperature

Humidity

0-40°C

Up to 85%, n. condens.

-20-90°C

Up to 95%, n. condens.

Don´t place the device close to source of heat .

Keep the product free of dust (Overheating or fire).

Please remove the power cord from socket in case of longer non-

use (Could led to overheating, fire hazard or electric strike).

Don´t pull the plug by pulling at the cable.

Don´t remove the cable with wet hands (electric strike).

Look for sufficient airflow and ventilation to avoid overheating or fire.

Leave service or cleaning only authorized and qualified personnel.

In case of strange noise or smell pull the power cord out of the

socket.

Danger and protection

Don´t open the housing of the device (fire hazzard/ electric strike).

Don´t use the product with wet hands (electric strike).

Don´t stick any items into the power supply (electric strike).

This product is only for indoor use as power supply for computers.

Don´t use or store this product close to water or in humid rooms.

Don´t use this product close to heat. The additional heat could

cause overheating or fire.

Don´t use any patched or damaged cable or plug.

Keep the product away from children.

Ensure that all cables are fixed permanently.

For your safety, please read this manual carefully before installation

or using. Keep this safety instructions and forward it when you

forward the power supply.

Intended use
