USER MANUAL
Advanced 2/4/8/16-Port DVI-I Secure KVM
SDVN-2S 2-Port Secure DVI-I KVM with Audio
SDVN-2D 2-Port Secure Dual-Head DVI-I KVM with Audio
SDVN-2S-P 2-Port Secure DVI-I KVM with Audio and CAC Support
SDVN-2D-P 2-Port Secure Dual-Head DVI-I KVM with Audio and CAC Support
SDVN-4S 4-Port Secure DVI-I KVM with Audio
SDVN-4D 4-Port Secure Dual-Head DVI-I KVM with Audio
SDVN-4S-P 4-Port Secure DVI-I KVM with Audio and CAC Support
SDVN-4D-P 4-Port Secure Dual-Head DVI-I KVM with Audio and CAC Support
SDVN-4Q-P 4-Port Secure Quad-Head DVI-I KVM with Audio and CAC Support
SDVN-8S 8-Port Secure DVI-I KVM with Audio
SDVN-8D 8-Port Secure Dual-Head DVI-I KVM with Audio
SDVN-8S-P 8-Port Secure DVI-I KVM with Audio and CAC Support
SDVN-8D-P 8-Port Secure Dual-Head DVI-I KVM with Audio and CAC Support
SDVN-16S 16-Port Secure DVI-I KVM with Audio
SDVN-16S-P 16-Port Secure DVI-I KVM with Audio and CAC Supporth
Release Date: July 3rd, 2018
TABLE OF CONTENTS
3
4
4
4
5
11
11
12
12
12
13
13
13
14
TECHNICAL SPECIFICATIONS___________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________
SECURITY FEATURES_________________________________________________________________
SDVN FRONT AND REAR______________________________________________________________
INSTALLATION_______________________________________________________________________
CAC INSTALLATION: COMMON ACCESS CARD, SMART CARD READER__________________________
CAC PORT CONFIGURATION____________________________________________________________
AUDITING: Dumping the Event Log via User Menu Options___________________________________
RESET: Restore Factory Default_________________________________________________________
LED’s BEHAVIOR_____________________________________________________________________
SYSTEM OPERATION__________________________________________________________________
TROUBLESHOOTING__________________________________________________________________
TECHNICAL SUPPORT_________________________________________________________________
LIMITED WARRANTY STATEMENT_______________________________________________________
2Advanced 2/4/8/16 DVI-I Secure KVM Switch
TECHNICAL SPECIFICATIONS
3
VIDEO
Format DVI-I Dual Link
Host Interface
SDVN-2S/SDVN-2S-P (2) DVI-I 29-pin (female)
SDVN-2D/SDVN-2D-P/ SDVN-4S/
SDVN-4S-P
(4) DVI-I 29-pin (female)/DVI-D
SDVN-4D/SDVN-4D-P/SDVN-8S/
SDVN-8S-P
(8) DVI-I 29-pin (female)/DVI-D
SDVN-4Q-P/SDVN-8D/SDVN-8D-P/
SDVN-16S/SDVN-16S-P
(16) DVI-I 29-pin (female)
User Console
Interface
SDVN-2S/SDVN-2S-P/SDVN-4S/
SDVN-4S-P/SDVN-8S/
SDVN-8S-P/SDVN-16S/
SDVN-16S-P
(1) DVI-I 29-pin (female)
SDVN-2D/SDVN-2D-P/SDVN-4D/
SDVN-4D-P/SDVN-8D/SDVN-8D-S
(2) DVI-I 29-pin (female)/DVI-D
SDVN-4Q-P (4) DVI-I 29-pin (female)/DVI-D
Max Resolution 2560 x 1600 @ 60Hz; 3840x2160 @ 30Hz
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
USB
Signal Type USB 1.1 and 1.0 Keyboard and Mouse only. USB 2.0 for CAC connection.
Host Interface
SDVN-2S/SDVN-2D (2)
SDVN-2S-P/SDVN-2D-P/SDVN-4S/SDVN-4D (4)
SDVN-4S-P/SDVN-4D-P/SDVN-4Q-P/SDVN-8S (8)
SDVN-8S-P/SDVN-16S (16)
SDVN-16S-P (32)
User Console Interface
(2) USB Type-A for keyboard and mouse connection only
(1) USB Type-A for CAC connection (P models only)
AUDIO
Input (2/4/8/16) Connector Stereo 3.5mm Female
Output (1) Connector Stereo 3.5mm Female
POWER
Power Requirements
12V DC, 2A (minimum) power adapter with center-pin positive polarity. Quad head models require a 12V
DC 3A (minimum) power adapter with center-pin positive polarity.
ENVIRONMENT
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
CERTIFICATIONS
Security Accreditation &RPPRQ&ULWHULD9DOLGDWHG7R1,$33URWHFWLRQ3URÀOH3669HU
OTHER
Emulation USB 1.1 and USB 2.0 Compatible
Control Front Panel Buttons
Advanced 2/4/8/16 DVI-I Secure KVM Switch
Produktspecifikationer
| Varumärke: | IPGARD |
| Kategori: | Inte kategoriserad |
| Modell: | SDVN-4S |
