Sida 1/64

Version 15 20180507

https://www.realwear.com/support

support@realwear.com

Safety Instructions HMT-1Z1 model T1100S

1 Note

This document contains the safety instructions

necessary for the safe use of the HMT-1Z1 model

T1100S device in explosive and potentially explosive

atmospheres. Such areas or zones are referred to as

“ex-hazardous areas” in this document.

2 Introduction

This document contains information and safety

regulations which are to be observed – without fail -

for safe operation of the device under the described

conditions. Non-observance of this information and

instructions can have serious consequences and / or

may violate regulations. Please read the manual and

these safety instructions before using the device. In

case of any translation or printing errors, the English

version shall apply.

3 Application

3.1 ATEX & IECEx

The HMT-1Z1 model T1100S is approved for use in

zone 1, zone 2, zone 21 and zone 22 in accordance

with directives 2014/34/EU (ATEX) and the IECEx

System.

3.2 NEC & CEC

The HMT-1Z1 model T1100S is approved for use in

Division 1 and 2 Class I, II, III.

3.3 Manufacturer

i.safe MOBILE GmbH,

i_Park Tauberfranken 10

97922 Lauda-Koenigshofen; Germany

4 Faults and Damage

Before entering ex-hazardous areas, the safety of the

device must be checked. If there is any reason to sus-

pect that the safety of the device has been compro-

mised, it must be withdrawn from use and removed

from any ex-hazardous areas immediately.

Measures must be taken to prevent any accidental

restarting of the device. The safety of the device may

be compromised, if, for example:

• Malfunctions occur.

• The housing of the device shows damage.

• The device has been exposed to excessive loads.

• The device has been stored improperly.

• Markings or labels on the device are illegible.

• Permitted limit values have been exceeded.

It is recommended that a device displaying errors or

for which an error is suspected be sent back to an

authorized service center to be checked.

5 Ex-relevant / Intrinsic Safety Regulations

Use of this device assumes that the operator ob-

serves the conventional safety regulations and has

read and understood the user manual, safety instruc-

tions and safety certicate. The following additional

safety regulations must be complied with:

5.1 Charging and battery

• The device may only be charged outside

ex-hazardous areas using the i.safe PROTECTOR

1.0 USB-cable (or other equipment approved by

i.safe MOBILE GmbH.)

• The device may only be charged at temperatures

between +5°C and +40°C.

• The battery is not removable by the user.

5.2 Connections and covers

• Physical connections to other equipment are only

permitted outside ex-hazardous areas, using the

i.safe PROTECTOR 1.0 USB-cable (or other

equipment approved by i.safe MOBILE GmbH.)

• Inside ex-hazardous areas the covers of the Micro

USB connector and the Micro SD card slot must be

kept closed.

• The audio jack can be used to connect approved

headsets inside ex-hazardous areas.

• To ensure the integrity of ingress protection (IP),

check that all gaskets are present and functional.

• During charging any headset or accessory must be

unplugged from the audio jack.

5.3 Usage environments

• The device may not be taken into zones 0 or 20.

• The device may not be exposed to any aggressive

acids or alkalis.

• The device must be protected from impacts

with high impact energy, against excessive UV

emission and high electrostatic

charge processes.

• The permitted ambient operating temperature

range is -20°C to +60°C.

5.3 Accessories

• Only accessories approved by i.safe MOBILE

GmbH may be used.

• Adjustment of the head strap in ex-hazardous

areas is not permitted.
