USER GUIDE

P30

DUAL CHANNEL

SMART CHARGER

Never use the charger without supervision, please stop using the charger and refer to the manual for reasons

if any functional abnormity.

Keep the charger away from dust, humidity, rain and high temperature, as well as avoid direct exposure to the

sunlight and intense vibration.

Place the charger on a heat-resisting, non-ﬂammable and insulating surface.

Do not use it on the car’s seats, carpet or other similar places.

Keep inﬂammable and explosive objects away from operation areas of the charger.

Read the instruction manual carefully to be familiar with the features of the charger,

and set proper charging parameters before operating. Setting the parameters incorrectly will

result in damage to the product, personal property and cause serious injury as well.

Warnings and Safety Tips

•

For your safety and a better user experience,

please read this manual and follow the instruction before using the new charger.

Please visit: www.isdt.co for more details on the functions of this smart charger,

as well as purchase various accessories. Functions of products will be kept on upgrading,

the manual in your hand may be diﬀerent from the actual operation, please refer to the actual functions.

Thanks for purchasing the ISDT P30 Smart Charger.

Model No: P30

Input voltage: DC 10~34V

Output voltage: DC 1~34V

Max. input current: 60A

Charging current: 0.2~30A ×2

Discharging current: 0.2~3.0A ×2

Balance current: 1.5A/Cell Max

Max. discharging power: 30W ×2

Max. charging power: Single channel Max. 1000W ; Whole model Max. 1500W

Supported battery types and cell count: LiFe,LiIon,LiPo 1-8S ; LiHv 1-7S ; Pb 1-12S ; NiMH/Cd 1-16S

Speciﬁcations

Working temperature: 0~40℃

Storage temperature: -20~60℃

Abnormal voltage alarm: Support

Incorrect cell count setting alarm: Support

Dimension: 110×110×65mm

Weight: 730g

Port / Key

Power

Input

Display

Screen

CH2

Touch Key

CH1

Touch Key

Type-C

Upgrading Port

CH1

Power Output

CH2

Power Output

CH1

Balance Port

CH2

Balance Port

Fan

Vent

USB

Connection

Key operation instructions (under standby interface)

CH1 Middle Key：Short press to enter CH1 detail page, Long press to enter CH1 task setting menu.

CH2 Middle Key：Short press to enter CH2 detail page, Long press to enter CH2 task setting menu.

Press and Hold the CH1 ad CH2 Middle Key to enter advanced settings menu.

Produktspecifikationer

Varumärke:	ISDT
Kategori:	Batteriladdare
Modell:	P30
Inbyggd display:	Ja
Bredd:	110 mm
Djup:	110 mm
Höjd:	65 mm
Skärm diagonal:	3.5 "
Upplösning:	320 x 480 pixlar
Uteffekt:	30 A
Spänning:	10-34 V
Antal batterier:	2
Produktens färg:	Svart
Skärmtyp:	IPS
Antal per förpackning:	- styck
Strömförbrukning (vanlig):	1500 W
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Utgångsspänning:	1-34 V
Material, hölje:	Gjuten aluminium
Strömkälla av typen:	DC
Ingående ström:	60 A
Kompatibelt batteri teknik:	Lithium Iron Phosphate (LiFePo4), Lithium Polymer (LiPo), Lithium-Ion (Li-Ion), Nickel-Metal Hydride (NiMH)
