INSTALLATION INSTRUCTIONS
EVO3 AQUARIUS
DO NOT expose this product to dripping or splashing and no objects filled with liquids, such as vases, shall be
placed near the apparatus. If liquid enters the chassis immediately unplug from the wall socket.
DO NOT impede ventilation by covering the ventilation openings with items, such as newspapers,
table-cloths, curtains, etc.;
DO NOT expose this product to naked flame sources, such as lighted candles,
these should not be placed near the apparatus;
MAKE SURE that this appliance (CLASS 1) is connected to a mains outlet socket with protective earth.
PLEASE NOTE that the mains plug is used as the disconnect device and must remain readily operable.
The two output sockets marked ‘A’ are designed for use with power amplifiers, sub-woofers or active loudspeaker systems.
These sockets are protected by a 16A circuit breaker which can be located under the chassis.
The four output sockets marked ‘B’ are designed for use with CD players, pre amplifiers, music servers, digital to analogue
converters, loads of typically no greater than 200W. These sockets are fused with a 5A fuse (T5AH250) which can be located
under the chassis.
The rated maximum total load for all six sockets together (A + B) is 16A 3680W.
Should the unit fail, or cease to function, or function in a manner which seems unusual, please immediately turn off
and unplug from the mains supply.
Send an email to: support@isoteksystems.com
SAFETY FIRST
PLEASE READ THE FOLLOWING INSTRUCTIONS BEFORE INSTALLATION
OUTPUT SOCKETS
ADDITIONAL INFORMATION ON FUSING AND RATINGS
SERVICE & REPAIR
NO USER SERVICEABLE PARTS INSIDE
A
B
©2016 Audio Power Systems GmbH
A
B
Max Total for all six sockets 16A 3680Watts
16A Max Total
16A
INSTALLATION INSTRUCTIONS
EVO3 AQUARIUS
A = MIN 3cm
3680w
INPUT
SUB WOOFER
NAZ
1150w
MAX
9kg EVO3 Premier 1.5m
315mm
445mm
110mm
PLUG IN
BRANCHEMENT SECTEUR / EINSTECKEN / CONECTAR / / ПОДКЛЮЧЕНИЕ К СЕТИ
2
UNPACK
DEBALLAGE / AUFPACKEN / DESEMBALAR / / РАСПАКОВКА
1
3
PLACEMENT
PLACEMENT / POSITIONIEREN / UBICACIÓN / / УСТАНОВКА
A = MIN 3cm
B = MIN 3cm
INPUT
SUB WOOFER
NAZ
MAX
9kg EVO3 Premier 1.5m
315mm
445mm
110mm
A = MIN 3cm
B = MIN 3cm
3680w
INPUT
SUB WOOFER
NAZ
1150w
MAX
9kg EVO3 Premier 1.5m
315mm
445mm
110mm
4
© 2016 Audio Power Systems GmbH. All rights reserved.
Information contained in this manual is correct at the time of print, however small product improvements may take place from time to time.
TURN ON
MISE EN ROUTE / ANSCHALTEN / ENCENDER / / ВКЛЮЧЕНИЕ
5
UPGRADE
MISE A JOUR / UPGRADE / ACTUALIZAR / / ОБНОВЛЕНИЕ
DISPLAY OFFVOLTAGE %THD
ON
EVO3 OPTIMUM
EVO3 PREMIER
EVO3 SYNCRO
EVO3 OPTIMUM EVO3 ELITE
16A
EVO3 TITAN
4600w
SUB WOOFERPOWER AMP
MONO AMPMONO AMP
DISPLAY OFFVOLTAGE %THD
EVO3 OPTIMUM
EVO3 PREMIER
EVO3 SYNCRO
EVO3 OPTIMUM EVO3 ELITE
EVO3 TITAN
EVO3 AQUARIUSEVO3 SYNCRO EVO3 TITAN OPTIMUM LINK
3680W
SUB WOOFERPOWER AMP
MONO AMPMONO AMP
6
REGISTER: EXTEND YOUR WARRANTY FOR FREE
PROLONGEZ LA GARANTIE GRATUITEMENT
KOSTENLOSE GARANTIEVERLAENGERUNG UNTER
REGISTRO: PROLONGUE LA GARANTÍA GRATIS
РЕГИСТРАЦИЯ:РАСШИРЯЕТБЕСПЛАТНУЮГАРАНТИЮ
WWW.ISOTEKSYSTEMS.COM/REGISTER
@IsoTekSystems isoteksystems.com/IsoTekSystems/IsoTekSystems
EVO3 Premier 1.5m
EVO3 Premier 1.5m
