BPU-350SATA 3.5”Hard Drive Cage

User’s Manual

Specification:

Order Information:

Hot Swap

5x3.5”HDD

Cooling Fan

1x80mm

Standard Drive Bays

5.25” Drive: 3

Dimension (W x H x D)

5.75 x 4.96 x 8.11 inches

Material

Aluminum Design with Conductive Dissipation

Grooves

HDD Interface

SATA / SAS

Weight

4bs

Cable

SATA Cable Included (5pcs)

Model Number:

Color:

UPC Code:

BPU-350SATA-BLACK

BPU-350SATA-RED

BPU-350SATA-BLUE

BPU-350SATA-SILVER

BPU-350SATA-BPL

(lockable handle)

Black

Red

Blue

Silver

Plastic

846813022606

846813000604

846813000598

846813000611

846813016087

Introduction:

Create more space for hard drive with hot-swap capability, by using the BPU-

350SATA HDD cage series that supports RAID 1/0/1+0/5 configuration for high

performing data recovery or redundancy application. Its aluminum construction

translates into lighter system weight and better heat dissipation. The 80mm fan

also help keeps hard drives at maximum performance temperature.

Features:



Aluminum Frame, Aluminum cover



Interface: Support SAS-I and SAS-II, SATA-I, SATA-II, SATA-III



High performance transfer rate: up to 6.0 GB/s for SAS & SATA hard drives



Plug & play, hot swappable



SATA 15Pin & 4Pin Power connectors



LED for P/S, HDD access, Fan sensor & Buzzer



Power Control Switch



3-stage temperature alarm settings & reset switch for buzzer alarm



8cm cooling fan X1



Dim: 8.11(L) X 5.75(W) X 4.96(H) inch



Patent products with advanced structure design



Patent balance handle-No skew in/out problem & avoid the abrasion during

connection



Precisely connection on connector

Hardware Information: Front View

D-1 ~ D-5: Power Switch & HDD LED. Power On: LED indicates Blue. Purple color blinking

for HDD access.

D-6: Reset Switch & Overheat LED. Power On: LED indicates Blue. Overheat (default 55º

C): LED indicate Red and buzzer alarms. Press the Reset Switch (D-6) to stop the alarm

for 3 minutes.

D-7: Fan senor LED. Fan On: LED indicates Blue. Fan Off: LED indicates Red and buzzer

alarms. Press the Reset Switch (D-6) to stop the alarm.

(If you want to switch off the “Alarm function”, press the Reset Switch (D-6) for more

than 6 seconds until 3 beeps comes out, then the “Alarm function” stopped.)

BPU-350SATA

iStarUSA – Powered by iStarUSA Group

727 Phillips Drive

City of Industry, CA 91748

Tel: (888) 989-1189

Email: sales@istarusa.com

BPU-350SATA

Produktspecifikationer

Varumärke:	IStarUSA
Kategori:	Diskarray
Modell:	BPU-350SATA-KL
Bredd:	146 mm
Djup:	209.5 mm
Höjd:	126 mm
Lagringsenheter installerade:	Nej
Total installerad lagringskapacitet:	- TB
Antal lagringsenheter som stöds:	5
Typer av lagringsenheter som stöds:	HDD & SSD
Värdportar:	5
Dataöverföringshastighet:	6 Gbit/s
SATA-värdport:	Ja
Produktens färg:	Svart
Hållbarhetscertifiering:	RoHS
Kabel inkluderad:	SATA
Typ av installerad lagringsenhet:	Nej
RAID-nivåer:	JBOD
Intern:	Ja
Antal fläktar:	1 fläkt/-ar
Lagringsenhetens gränssnitt:	Serial ATA, Serial ATA II, Serial ATA III
Högsta lagringskapacitet:	- TB
Hårddiskplatser med hotswap-funktion:	Ja
Chassityp:	Skrivbord
Lagringsenhetens storlek:	2.5/3.5 "
