JBL® Studio 260P
12" Powered Subwoofer
Bass that rises to any occasion
No self-respecting 9-piece series of loudspeakers would call itself unrivaled without packing unbeat-
able bass. With the SUB 260P powered subwoofer as part of our new JBL
® Studio 2 Series, it’s time
we called it a day and claimed victory. Alongside its dynamic cousin, the 10" SUB 250P, the SUB260P
is engineered to add faultless, deep-penetrating bass into whatever music, movie, portable device, or
game console you’re listening to at any given moment.
With its 12" PolyPlas low-frequency transducer, its 300-watt Class D high-efficiency built-in amplifier,
and its rear-firing Slipstream bass port that provides unyielding clarity, all that’s left for you to do is
kick back, relax, and enjoy the final word in acoustics. Combine this with the SUB 260P’s sleek,
clean design and you’ll be the first to admit - we’ve created a powered subwoofer that defines – and
commands – its era.
12" PolyPlas low-frequency transducer for tight, extended bass
response
300-watt Class-D high-efficiency amplifier features unobtrusive
rear-mounted inputs and controls for easy set-up and system
integration
Internal edge-to-edge bracing reduces cabinet wall flexing, there-
by significantly improving bass response and lowering distortion
Solid cabinet construction with soft-rounded edges and no visible
fasteners
Gloss black top panel adds a touch of elegance to the sleek
cabinet design
Soft-touch paint covers driver trim ring for a clean, timeless look
Rear-firing Slipstream bass port eliminates bass turbulence and
audible distortion
JBL® Studio 260P
12" Powered Subwoofer
Features
12" PolyPlas low-frequency transducer for tight, extended bass response
Envision flawless JBL sound seducing your ears – bass so tight that every note is held to its
proper duration, and with all the right harmonic overtones. Picture this, and then listen to the Studio
SUB 260P’s 12" PolyPlas transducer. Hear any difference between your imagination and reality?
We didn’t think so.
300-watt Class-D high-efficiency amplifier features unobtrusive rear-mounted
inputs and controls for easy set-up and system integration
Not only is the SUB 260P’s 300-watt amplifier a powerhouse in the realm of home entertainment, but
it’s also one of the smartest. Its Class-D energy rating allows the amplifier to cool itself naturally –
saving it from danger of burnout – and saving you from a higher electric bill. Its rear-mounted inputs
and controls allow for discrete, easy set-up and integration with other loudspeakers in the Studio 2
Series.
Sophisticated, 21st century visual design features that can’t fail to seduce
The JBL way is to make it look as good as it sounds. And with our Studio SUB 260P, we’ve made
no exception. With its 21st century elegance – including a solid cabinet construction with no visible
fasteners, softly rounded edges, a gloss black top panel, and a customized soft-touch paint scheme–
we’ve built something that seduces your eye as much as your ear.
What’s in the box:
JBL® Studio 2 Series 12" Powered Subwoofer
Owner’s Manual
LFE Cable x 1
Carpet Spikes x 4
Product specifications:
Type: Studio 2 Series 12" Powered Subwoofer
12" (300mm) PolyPlas low-frequency transducer
Braced enclosure with Slipstream rear-firing bass port
Frequency response: 29Hz – 150Hz
300W RMS built-in amplifier
600W peak dynamic power
Line-level and LFE inputs
Continuously adjustable low-pass crossover frequency
control (50Hz – 150Hz; 24dB/octave)
Phase switch, level control, bass boost and signal-sensing
auto power
Dimensions (H x W x D): 445mm x 381mm x 435mm
(17-1/2" x 15" x 17-1/8")
Weight: 17.2 kg (38 lb)
HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.jbl.com
© 2013 HARMAN International Industries, Incorporated. All rights reserved.
JBL is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or
other countries. The “Hear the truth” logo is a trademark of HARMAN International Industries, Incorporated.
Features, specifications and appearance are subject to change without notice.
