1
undEr countEr
refrIgEratiOn drawErs
DETAILED PLANNING DIMENSIONS GUIDE
JUCFP242HL, JUCFP242HM, JUCFP242HX, JUDFP242HL, JUDFP242HM, JUDFP242HX
23⁄" (W) x 34⁄" (H) x 23⁄" (Depth without door panels/handles)
Because Whirlpool Corporation policy includes a continuous
commitment to improve our products, we reserve the right to
change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details,
see Installation Instructions packed with product. Specifications
subject to change without notice.
Choose one of following configuration to match your kitchen design.
Double Drawer Refrigerator/Freezer Double-Refrigerator Drawers
Base Unit
(Panel Ready)
RISE™ Model NOIR™ Model
Base Unit
(Panel Ready)
RISE™ Model NOIR™ Model
JUCFP242HX JUCFP242HL JUCFP242HM JUDFP242HX JUDFP242HL JUDFP242HM
OPTIONAL ACCESSORIES FOR CUSTOM OVERLAY DESIGNS
RISE™ STAINLESS HANDLE KIT
W11231237
For use with Custom Overlay panels
Quantity - One handle per kit
(2 kits are required for one product)
NOIR™ STAINLESS HANDLE KIT
W11231236
For use with Custom Overlay panels
Quantity - One handle per kit
(2 kits are required for one product)
W11356577B
2
undEr countEr
refrIgEratiOn drawErs
DETAILED PLANNING DIMENSIONS GUIDE
JUCFP242HL, JUCFP242HM, JUCFP242HX, JUDFP242HL, JUDFP242HM, JUDFP242HX
23⁄" (W) x 34⁄" (H) x 23⁄" (Depth without door panels/handles)
Because Whirlpool Corporation policy includes a continuous
commitment to improve our products, we reserve the right to
change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details,
see Installation Instructions packed with product. Specifications
subject to change without notice.
PRODUCT DIMENSIONS
RISE™/NOIR™/Panel Ready (FRONT VIEW) RISE™/NOIR™/Panel Ready (SIDE VIEW)
RISE™/NOIR™ (TOP VIEW) Panel Ready (TOP VIEW)
*Add 3/4" (1.9 cm) to the height dimension when leveling legs are fully extended.
**For custom panel models, this will vary.
1/4"
(6 mm)
15"
(380 mm)
15"
(380 mm)
30¼"
mm)(760
34⅛"
(868 mm)
*
23⅞"
(606 mm)
23⅞"
(606 mm)
26⁄"
(676 mm)**
21⅝"
(550 mm)
23⁄"
(603 mm)
23⁄"
mm)
(588.2
21⅝"
mm)(550
41⁄" (1055 mm)**
4" (102 mm)*
34⁄" (868 mm)*
20⁄"
(527 mm)*
44⁄" (1125 mm)
