W10779525B
SIDE BY SIDE BUILT-IN REFRIGERATOR
’ ’
RÉFRIGÉRATEUR ENCASTRÉ CÔTE À CÔTE
INTRODUCTION | 3
INTRODUCTION
INTRODUCTION
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To ce e injur wheredu th risk sho or of ck, y n using yo orur frig atre er , foll these c ow basi precautions:
■To avoid a hazard due to instability of the
with the instructions.
■Installation shall be performed only by
manufacturer, or an authorized agent.
■Plug ed tlet.into a ground 3 prong ou
■Do not remove gr ong.ound pr
■Do not use an adapter.
■Do not use an extensi coon rd.
■Disconnect power to all units before servicing.
■If the SUPPLY CORD is damaged, it must be
replaced by the manufacturer, its service agent
a hazard.
■Replace all nels parts and pa before opera .ting
■This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
■Children should be supervised to ensure that they do
not play with the appliance.
■This refrigerator is intended to be used in household
and similar applications such as:
working environments
– farm houses and by clients in hotels, motels,
and other residential type environments
– bed and breakfast type environments
– catering and similar non-retail applications
■Remove doors from or eratyour old refrig .
■Connect to a otable water supply onlyp .
■Use
■Ke mmable materia ls and vapors, such
as line ay fr igeratgaso , aw om refr or.
■Do not store explosive substances such as
this refrigerator.
■Use two or more people to mo ve and install
refrigerator.
■Dis neccon t power before installing ice maker
(on ice maker kit ready models only).
■Use a sturdy glass wh en dispensing ice
(on some models).
■Do not hit the refrigerator glass doors
(on some models).
SAFETY
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
DANGER
WARNING
You can be killed or seriously injured if you don't follow instructions.immediately
You can be killed or seriously injured if you don't follow instructions.
4 | INTRODUCTION
INTRODUCTION
PROPER DISPOSAL OF YOUR OLD
REFRIGERATOR
IMPORTANT: Child entrapment and suffocation
are not problems of the past. Junked or
abandoned refrigerators are still dangerous –
even if they will sit for “just a few days.” If you
are getting rid of your old refrigerator, please
follow these instructions to help prevent
accidents.
Before You Throw Away Your Old Refrigerator
or Freezer:
■Take off the doors.
■Leave the shelves in place so that children
may not easily climb inside.
WARNING
Suffocation Hazard
Remove doors from your old refrigerator.
Failure to do so can result in death or brain damage.
Important information to know about disposal of
refrigerants:
Dispose of refrigerator in accordance with Federal and Local
regulations Refrigerants must be acuated a licensed, . ev by
EPA certified refrigerant technician in accordance with
established procedures.
INTRODUCTION TABLE OF CONTENTS
INTRODUCTION
Safety 3 .............................................................................
Proper Disposal Of Your
Old Refrigerator 4 ......................................................
Registering Your Appliance 5 ............................
Product Identification 5 ........................................
Product Features 6 ....................................................
Using The Controls 8 ................................................
GETTING STARTED
Remove The Packaging 12 .....................................
Clean Before Using 12 ...............................................
Water Supply Requirements 12 ..........................
Reverse Osmosis Water Supply.................... 12
Water System Preparation 13 ..............................
Install Produce Preserver 14(On Some Models) ...
Refrigerator Use 15 ......................................................
Power On/Off Switch 15 ...........................................
Water and Ice Dispensers
(on some models) ..............................................................16
CARE AND CLEANING
Ice Maker and Storage Bin
(on some models - Accessory) ..................................20
Clean the Ice Storage Bin 21 .................................
Water Filtration System 21 .....................................
Refrigerator Shelves 22 .............................................
Temperature Controlled Deli Drawer 22 .......
Crisper and Covers 23 ................................................
Wine Rack 23 ...................................................................
Freezer Shelf 23 ..............................................................
Freezer Basket .......................................................... 24
Door Bins ..................................................................... 24
Cleaning 25 .......................................................................
Lights 25 ..............................................................................
Power Interruptions ............................................. 26
Vacation Care ............................................................ 26
TROUBLESHOOTING
Refrigerator Operation 28 .......................................
Temperature And Moisture 29 .............................
Ice And Water 29 ...........................................................
ASSISTANCE
To Order Accessories ............................................ 32
Performance Data Sheet 34 ..................................
Warranty 38 .......................................................................
REGISTERING YOUR APPLIANCE
Gain access to our concierge-level Customer
Support by registering your appliance.
We make product registration simple and
straightforward so you can start using your
exclusive JennAir benefits today.
Registering your appliance allows you to:
■ Streamline your warranty service
If we have your appliance information, we
can help you faster.
■ Protect your purchase
In case of an insurance loss—such as fire,
flood, or theft—your product registration
could serve as a proof of purchase.
■ Keep your family safe
We’ll notify you in the rare case of a safety
notification.
Start taking advantage of these benefits today
by going online to register your appliance at
jennair.com/customer-care.
PRODUCT IDENTIFICATION
Your product identification, which includes
the model and serial numbers, is listed on the
product rating plate.
Recording this information below allows us to
assist you more easily if your appliance should
ever require service from one of our JennAir
Authorized Service Providers.
Model Number: --------------------------------
Serial Number: --------------------------------
Date of Installation: ----------------------------
Authorized Dealer: -----------------------------
Authorized Dealer Phone #:--------------------
1.
2.
3.
4.
5.
6.
7.
8.
PRODUCT FEATURES
1. Fully Integrated and Flush
Design with Articulating Hinge
Creates an integrated appearance with
custom cabinetry without exposed hinges
or trim pieces.
2. Adjustable Door Bins with Metal
Accents
Refrigerator and freezer door bins can be
positioned to accommodate a variety of
container sizes.
3. Adjustable Elegance Shelving
Glass shelves, accented with brushed
aluminum, make foods and beverages
appear to float, allowing more light to fill
the interior.
4. Obsidian Interior
Satisfies consumer’s desire to make a
design statement with an exclusive color
among luxury refrigerators on the market.
5. Multi-Point LED Theater
Lighting
Minimizes shadows and evenly distributes
light throughout the refrigerator, crisper
and freezer.
6. 90°/110° Door Stop Lighting
Position
Limits the opening angle of a refrigerator to
either 90° or 110°.
7. Soft, Auto-Close Crisper Drawers
Provide smooth operation by rolling open
even when fully loaded, and feature an
innovative auto-close design that pulls the
drawer closed.
INTRODUCTION
INTRODUCTION | 11
INTRODUCTION
INTRODUCTION
12 | GETTING STARTED
GETTING STARTED
REMOVE THE PACKAGING
NOTE:
Remove tape and glue residue
from surfaces before turning on the
refrigerator. Rub a small amount of
liquid dish soap over the adhesive with
your fingers. Wipe with warm water
and dry.
Do not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue. These
products can damage the surface of
your refrigerator. For more information,
see “Refrigerator Safety.”
Dispose of/recycle all packaging
materials.
CLEAN BEFORE USING
After you remove all of the packaging materials,
clean the inside of your refrigerator before
using it. See the cleaning instructions in
“Refrigerator Care.”
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers
are heavy. Use both hands when removing them to avoid
dropping.
WATER SUPPLY REQUIREMENTS
Read all directions before you begin.
IMPORTANT:
■When your refrigerator was installed,
the water connection from the water
source should have been connected
to your refrigerator. If your refrigerator
is not connected to a water source,
see “Connect to Water Line” in the
Installation Instructions. If you have any
questions about your water connection,
see “Troubleshooting” or call a licensed,
qualified plumber.
■If you turn the refrigerator on before the
water line is connected, turn the ice maker
Off. See “Ice Maker and Storage Bin.”
■All installations must meet local plumbing
code requirements.
■Connect to potable water supply only.
WATER PRESSURE
A cold water supply with water pressure
between 30 and 120 psi (207 and 827 kPa) is
required to operate the water dispenser and
ice maker. If you have questions about your
water pressure, see “Troubleshooting” or call a
licensed, qualified plumber.
NOTE: If the water pressure is less than what
is required, the flow of water from the water
dispenser could decrease or ice cubes could
be hollow or irregular shaped. If you have
questions about your water pressure, call a
licensed, qualified plumber.
Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system. Systems certified for cyst reduction
may be used on disinfected waters that may contain
filterable cysts.
REVERSE OSMOSIS WATER SUPPLY
IMPORTANT: The pressure of the water supply
coming out of a reverse osmosis system going
to the water inlet valve of the refrigerator needs
to be between 30 and 120 psi (207 and 827 kPa).
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs
to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis
system is less than 40 psi (276 kPa):
■Check to see whether the sediment filter
in the reverse osmosis system is blocked.
Replace the filter if necessary.
■Allow the storage tank on the reverse
osmosis system to refill after heavy usage.
■If your refrigerator has a water filter, it may
further reduce the water pressure when
used in conjunction with a reverse osmosis
system. Remove the water filter. See “Water
Filtration System.”
If you have questions about your water
pressure, call a licensed, qualified plumber.
GETTING STARTED | 13
GETTING STARTED
GETTING STARTED
WATER SYSTEM PREPARATION
Please read before using the water system.
Follow the directions specific to your model.
STYLE 1 (DISPENSER MODELS)
IMPORTANT: After connecting the refrigerator
to a water source or replacing the water filter,
follow the steps below to make sure that the
water system is properly cleaned. This will flush
air from the filter and water dispensing system,
and prepare the water filter for use.
NOTE: If your model has a base grille filter
system, make sure the base grille filter
is properly installed and the cap is in the
horizontal position.
1. Open the freezer door and turn off the ice
maker. The On/ Off switch is located on the
top right side of the freezer compartment.
Move the switch to the OFF (right) setting
as shown.
Do not use with water that is microbiologically
unsafe or of unknown quality without adequate
disinfection before or after the system. Systems
certified for cyst reduction may be used on
disinfected waters that may contain filterable cysts.
2. Use a sturdy container to depress and hold
the water dispenser lever for 5 seconds, and
then release it for 5 seconds. Repeat until
water begins to flow. Once water begins to
flow, continue depressing and releasing the
dispenser lever (5 seconds on, 5 seconds
off) until a total of 3 gal. (12 L) has been
dispensed. This will flush air from the filter
and water dispensing system and prepare
the water filter for use. Additional flushing
may be required in some households.
NOTE: As air is cleared from the system,
water may spurt out of the dispenser.
3. Open the freezer door and turn on the ice
maker. Move the switch to the ON (left)
position.
NOTE:
Allow 24 hours to produce the first
batch of ice.
Discard the first three batches of ice
produced.
Allow 3 days to completely fill ice
container.
Depending on your model, you may
want to select the maximum ice feature
to increase the production of ice.
STYLE 2 (NON-DISPENSER MODELS)
IMPORTANT: After connecting the refrigerator
to a water source or replacing the water filter,
fill and discard two full containers of ice to
prepare the water filter for use, before using the
ice.
NOTE: If your model has a base grille filter
system, make sure the base grille filter
is properly installed and the cap is in the
horizontal position.
1. Turn on the ice maker. Lower the wire
shutoff arm as shown. Please refer to “Ice
Maker and Storage Bin” for further
instructions on the operation of your ice
maker.
NOTES:
■Allow 24 hours to produce the first batch of
ice.
■Allow 3 days to completely fill ice container.
■Depending on your model, you may want
to select the maximum ice feature to
increase the production of ice.
GETTING STARTED | 15
GETTING STARTED
GETTING STARTED
REFRIGERATOR USE
If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similar qualied person. Do not use a
cord that shows cracks or abrasion damage
along its length or at either the plug or
connection end.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, re, or electrical shock.
POWER ON/OFF SWITCH
If you need to turn the power to your
refrigerator On or Off, you must remove the top
grille assembly to access the power switch. Turn
the power to the refrigerator Off when cleaning
your refrigerator.
INTEGRATED INSTALLATION - FULL HEIGHT /
ARMOIRE MACHINE COMPARTMENT COVER
To install the grille panel to the refrigerator:
1. Slide the upper and lower slots in each
bracket onto the mounting pins extending
upward from the top of the refrigerator.
2. Push the grille panel forward to fully
engage the spring clips and fasten the
grille panel.
TO REMOVE THE GRILLE PANEL FROM THE
REFRIGERATOR:
1. Open the door(s).
2. Place both hands under the grille panel,
grasping the bottom edge between your
ngers and thumbs.
3. Pull the grille panel straight out until the
grille stops. Then, lift up on the grille panel
to remove.
TURN POWER ON OR OFF:
1. Remove the top grille panel.
2. Press Power switch to the ON or OFF
position.
3. Replace top grille.
IMPORTANT: Be sure the power switch is set to
the ON position after cleaning refrigerator or
changing light bulbs.
A
A. Power switch
WARNING
Explosion Hazard
Keep flammable materials and vapors, such
as gasoline, away from refrigerator.
Failure to do so can result in death,
explosion, or fire.
16 | GETTING STARTED
GETTING STARTED
For crushed ice, cubes are crushed before
being dispensed. This may cause a slight delay
when dispensing crushed ice. Noise from the
ice crusher is normal, and pieces of ice may vary
in size. When changing from crushed to cubed,
a few ounces of crushed ice will be dispensed
along with the first cubes.
To Dispense Ice:
1. Press the button to select the desired type
of ice.
2. Press a sturdy glass against the ice
dispenser pad. Hold the glass close to the
dispenser opening so ice does not fall
outside of the glass.
IMPORTANT: You do not need to apply a lot
of pressure to the pad in order to activate
the ice dispenser. Pressing hard will not
make the ice dispense faster or in greater
quantities.
Cut Hazard
Use a sturdy glass when dispensing ice.
Failure to do so can result in cuts.
WARNING
WATER DISPENSER
To Dispense Water:
1. Press a sturdy glass against the water
dispenser pad.
NOTES:
While dispensing water and for 3
seconds after dispensing has stopped,
the digital display will show how many
ounces of water have been dispensed.
To switch from ounces to cups, press
and hold ICE and LOCK at the same
time until the dispenser beeps after 3
seconds. To switch from cups to liters,
press and hold the buttons for another
3 seconds. To switch back to ounces,
repeat the process a third time.
2. Remove the glass to stop dispensing.
NOTE: Water may have an off-flavor if you do
not use the dispenser periodically. Dispense
enough water every week to maintain a fresh
supply.
ICE DISPENSER
Ice dispenses from the ice maker storage bin in
the freezer when the dispenser pad is pressed.
The dispensing system will not operate when
the freezer door is open. To turn off the ice
maker, see “Ice Maker and Storage Bin.”Your ice
maker can produce both crushed and cubed
ice. The display screen reads “CRUSHED” or
“CUBED,” indicating which type is selected. To
change the setting, press the ICE button before
dispensing ice.
WATER AND ICE DISPENSERS
ON SOME MODELS
IMPORTANT:
■After connecting the refrigerator to a water
source or replacing the water filter, flush
the water system. Use a sturdy container to
depress and hold the water dispenser lever
for 5 seconds, then release it for 5 seconds.
Repeat until water begins to flow. Once
water begins to flow, continue depressing
and releasing the dispenser lever
(5 seconds on, 5 seconds off) until a total
of 3 gal. (12 L) has been dispensed. This
will flush air from the filter and water
dispensing system, and prepare the water
filter for use. Additional flushing may be
required in some households.
NOTE: As air is cleared from the system,
water may spurt out of the dispenser.
■Allow 24 hours for the refrigerator to cool
down and chill water.
■Allow 24 hours to produce the first batch
of ice. Discard the first three batches of ice
produced.
■The dispensing system will not operate
when the freezer door is open.
■Depending on your model, your water and
ice dispensers may have one or more of
the following features: a dispenser tray, a
special light that turns on when you use
the dispenser, or a lock option to avoid
unintentional dispensing.
Produktspecifikationer
| Varumärke: | JennAir |
| Kategori: | kylskåp |
| Modell: | JS48PPDUDE |
Behöver du hjälp?
Om du behöver hjälp med JennAir JS48PPDUDE ställ en fråga nedan och andra användare kommer att svara dig
kylskåp JennAir Manualer
8 Januari 2025
8 Januari 2025
7 Januari 2025
7 Januari 2025
7 Januari 2025
27 Oktober 2024
27 Oktober 2024
22 September 2024
22 September 2024
22 September 2024
kylskåp Manualer
- WLA
- CombiSteel
- Ecotronic
- Norlake
- Godrej
- Bushman
- WhiteLine
- New Pol
- Porkka
- Arthur Martin-Electrolux
- Crosley
- Alno
- IOMABE
- Indesit
- Garmin
Nyaste kylskåp Manualer
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
21 Oktober 2025
21 Oktober 2025
20 Oktober 2025
20 Oktober 2025
