Sida 1/4
1
KRONO
Multi-modal Programmable Clock Generator
KRONO is a 4HP programmable multi-mode clock and rhythm generator module featuring tap tempo,
state persistence, CV group swap and 12 independent outputs
why
• To copy, sync and multiply clocks with algorithmic flexibility
• To generate complex, evolving, and synchronized clock patterns via multiple outputs.
• To explore algorithmic rhythms (euclidean, chaos, polyrhythms) and musical ratios.
• To sync your system using tap tempo or external clock sources.
• To instantly save and recall the state for each operational mode.
with
• Sequencers: Drive step progression with synchronized clocks and various rhythmic
divisions/multiplications.
• Drum Modules / Samplers: Create dynamic, polyrhythmic, or probabilistic percussion patterns.
• Modular Effects (Delay, Chorus, etc.): Synchronize effect parameters to the master tempo.
• LFOs / Envelopes / VCAs: Trigger modulations and gates with rhythmic precision and
mathematical/musical relationships.
• Logic Modules: Combine KRONO's outputs to create even more intricate trigger sequences.
how
Set the Base Tempo:
• Tap Tempo: Rhythmically press the TAP button at least 3 times. KRONO record and averages the
intervals. The Aux LED blinks on each valid update. This base tempo is always present on outputs
1A and 1B.
• External Clock: Send a clock signal to the TAP input. KRONO automatically syncs after validating
stable pulses and coping the external input clock. The Aux LED will blink when the new tempo is
copied. At this stage you can then remove the external clock jack and use it somewhere else in
your system.
Select Operational Modes:
1. Press and hold the TAP button until the Status LED becomes steady and then release it.
2. Click the MOD button X times to select mode X (two clicks will select mode 2, etc.).
3. Click TAP to confirm the selection of mode X and activate it.
• The Status LED blinks X times to indicate the active mode. The Aux LED blinks upon confirmation.
• Automatic Save: Upon confirming a mode selection, KRONO automatically saves the current
tempo (from Tap or Ext Clock) and the Swap state (see below) associated with that specific mode
to the internal Flash memory – this will be preserved on power cycles.
Swap Groups A/B:
• Give the MOD button a short press or send a gate signal to the MOD in to swap.
• This action inverts the function/pattern assignment between the Group A outputs (2A-6A) and
Group B outputs (2B-6B). For example, in Euclidean mode, the K/N patterns swap between the
two groups.
• The Aux LED blinks to confirm the swap.
• The Swap state (active/inactive) is saved along with the base tempo when selecting a mode.
TIP: If you want to save the current tempo or swap state without changing the mode, simply re-select the
current mode.
2
modes – firmware v1.0
1. Ratios: Direct multiplications and divisions of the base tempo for proportional rhythmic ratios.
2. Euclidean: Generates Euclidean rhythms by distributing K pulses over N steps.
3. Musical: Applies common musical ratios (e.g., triplets, dotted notes, predefined swing divisions).
4. Probabilistic: Outputs trigger based on defined probability thresholds for each output.
5. Sequential: Generates clocks based on mathematical sequences (Fibonacci, prime numbers).
6. Swing: Applies individual swing/shuffle levels per output, delaying even beats.
7. Polyrhythm: Assigns independent X:Y ratios to outputs; output 6 can generate a logical sum.
8. Logic: Applies logic operations (AND, OR, XOR, NAND, XNOR) between internal clocks or external
inputs (if configured).
9. Phasing: Generates pulses with configurable time offsets (phase shifts) relative to the main clock.
10. Chaos: Creates unpredictable rhythmic patterns based on chaotic algorithms.
New modes will be added with upcoming firmware updates.
1. Ratios: Multiplications/Divisions
• Group A: Outputs clocks at multiples of the base tempo (x2, x3, x4, x5, p2-x6 on outputs 2A–6A).
• Group B: Outputs clocks at divisions of the base tempo (/2, /3, /4, /5, /6 on outputs 2B–6B).
• Swap: Inverts functions between groups (Group A becomes divisions, Group B becomes
multiplications).
2. Euclidean Rhythms
• Group A: Generates Euclidean rhythms on outputs 2A–6A using a predefined set of steps (K) and
total length (N).
• Group B: Generates Euclidean rhythms on outputs 2B–6B using a different predefined K/N set.
• Swap: Swaps the K/N parameter sets between Group A and B.
3. Musical
• Outputs clocks based on rhythmic ratios (fractions of the base tempo) on outputs 2–6 of each
group.
• Group A ratios: 1/6 - 1/8 - 8/1 - 6/5 - 4/5.
• Group B ratios: 1/7 - 3/4 - 5/3 - 7/2 - 9/4.
• Swap: Swaps the ratio sets between groups.
4. Probabilistic: Trigger Probability
• Group A: Each output (2A–6A) has a predefined increasing probability (10% to 50%) of firing
a trigger on each base clock.
• Group B: Each output (2B–6B) has a predefined exponentially decreasing probability (50% to
~3%) of firing a trigger on each base clock.
• Swap: Inverts the probability curves between groups (Group A becomes decreasing, Group B
becomes increasing).
5. Sequential: Mathematical Sequences
• Group A: Outputs triggers on 2A–6A based on a mathematical sequence (Default: Fibonacci {1,
2, 3, 5, 8}) applied to the base clock counter.
• Group B: Outputs triggers on 2B–6B based on a different sequence (Default: Primes {2, 3, 5, 7,
11}).
• Swap: Swaps sequences between groups (Group A uses Lucas {2, 1, 3, 4, 7}; Group B uses
Composites {4, 6, 8, 9, 10}.
6. Swing and Shuffle
• Group A: Applies unique swing percentages to outputs 2A–6A, delaying even-numbered beats.
• Group B: Applies a different set of unique swing percentages to outputs 2B–6B.
• Swap: Swaps the swing percentage sets between groups.
