Sida 1/12
USA: Joovy • 2919 Canton Street • Dallas, TX 75226 • Tel: (877) 456-5049 • Fax: (214) 761-1774 • Email: customerservice@joovy.com • Website: www.joovy.com
CANADA: ISSI Inc. • 2400A Autoroute Transcanadienne • Pointe-Claire, QC, H9R 1B1 • Tel: (800) 667-4111 • Montreal: (514) 344-3045 • Email: service@issibaby.ca
Tricycoo 4.1™
102X
© Joovy 2016 • 160331
EN
FR ES
!
WARNING
Please read these instructions carefully before use and keep them for future reference.
TO AVOID SERIOUS INJURY
• Continuous adult supervision is required.
• Never use near motor vehicles.
• Never use near streets, swimming pools, hills, steps, or sloped driveways.
• Always wear shoes when using the tricycle.
• Allow only one rider.
• Minimum age of rider shall be 10 months.
• Maximum weight of rider shall be 44 lbs. (20 kg).
• The baby surround system should be used for children who are not yet capable of sitting in the seat without support
or who are not capable of pedaling the product by themselves.
• RidershouldalwayswearaproperlyttedhelmetthatcomplieswithFederalhelmet(16CFR1203)requirements.
• Do not load the basket with more than 2 lbs. (0.9 kg). Excessive weight may cause a hazardous or unstable
condition.
Please do not return this product to the store
If you experience any difculty with the assembly or use of this product, or if you have a question regarding these
instructions, please contact our Customer Service Department:
UNITED STATES – Joovy: (877) 456-5049, Hours 8:30 am – 5:00 pm Central Time.
CANADA – ISSI Inc.: (800) 667-4111, Hours 8:30 am – 5:00 pm Eastern Time.
Please note: Styles and colors may vary.
1 Unpacking the Product
• Remove everything from the box and identify the parts using Figure 1.1. (not to scale)
A: triycle frame, B: handlebar, C: canopy, D: seat, E: seat pad, F: front wheel, G: rear wheels, H: fender, I: headrest/harness,
J: shoulder harness cover pads, K: baby surround system, L: parent push handle, M: basket, N: cup holder, O: box wrench,
P: allen wrench, and documents (not shown)
NOTE: All hardware (screws, nuts, bolts) will come pre-attached to various parts of the tricycle.
• Discard all packaging materials properly including plastic coverings.
• DO NOT allow children to play with any packaging materials.
!
WARNING
Adult assembly required. Tools required (not included): Phillips Screwdriver.
Choking Hazard to children under the age of 3 years – contains small parts prior to assembly. Some screws may
have sharp edges and sharp points.
Keep all small parts out of reach of children at all times.
2 Installing the Rear Wheels
• Keep children away while assembling.
• Insert one rear wheel to the rear axle of the tricycle frame until there is an audible click. See Figure 2.1.
• Repeat on the other side.
• To remove the rear wheels, push the tab on the rear axle and pull the rear wheel away from the tricycle. See Figure 2.2.
3 Front Wheel Assembly
• Using a screwdriver (not included), unfasten the screws and the top part of the cap on the tricycle frame. See Figure 3.1. Set parts aside.
• Note where there is a circular hole and a square hole on the front wheel tube.
• Place the fender onto the front wheel tube, making sure to place the fender all the way down. The square hole on the front wheel tube
should be facing the short side of the fender. See Figure 3.2. This is the front of the tricycle.
• Insert the front wheel tube into the tricycle frame. The square hole/short side of the fender should be facing the front of the tricycle. See
Figure 3.3.
4 Handlebar Assembly
• Unfasten the nut and bolt on the handlebar using the larger end of the box wrench. See Figure 4.1. Set the nut and bolt aside.
• Insert the handlebar through the top part of the cap previously removed from the tricycle frame in Section 3.
• Attach the handlebar to the top of the front wheel tube. The handlebar should be leaning forward, with the square and circular holes
matching the front wheel tube. See Figure 4.2.
