Sida 1/6
Joy-IT powered by SIMAC Electronics GmbH - Pascalstr. 8 - 47506 Neukirchen-Vluyn - www.joy-it.net
SBC-LCD02
1.44" HD IPS TFT LCD
1. GENERAL INFORMATION
Dear customer
Thank you for choosing our product. In the following, we will show you
what you need to bear in mind during commissioning and use.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us.
These instructions were developed and tested for the Raspberry
Pi 4 and Raspberry Pi 5 with the Bookworm OS operating system.
It has not been tested with newer operating systems or newer
hardware.
i
2. USE WITH THE ARDUINO
2.1 Connection
Arduino Display
VCC (3V) LED
Pin 13 SCK
Pin 11 SDA
Pin 5 A0
Pin 3 Reset
Pin 4 CS
GND GND
VCC (3V) VCC
i
2.2 Code example
For the SBC-LCD02 we use the ucglib library from olikraus (in the library
manager you will find the library under the name Ucglib, published by
Oliver), which was published under the
bsd-License
. You can download
the library under
Sketch → Include library → Manage libraries...
.
Now you can execute GraphicTest under
File → Examples → Ucglib →
GraphicTest
. You can upload the code via Upload. First make sure that
the board and port are selected correctly under Tools.
Before using the code example,
the constructor
must first be selected
in
the code example
. This can be found in the
GraphicTest example in lines 49 to 90
. Line 61 is required for the dis-
play used in these instructions. You can also use line 60 if you do not have
the option of connecting your display to the hardware SPI pins and need
or want to use other pins instead.
Please note that you may have to adjust the pins in the
respective constructor so that they correspond to your hardware
SPI pins or, if applicable, your desired pins.
i
If you still have an older model of the display, here a display with a red
circuit board instead of the newer model with the black circuit board, you
can download a slightly customised library file here. You must unzip this
file and can then insert the unzipped file under
"C:\Users\username\Documents\Arduino\libraries\Ucglib\src\clib"
and thus replace the existing file there.
In line 42 of the file that has now been inserted, you have the option of
adjusting the oset of the y-axis.
If you set the oset to 32, this means that you are using the display with
the black board. However, if you set the oset to 0, this means that you
are using the display with the red board.
