Sida 1/7
RK-C17D2
/ESP
&
ASSEMBLY INSTRUCTIONS
Thank you purchasing the rack mount for adapter.
Please carefully read these assembly and installation instructions before
beginningassembly.
SafetyPrecautions
Please read understand these safety precautions before using and this
product.
RackMountAdapter
RK-C17D2)74
Assembly and Installation Instructions
Symbols
To highlight usage precautions and product depictions to assure safe and correct
product usage and to avoid danger or injury to persons using this product or
other persons, several symbols are used.
Improper handling in disregard of these notices may result in
bodily injury and
even death.
Mishandling of the unit in disregard of these notices may
result in minor injury or damage to the unit.
Assembly/Installation Precautions
･Attaching this product to video monitors other than those authorized by
JVC may result in the monitor falling over or falling down, potentially
causing damage or bodily injury.
･To assure secure installation when attaching this product to an EIA
rack, separately provide appropriate screws and bolts. Do not
improperly attach, or use improper screws or bolts. Doing so may result
in the monitor or EIA rack falling over or falling down, potentially
causing damage or bodily injury.
･ Assemble all provided bolts, nuts and screws securely. Failure to do so
may result in the monitor falling over or falling down, potentially causing
damage or bodily injury.
･Do not install in unstable locations such as uneven or sloped surfaces
or locations subject to vibration or shock. Doing so may result in the
monitor falling over or falling down, potentially causing damage or
bodily injury.
･ To avoid against bodily injury or damage, be sure that you have
sufficient working area before beginning assembly.
Tools required for assembly
Philips-head screwdriver
Parts List
Please contact the store where you purchased the product if any parts are missing.
Side Panel x 2
Monitor Securing
Screw x 4
●Remove monitor stand prior to installing.
1. Attach side panels to left and right sides of monitor.
Secure panels with two monitor securing screws per side.
●
To avoid injury to fingers, take care to not catch your
finger between the monitor and the part when
tightening the parts together.
* Screws to install to an EIA rack must be prepared separately.
Screw
x 2
Screw
x 2
Side panel
<View from side>
Panels can be attached in two ways.
2. Attach monitor to rack.
Or
Pattern 1
(Aligning to the front cabinet)
Pattern 2
(Aligning to the control panel)
