I N S T A L L E D S U B W O O F E R S

If you want your bass to be heard but not seen, KEF oers a wide

selection of installed subwoofers with incredible sonic performance

whilst remaining visually discreet. The foundation of the range, the

powerful KASA500 amplier (250Wx2) featuring selectable

customized equalisation and compression limiting, is designed to

maximize the performance of each KEF subwoofer option which

includes three superlative subwoofers: The Ci200QSb-THX with

a massive 8inch driver, the Ci3160RLb-THX with three 6.5inch

woofers on a rigid aluminum bae, and the svelte Ci200TRb that

requires only 59mm of mounting depth.

Not only do these subwoofers provide a perfect visual match to

our Extreme Theatre speakers they also perfectly enhance the

sonic capabilities of the entire KEF line, providing you with a true

high performance discrete theatre system. Rened yet gutsy, two

Ci3160RLb-THX, or four of the Ci200QSb-THX powered by

the KASA500 meet THX Select2 standards; double that to achieve

THX Ultra2. In passive mode, the Ci200TRb and Ci200QSb-THX

can be used with a stereo amplier to provide the bass response of

an 8inch speaker for a smaller in-wall or in-ceiling mounting.

E X T R E M E H O M E T H E A T R E

For the ultimate custom installed home cinema, the formidable Ci-REFERENCE

and Ci-R Series has the jaw-dropping acoustic capabilities of the classic KEF

oorstander it’s named after, with all the drama and emotional intensity of full

theatre sound quality. A complete system certied to THX Ultra2/Select2

standards, the Ci-REFERENCE and Ci-R Series consists of two powerful

in-ceiling speakers that can be combined with one of four in-wall models

and a choice of two sensational new powered subwoofer congurations. As

you might expect, its towering performance sets a new standard for custom

installed speakers.

E X T R E M E LY L O W P R O F I L E

With its patented ultra-low prole speaker driver, the revolutionary

T Series ts snugly into even the narrowest voids while delivering all the

lavishly detailed and evenly dispersed imagery of KEF’s latest tangerine

waveguide technology. Comprised of a Round model and a Square model

requiring less than 36mm of mounting depth, and a revolutionary 200mm

sub-woofer that needs 59mm of depth, the T Series allows you to install

a speaker that delivers full audiophile quality sound even when mounting

space is at a premium. As easy to t as any other KEF architectural

speaker, and an equally accomplished sonic performer, it’s another

example of KEF innovation beneting the installer as much as the listener.

K E F C i S P E A K E R P L A C E M E N T T O O L

Simple to use, with pull-down menus and sliders to dene the room size, desired

volume and coverage pattern, the KEF Ci speaker placement software generates

optimum speaker locations, wiring diagrams and sound coverage topography to help

you determine the right number of speakers for the area concerned.

H I D E Y O U R S P E A K E R S ,

N O T Y O U R S O U N D

For music or movies, your installation needs to deliver the awlessly accurate

three-dimensional sound you’d expect from the best conventional speakers -

startlingly clear and breathtakingly realistic. And that’s exactly what our Ci

range does.

KEF’s passion for acoustic excellence shines through in

every model. By combining radically innovative engineering

with sophisticated design technologies, the Ci range

achieves what used to be thought impossible: compact

custom installation speakers that sound as compelling as an

audiophile quality hi- system, no matter where you sit.

With impeccable cosmetics, there’s a KEF Ci model for

every application, from tiny ceiling speakers the size of

downlights to motorised super-premium home theatre

speakers that glide into place at the touch of a button.

All KEF speakers are timbre-matched, with each other and with KEF’s extensive range

of home speakers, so any combination you specify for dierent listening areas will

have the same tonal colour for a perfectly consistent soundstage.

Fast, easy installation has always been valued by installers. With only a few simple

steps and KEF’s unique design features, architectural speakers can be tted quickly,

with no special skills. Once the hole is cut and the cable run, the area is soon ooded

with great high denition sound.

O B S E S S E D W I T H H I G H R E S O L U T I O N

KEF, one of the originators of British Hi-Fi sound, has more than 55 years of

pioneering award winners from professional studio monitors to the legendary

Reference Series and the ground-breaking MUON, BLADE and LS50 Wireless.



Every KEF speaker, large or small, epitomises the seamless integration of

innovative engineering and outstanding design.

This technology leadership has always been what sets KEF’s installed systems

apart, ever since our revolutionary Motorised and Soundlight models. Today, you

can choose from a superlative range of whole house solutions to suit any space,

large or small, outside as well as in. Discreet in appearance, easy to install and

engineered to last, what they all share is best-in-class acoustic performance. And

that’s the real dierence - with KEF’s architectural speakers, everyone gets to

enjoy uncompromised audiophile quality sound.

U N I - Q

KEF’s patented Uni-Q driver technology is a feat of acoustical engineering, precisely

aligning the acoustic centres of both the tweeter and midrange/bass driver. The result

is a point source that eortlessly reproduces sound just as it was captured in the

recording, with clear highs, smooth midrange and fast, clean bass all with minimal,

sound-damaging distortion. Imaging is precise, and with Uni-Q’s signature wide o-

axis response, all of the benets are delivered to every person in the room.

“Hide your speakers, not your sound” - by eliminating the traditional ‘sweet spot,’

Uni-Q allows for complete freedom of positioning, ideal for placement where

aesthetics are important without compromising on sound quality. For Extreme

Theatre, when installed in-ceiling and close to the wall, the front speakers precisely

match the sound to the on-screen action.

F E AT U R E S A N D T E C H N O L O G I E S

Whatever your budget, you’ll nd that the clarity, depth and sheer realism of the

sound you experience with KEF architectural speakers is enhanced by technologies

found nowhere else.

Uni-Q driver array - KEF’s patented Uni-Q driver technology places the

tweeter at the acoustic centre of the bass/midrange cone so that both act

as a single source, dispersing sound widely and evenly over a large area. No

matter the placement, KEF custom installation speakers deliver eortlessly

natural sound with minimal distortion to every person in the room.

Special Grill Treatment - The powder coated grille has a unique plating

process to ensure long life and corrosion resistance even in humid and

marine conditions.

Tangerine waveguide - As well as protecting the driver, this enhances

Uni-Q’s exceptionally wide dispersion characteristics.

IP64 Certication - The speaker passed ocial IEC testing to ensure that

splashing water would have no harmful eects on assembly components.

KASA500 Amplier

Ci160TR

Ci160TS

Ci200QSb-THX Ci200TRb-THX

Ci3160RLb-THX

PM-CI-B-EN-TX-19

KEF.COM

A r c h i t e c t u r a l S p e a k e r s

Scan to learn more

O U T D O O R

C O M M E R C I A L R O U N D

M O T O R I S E D

Uni-Q driver array - KEF’s patented Uni-Q driver technology places the

tweeter at the acoustic centre of the bass/midrange cone so that both

act as a single source, dispersing sound widely and evenly over a large

area. No matter the placement, KEF custom installation speakers deliver

eortlessly natural sound with minimal distortion to every person in the

room.

Special Grill Treatment - The powder coated grille has a unique plating

process to ensure long life and corrosion resistance even in humid and

marine conditions.

Tangerine waveguide - As well as protecting the driver, this enhances

Uni-Q’s exceptionally wide dispersion characteristics.

IP64 Certication - The speaker passed ocial IEC testing to ensure that

splashing water would have no harmful eects on assembly components.

Woofer

160 mm

(6.5 in.)

130 mm

(5.25 in.)

115 mm

(4.5 in.)

Dimensions

(H x W x D)

300 x 226 x 263.5 mm

(11.8 x 9 x 10.37 in.)

262 x 197 x 235 mm

(10.3 x 7.75 x 9.25 in.)

235 x 172 x 203.2 mm

(9.25 x 6.75 x 8 in.)

Finish

White/Black White/Black White/Black

V E N T U R A

Ventura 6 Ventura 5 / 5T* Ventura 4

Woofer

160 mm

(6.5 in.)

115 mm (4.5 in.) /

110 mm (4.3in.)

Cut-out

Ø240 mm

(Ø9.45 in.)

Ø196 mm

(Ø7.71 in.)

Q S E R I E S

Uni-Q Driver

Ci115QCT

C L A S S I C

S E R I E S

Ci160ST Ci110FCT

Rough-in Frame

RIF200R RIF160R

Rear Enclosure

N/A N/A

Woofer

3 X 75 mm

(3 X 3 in.)

Cut-out

112 X 354 mm

(4.41 X 13.94 in.)

Q S E R I E S

CI3-80QT

Tall Rectangle Rectangle Square Round

Subwoofers Soundlight Dual Stereo

Rectangle Square Square SquareRound Round Round

Woofer

5 x 160 mm

(5 x 6.5 in.)

3 x 160 mm

(3 x 6.5 in.)

4 x 100 mm

(4 x 4 in.)

200 mm

(8 in.)

160 mm

(6.5 in.)

200 mm

(8 in.)

160 mm (6.5 in.)

T Series

115mm (4.5 in.)

130 mm

(5.25 in.)

200 mm

(8 in.)

160 mm (6.5 in.)

T Series

115mm (4.5 in.)

130 mm

(5.25 in.)

3 x 160 mm

(3 x 6.5 in.)

200 mm

(8 in.)

200 mm

(8 in.)

100 mm

(4 in.)

100 mm

(4 in.)

50 mm

(2 in.)

160 mm

(6.5 in.)

160 mm

(6.5 in.)

Cut-out

1052 x 209 mm

(41.42 x 8.23 in.)

660 x 209 mm

(25.98 x 8.23 in.)

476 x 114 mm

(18.74 x 4.49 in.)

334 x 238 mm

(13.15 x 9.37 in.)

274 x 194 mm

(10.79 x 7.64 in.)

238 x 238 mm

(9.37 x 9.37 in.)

194 x 194 mm

(7.64 x 7.64 in.)

158 x 158 mm

(6.22 x 6.22 in.)

Ø240 mm

(Ø9.45 in.)

Ø196 mm

(Ø7.71 in.)

Ø158 mm

(Ø6.22 in.)

660 x 209 mm

(25.98 x 8.23 in.)

238 x 238 mm

(9.37 x 9.37 in.)

Ø240 mm

(Ø9.45 in.)

112 x 112 mm

(4.41 x 4.41 in.)

Ø118 mm

(Ø4.65 in.)

Ø65 mm

(Ø2.56 in.)

194 x 194 mm

(7.64 x 7.64 in.)

Ø196 mm

(Ø7.71 in.)

C i - R E F E R E N C E

Extreme Theatre

Ci5160REF-THX

C i - R S E R I E S

Extreme Theatre

Ci5160RL-THX Ci3160RL-THX Ci200RS-THX Ci200RR-THX

Ci3160RLb-THX

KASA500 Required

C i - T S E R I E S

Ci160TS Ci160TR

Ci200TRb

KASA500 Recommended

C i - Q S E R I E S

Ci4100QL-THX Ci130QRCi200QL Ci200QS Ci200QRCi160QL Ci160QS Ci130QS Ci160QR

Ci200Qsb-THX

KASA500 Recommended

Ci100QS Ci100.2QR

C i - C S E R I E S

Ci160.2CL Ci160.2CS Ci160.2CR Ci160CSds Ci160CRdsCi130.2CS Ci200.2CR Ci130.2CR Ci50R

C i - E S E R I E S

Ci200ER Ci160ER Ci130ER

Rough-in Frame

RIF5160L RIF3160L RIF160L RIF160S RIF160R RIF3160L RIF160S RIF160RRIF4100L RIF200L RIF200S RIF130S RIF200R RIF130R RIF200S RIF200R RIF100S RIF100R N/A

Rear Enclosure

N/A N/A N/A RNC200L RNC160L

RNC200S

Excluding Ci20 0RS-THX

RNC160S RNC130S

RNC200R

RNC160R RNC160S RNC160RRNC130R N/A N/A RNC200R RNC100S RNC100R Ci50CAN

Ci200QSb-THX

36mm

(1.42 in.)

Mounting Depth

BTS30 Bluetooth Keypad and Compact Amplier System

The KEF BTS30 is capable of delivering Hi-Fi quality audio to a pair of loudspeakers, and is exible

enough to deliver sound to systems in other rooms. Ideal for use in a wide variety of applications

including homes, hotels, bathrooms and kitchens.

Weatherproof, IP65 certied and salt spray tested, marine quality Ventura Series outdoor

models can ood your pool, garden or yacht with high quality sound, even in the most

extreme atmospheric conditions.

• Weatherproof sealed enclosure

• Salt spray tested for over 1200 hours

• Operating temperature range: -40 to +70C

(-40 to +158F)

• Independent test lab certied IP65

• Aluminium grille and mounting bracket, ¼” -20 threaded inserts for mounting options

• Stainless steel / brass hardware

• Rotatable logo

O U T D O O R

*KEF Ci subwoofer requires the KASA500 subwoofer amplier. ** Ultra 2 certication requires 4 x Ci3160RLb-THX or 4 pairs x Ci200QSb-THX used with 2 x K ASA500. *** Select 2 certication requires 2 x Ci3160RLb-THX or 2 pairs x Ci200QSb-THX used with 1 x KASA50 0.

† Not all accessories and nishes are available in all markets, contact your local dealer for specic range details. THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdic tions. All rights reserved.

*Ventura 5T has 70/100 volt transformer built-in

U LT R A T H I N B E Z E L

Oers the slimmest visible rim around the speaker while casting virtually no shadow.

Designed to sit tight to the wall or ceiling with no visible gap, KEF speakers disappear as

if part of the ceiling. Coupled with a magnetic grille that is as silent as it is acoustically

transparent, KEF architectural speakers are fast and easy to install for the ultimate in

discreet installation.

D U A L S T E R E O

For areas with space for only one speaker, KEF’s Ci Series Dual Stereo model plays

left and right channels from a single unit containing twin tweeters and a dual voice coil

woofer.

S O U N D L I G H T S

As discreet as halogen downlights, KEF’s tiny Soundlights give you big speaker

performance with outstanding sound coverage, thanks to Uni-Q’s exceptionally wide

dispersion.

E X T R E M E LY L O W P R O F I L E

When nothing else will t at 40mm (1.57in.) deep, requiring a mounting depth of only 36mm (1.42in.), the Ci160TR round, the

Ci160TS square, and the Ci200TRb subwoofer at 59mm are the slimmest architectural speakers in the world, and all t snugly

into even the narrowest voids without compromising audio performance.

A complete system certied to THX Ultra2/Select2 standards, the Ci-REFERENCE

and Ci-R Series consists of two powerful in-ceiling speakers that can be combined with

one of four in-wall models and a choice of two sensational new powered subwoofer

congurations. As you might expect, its towering performance sets a new standard for

custom installed speakers.

KEF’s patented Uni-Q driver technology places the tweeter at the acoustic centre of the

bass/midrange cone so that both act as a single source, dispersing sound widely and evenly

over a large area. No matter the placement, KEF custom installation speakers deliver

eortlessly natural sound with minimal distortion to every person in the room.

E X T R E M E H O M E T H E AT R E

U N I - Q

With three subwoofers to choose from, the elegant Ci3160RLb-THX with 3 lighting fast

6.5” woofers, the powerful and exible square Ci200QSb-THX with a massive 8” driver,

and the svelte Ci200TRb that mounts in under 59mm, there is a KEF installed subwoofer

for any room or installation. When driven by the powerful KASA500 amplier (2x250W),

whose custom DSP EQ curves allow them to adapt to any sonic situation, the KEF installed

subwoofers are the foundation for your theatre or music room, unleashing all of the impact,

drama, and intensity of any movie soundtrack while preserving valuable oor space! KEF’s

THX Select and Ultra certied in-wall subwoofers are built with a serious regard for aesthetic

appeal that will make even the most demanding interior designer fall in love.

I N S T A L L E D S U B W O O F E R

T E C H N O L O G I E S

F E AT U R E S

S P E A K E R N O M E N C L AT U R E

S P E C I A L A P P L I C AT I O N

Dual Stereo

Subwoofer

THX

approved

Transformer

S H A P E

R A N G E N A M E

REF

Reference

R Series

Q Series

T Series

C Series

E Series

W O O F E R S I Z E ( M M )

C U S T O M I N S TA L L AT I O N

Round

Square

Rectangle

Motorised

Rear Can

160

E X A M P L E - C i 1 6 0 C R d sC R d s

A C C E S S O R I E S

Steel Rough-in Frames

(See table for product code)

Rough-in Frames (new construction brackets)

are used with in-wall and in-ceiling speakers and

are available for most models. Installed during

the pre-wiring of a new construction installation,

they allow the installer to reserve the space in

the wall or ceiling and simplify cutting the perfect

hole size.

Steel Rear Enclosures

(See table for product code)

Metal Rear Enclosures (back boxes) are

available for most models of KEF architectural

speakers. Installed during the pre-wiring of

a new construction installation they provide

a sealed enclosure for the loudspeaker and

reduce sound transmission to the room

behind the speaker.

A M P L I F I C A T I O N

O P T I O N A L

KASA500

KASA500 is a powerful 2x250W Class D stereo amplier. With powerful, bespoke DSP utilizing KEF’s

propriety iBX technology that extends the bass depth dynamically, KASA500 unlocks the full potential

of the driver’s power at any listening level. Custom EQ settings optimise the performance of KEF

subwoofers into any installation, and limitless system congurations are possible through the inclusion

of high-level speaker and line level inputs, plus signal pass-through with full range or adjustable high pass

operation. Rackmount ears included.

Keypad (IP64 certifed) Amplifer (UL2043 approved)

Produktspecifikationer

Varumärke:	KEF
Kategori:	ej kategoriserat
Modell:	BTS30

Behöver du hjälp?

Om du behöver hjälp med KEF BTS30 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

ej kategoriserat KEF Manualer

KEF BTS30 Bruksanvisning

8 Augusti 2025

KEF Q Series Grille Bruksanvisning

8 Augusti 2025

ej kategoriserat Manualer

Nyaste ej kategoriserat Manualer

Sanus VisionMount VLMF109 Bruksanvisning

8 Augusti 2025

Vicoustic Suspended Baffle VMT 3D Bruksanvisning

8 Augusti 2025

Sonicware LIVEN MEGA SYNTHESIS Bruksanvisning

8 Augusti 2025

Vicoustic VicFix Base Bruksanvisning

8 Augusti 2025

Beha-Amprobe AT-8030-EUR Bruksanvisning

8 Augusti 2025

Vitamix FoodCycler Eco 5 Bruksanvisning

8 Augusti 2025

Smart-AVI QWALL-HD Bruksanvisning

8 Augusti 2025

Sanus MFLT1-B2 Bruksanvisning

8 Augusti 2025

Smart-AVI USB2FX-S Bruksanvisning

8 Augusti 2025

Smart-AVI VGA to DVI Active Converter Bruksanvisning

8 Augusti 2025
