Part No.K290223ML

Issue 2:August 2008

5

GP Acoustics (UK) Ltd.,Eccleston Road,Tovil,Maidstone,Kent,ME15 6QP U.K.

Tel:+ 44 (0)1622 672261Fax:+ 44 (0)1622 750653

GP Acoustics(US) Inc.,10 Timber Lane,Marlboro,New Jersey 07746 U.S.A.

Tel:+(1) 732 683 2356 Fax:+(1) 732 683 2358

GP Acoustics GmbH,Am Brambusch 22,D-44536 Lünen,Deutschland.

Tel:+49 (0) 231 9860-320Fax:+49 (0) 231 9860-330

GP Acoustics (France) SAS,39 Rue des Granges Galand - BP60414,

37554 Saint Avertin CEDEX,France.

Tel :+33(0)2 47 80 49 01 Fax:+33(0)2 47 27 89 64

GP Acoustics (HK) Limited,6F,Gold Peak Building,30 Kwai Wing road,

Kwai Chung,N.T.,Hong Kong.

Tel :+852 2410 8188 Fax:+852 2401 0754

KEF JAPAN 1-11-17,Honcho,Koganei-City,Tokyo,JAPAN 184-0004

Tel:+81 (0)42-388-2030 E-mail:info@kef.jp

www.kef.com

KEF and Uni-Q are registered trademarks.Uni-Q is protected under GB patent 2 236929,U.S.Pat.No.5,548,657 and other worldwide patents.

KEF reserve the right,in line with continuing research and development,to amend or change specifications.

DesignTwo-way bass reflexTwo-way bass reflex

Two and a half-way bass reflexTwo and a half-way bass reflex

Three-way bass reflex

Drive units

130mm (5.25in.) Uni-Q165mm (6.5in.) Uni-Q130mm (5.25in.) LF165mm (6.5in.) LF2 x 165mm (6.5in.) LF

19mm (0.75in.) alu dome HF19mm (0.75in.) alu dome HF130mm (5.25in.) Uni-Q165mm (6.5in.) Uni-Q165mm (6.5in.) Uni-Q

19mm (0.75in.) alu dome HF19mm (0.75in.) alu dome HF19mm (0.75in.) alu dome HF

Frequency response50Hz - 40kHz45Hz - 40kHz40Hz - 40kHz36Hz - 40kHz33Hz - 40kHz

Crossover frequency2.5kHz2.5kHz2.5kHz2.5kHz180Hz - 2.5kHz

Amplifier requirements

10-100W15-120W15-130W15-150W15-200W

Sensitivity (2.83V/1m)88dB89dB88dB90dB91dB

Maximum output108dB110dB109dB111dB113dB

Nominal impedance8Ω8Ω8Ω8Ω8Ω

Magnetic shieldingYesYesYesYesYes

Weight4.5kg (9.9lbs)6.45kg (14.2lbs)10.2kg (22.5lbs)14kg (30.9lbs)16.3kg (35.9lbs)

Dimensions301 x 175 x 261 mm365 x 220 x 327 mm815 x 175 x 261 mm865 x 220 x 327 mm942 x 220 x 327 mm

H x W x D11.8 x 6.9 x 10.3 in.14.4 x 8.7 x 12.9 in.32 x 6.9 x 10.3 in.34 x 8.7 x 12.9 in.37 x 8.7 x 12.9 in.

Plinth DimensionsN/AN/A28 x 250 x 295 mm28 x 288 x 348 mm28 x 288 x 348 mm

H x W x D1.1 x 9.8 x 11.6 in.1.1 x 11.3 x 13.7 in.1.1 x 11.3 x 13.7 in.

DesignThree-way bass reflex

Drive units

2 x 130mm (5.25in.) LF

130mm (5.25in.) Uni-Q

19mm (0.75in.) alu dome HF

Frequency response65Hz - 40kHz

Crossover frequency280Hz - 2.8kHz

Amplifier requirements

15-150W

Sensitivity (2.83V/1m)90dB

Maximum output111dB

Nominal impedance8Ω

Magnetic shieldingYes

Weight8.8kg (19.4lbs)

Dimensions165 x 512 x 255 mm

H x W x D6.5 x 20.1 x 10 in.

Installation Manual

Manuel d’installation

Installationshandbuch

Manuale d’installazione

Manual de instalación

Manual de instalação

Installatiehandleiding

Installationsanvisning

Podręcznik instalacji

GB

I

F

D

NL

ES

DK

P

PL

JP

RU

GR

K

CN

TC

(GB)Specifications

(F)Spécifications

(D)Technische Merkmale

(I)Specifiche

(ES)Especificaciones

(P)Especificações

(NL)Technische gegevens

(DK)Specifikationer

(PL)Specyfikacjatechniczna

(RU)

(GR)

(JP)

(CN)

(TC)

(K)

K7269_iQ08_Combined.qxd 17/9/08 12:42 Page 2

Инструкцияпоустановке

Εγχειρίδιο Εγκατάστασης

取り扱い説明書

安装手册

安裝手冊

설치방법

iQ Manual_II-Rev02.indd 12008-9-24 11:50:18

Produktspecifikationer
