Model/Modelo/Modèle: DU1093
Bagless Upright Vacuum
with Hair Eliminator™ Brushroll
Aspiradora de pie sin bolsa
Con cepillo para pelos Hair Eliminator™
Aspirateur Vertical Sans Sac
équipé de Brosse À Rouleau Hair
Eliminator™
www.kenmorefloorcare.com
Vacuum Cleaner Help Line:
1-877-531-7321 (US) / 1-844-608-3081 (CA)
8:00am-5:00pm EST, M-F
Use & Care Guide
Manual de Uso y Cuidado
Manuel d'entretien et d'utilisation

- 2 -
Before Using Your New Vacuum Cleaner 2 ........................................................................
Packing List 2 .....................................................................................................................
Important Safety Instructions 3-4 ........................................................................................
Vacuum Cleaner Warranty 5 ..............................................................................................
Parts and Features 6-7 ........................................................................................................
Assembly Instructions 8-10 .................................................................................................
Operating Instructions 10-15 ...............................................................................................
Performance/Safety Features 16 .........................................................................................
Vacuum Maintenance and Care 17-24 ................................................................................
Troubleshooting 25-26 ........................................................................................................
Requesting Assistance or Service Back Cover ......................................................................
TABLE OF CONTENTS
PACKING LIST
Your KENMORE BAGLESS UPRIGHT VACUUM CLEANER is packaged with the following
parts and components assembled separately in the carton:
1 Upright Vacuum Cleaner (with
Floor Nozzle)
1 Handle
1 Flexible Hose
1 Wand
1 Attachment Holder
Read this Use & Care Guide. It will help you assemble and operate your new Kenmore
vacuum cleaner in the safest and most effective way.
For more information about vacuum cleaner care and operation, call the Vacuum Cleaner
Help Line at 1-877-531-7321 (US) / 1-844-608-3081 (CA). You will need the complete model
and serial numbers when requesting information.
Your vacuum cleaner’s model and serial numbers are located on the Model and Serial
Number Plate. Use the space below to record the model number and serial number of your
new Kenmore vacuum cleaner.
Model No.____________________________________________
Serial No. ____________________________________________
Date of Purchase ______________________________________
Keep this book and your sales check (receipt) in a safe place for future reference.
BEFORE USING YOUR NEW VACUUM CLEANER
1 Hose Storage
1 Extension Wand
1 3-in-1 Combination Tool
1 Pet HandiMate®
1 Use & Care Guide

- 3 -
WARNING!
Your safety is important to us. To reduce the risk of fire, electrical shock, injury to persons
or damage when using your vacuum cleaner, follow basic safety precautions including the
following:
IMPORTANT SAFETY INSTRUCTIONS
• Use your vacuum cleaner only as
described in this Use & Care Guide. Use
only with manufacturer’s recommended
attachments.
• Disconnect electrical supply before
servicing or cleaning out the brushroll
area. Failure to do so could result in the
brushroll unexpectedly starting, causing
personal injury from moving parts.
• Do not leave vacuum cleaner when
plugged in. Unplug from outlet when
not in use and before performing
maintenance.
• To reduce the risk of electrical shock - Do
not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Close
attention is necessary when used by or
near children.
• Do not use with a damaged cord or plug.
If vacuum cleaner is not working as it
should, has been dropped, damaged,
left outdoors, or dropped in water,
immediately discontinue use and call
1-877-531-7321 (US) / 1-844-608-3081
(CA) for assistance.
• Do not pull or carry by cord, use cord as
a handle, close a door on cord, or pull
cord around sharp edges or corners. Do
not run vacuum cleaner over cord. Keep
cord away from heated surfaces.
• Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
• Do not handle plug or vacuum cleaner
with wet hands.
• Do not put any objects into openings.
• Do not use with any opening blocked;
Read all instructions in this guide before assembling or using your vacuum cleaner.
keep free of dust, lint, hair, and anything
that may reduce air flow.
• Keep hair, loose clothing, fingers, and all
parts of body away from openings and
moving parts.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not put on chairs, tables, etc. Keep on
floor.
• Do not use vacuum cleaner to pick
up flammable or combustible liquids
(gasoline, cleaning fluid, perfumes,
etc.), or use in areas where they may be
present. The fumes from these substances
can create a fire hazard or explosion.
• Do not pick up anything that is burning or
smoking, such as cigarettes, matches, or
hot ashes.
• Do not use vacuum cleaner without dust
cup and/or filters in place.
• Always clean the dust cup after
vacuuming carpet cleaners or freshener,
powders, and fine dust. These products
clog the filters, reduce airflow and can
cause damage to the vacuum cleaner.
Failure to clean the dust cup could cause
permanent damage to the vacuum
cleaner.
• Do not use the vacuum cleaner to pick
up sharp hard objects, small toys, pins,
paper clips, etc. They may damage the
vacuum cleaner or dust cup.
• You are responsible for making sure
that your vacuum cleaner is not used by
anyone unable to operate it properly.

- 4 -
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Proper assembly and safe use of your vacuum cleaner are your responsibilities. Your vacuum
cleaner is intended for Household use. Read this Use & Care Guide carefully for important
use and safety information. This guide contains safety statements under warning and caution
symbols.

- 5 -
VACUUM CLEANER WARRANTY
LIMITED WARRANTY
FOR ONE YEAR from the date of sale this product is warranted against defects in material
or workmanship.
WITH PROOF OF SALE a defective product will be replaced free of charge.
The Kenmore brand is used under license. Direct all claims for warranty service to:
1-877-531-7321 (US) / 1-844-608-3081 (CA).
This warranty does not cover filters or belts, which are expendable parts that can wear
out from normal use within the warranty period.
This warranty is void if this product is ever used for other than private household purposes.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
Cleva North America, Inc., Greenville SC 29607

- 6 -
PARTS AND FEATURES
It is important to know your vacuum cleaner’s parts and features to assure its proper and
safe use. Review these before using your vacuum cleaner.
REPLACEMENT PARTS
To order a replacement part, call 1-877-531-7321 (US) / 1-844-608-3081 (CA).
Item Part No.(US) Part No.(CA)
Foam Filter 561055105 561055105
Felt Filter 561055106 561055106
Belt 571025101 571025101
Brushroll 571032106 571032106
Wand 571025107 571025107
Handle 571032101 571032101
Flexible Hose 571032102 571032102
Extension Wand 561055128 561055128
3-in-1 Combination Tool 561055134 561055134
Pet HandiMate®561014106 561014106

- 7 -
PARTS AND FEATURES
Flexible
Hose
Power
Button
Connection
Hose
3-in-1
Combination
Tool
Handle
Wand
Carrying
Handle
Dust Cup
Dust Cup
Lid Release
Button
Dust Cup Release
Button
Hose
Storage
Lower
Hose
Connection
Suction
Control
Lower
Cord
Hook
Power
Cord
Upper
Cord
Hook
Pet
HandiMate®
Attachment
Holder
Floor
Nozzle
Height Adjust
Selector
Hose Release
Button
Accessory
Storage
Extension
Wand

- 8 -
1. Insert the handle into the wand until you
hear a ‘click’.
2. Insert the wand into the main body until
you hear a ‘click’.
3. Align the attachment holder clip with
the front of the wand as shown. Make
sure the oval hole aligns with the
corresponding protrusion on the wand.
Push and snap into place on wand.
Before assembling the vacuum cleaner, check the PACKING LIST (page 2). Use this list to
verify that you have received all the components of your new Kenmore Bagless Upright
Vacuum Cleaner.
Please pay special attention to these hazard alert boxes, and follow any
instructions given. WARNING statements alert you to such hazards as fire,
electric shock, burns and personal injury. CAUTION statements alert you to
such hazards as personal injury and/or property damage.
ASSEMBLY INSTRUCTIONS
Attachment
Holder
4. Align the hose storage with the back of
the wand as shown. Make sure the large
oval hole aligns with the corresponding
protrusion on the wand. Push and snap
into place on wand.
Hose
Storage

- 9 -
7. Insert the combination tool onto the
accessory storage post located on
the back of the main body. The Pet
HandiMate® is stored in the attachment
holder on the wand.
ASSEMBLY INSTRUCTIONS
8. Make sure the upper cord hook is in
the proper position as shown. Wrap the
power cord loosely around the upper
and lower cord hooks.
NOTE: Make sure to wrap the power
cord around the upper cord hook first, and
then around the lower cord hook to avoid
damaging the power cord.
5. Insert one end of the flexible hose into
the main body as shown until you hear a
‘click’. Then run the flexible hose over the
hose storage. Insert the other end of the
hose into the lower hose connection as
shown until you hear a ‘click’.
6. Store the extension wand under the hose
storage as shown. Make sure the smaller
end of the extension wand is upward.
Push and snap into place.
Upper
Cord
Hook
Hose
Storage
Lower
Hose
Connection
I
II
III
I
II

1. Turn the upper cord hook to either side
and down to release the power cord.
- 10 -
CAUTION
Moving parts! To reduce the risk of personal injury, DO
NOT touch the brushroll when vacuum is on. Contacting the
brushroll while it is rotating can cut, bruise or cause other
injuries. Disconnect electrical supply before servicing or
cleaning the vacuum cleaner. Use caution when operating near
children or pets.
OPERATING INSTRUCTIONS
POWER CORD – RELEASE & USE
WARNING
To reduce the risk of electric shock, this
appliance has a polarized plug (one
blade is wider than the other). This plug
will fit in a polarized outlet only one
way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does
not fit, contact a qualified electrician to
install the proper outlet. Do not change
the plug in any way.
Upper
Cord
Hook
9. Lock power cord plug onto the power
cord. WARNING
Electrical Shock and Personal Injury
Hazard
Wrapping the cord too tightly with
excessive stress on the cord may cause
cord damage. A damaged cord is an
electrical shock hazard and could cause
personal injury or damage.
ASSEMBLY INSTRUCTIONS
Power Cord
Plug
Power Cord

- 11 -
2. Detach the power cord plug from the
power cord.
3. Be sure the power cord is locked into
the lower locking notch and the upper
locking notch as shown. This will help
manage the power cord when operating
the vacuum cleaner.
NOTE: Lock the power cord into the
lower locking notch first and then lock
it into the upper locking notch to avoid
damaging the power cord.
Make sure the power cord can move freely
and is not over-extended when locking it
into the lower locking notch.
4. Plug the power cord plug into an outlet
located near the floor.
WARNING
Personal Injury and Product Damage
Hazard
· When any abnormality/failure occurs,
stop using the product immediately and
disconnect the power plug.
· DO NOT use outlets above counters.
Damage from cord to items in
surrounding area could occur.
5. Press the power button with your foot to
turn the vacuum cleaner on.
6. Once you have completed vacuuming,
press the power button again; unplug the
power cord plug from the outlet.
7. To store power cord after use, turn upper
cord hook to the upright position. Then
wrap cord loosely around cord hooks.
POWER CORD - RELEASE & USE
Upper Locking
Notch
Lower
Locking
Notch
WARNING
Electrical Shock and Personal Injury
Hazard
Wrapping the cord too tightly puts stress
on the cord and can cause cord damage.
A damaged cord is an electrical shock
hazard and could cause personal injury
or damage.

2. Turn on the vacuum cleaner by pressing
the power button with your foot.
3. Once the vacuum is on, operate the
vacuum cleaner by tilting the handle
back towards you and the nozzle is flush
with floor surface.
4. Once you have completed vacuuming,
press the power button again. Return
the handle to the fully upright position
by pushing the handle forward until the
vacuum body is locked down in place.
Unplug the power cord from the power
outlet.
UPRIGHT MODE
NOTE: Make sure the vacuum cleaner
is completely assembled and the dust cup
is empty before using. Do not operate
vacuum cleaner without filters in place.
1. Release the handle by placing a foot
on the floor nozzle and pulling back to
change handle position.
PILE HEIGHT SELECTION AND SETTINGS
Select a pile height setting by turning the
height adjust selector located on the floor
nozzle.
Suggested Pile Height Settings
There are four (4) pile height settings on
the vacuum cleaner. For best deep down
cleaning of low pile carpet, use the MED
LOW setting. However, you may need to
raise the height to make some jobs easier,
such as scatter rugs and some deep pile
carpets.
Suggested settings are:
LOW – Bare floor
MED LOW – Low pile carpet
MED HIGH – Medium to deep pile
HIGH – Shag, deep pile, or scatter rugs
- 12 -
OPERATION MODES
Power Button
Height Adjust
Selector

ABOVE FLOOR MODE
NOTE: Brushroll continues to rotate when
using the vacuum in the above floor mode.
DO NOT place the vacuum on the deep
pile carpet to avoid damage to carpet.
1. Place the vacuum cleaner in the upright
locked position.
2. Press the hose release button and
release the flexible hose for above floor
cleaning.
3. Choose the desired extension wand/
attachment and insert it into the flexible
hose.
4. Turn on the vacuum cleaner by pressing
the power button with your foot.
5. Once you have completed vacuuming,
press the power button again and unplug
the power cord from the power outlet.
NOTE: The attachment also can insert
directly into the flexible hose for above
floor cleaning.
CAUTION
Do not allow the vacuum cleaner to
remain in one spot for any length of time
when the brushroll is turning. Damage
to carpet may occur.
CAUTION
Incorrect setting may damage floor.
- 13 -
OPERATION MODES
Pet
HandiMate®
3-1 Combination
Tool
Pet
HandiMate®
3-1 Combination
Tool
Extension
Wand
Hose
Release
Button
I
II

3-IN-1 COMBINATION TOOL
The 3-in-1 combination tool can be
attached to the end of the flexible hose
and the extension wand. Slide the collar of
the tool over the open end of the hose or
the extension wand.
Use the 3-in-1 combination tool in crevice
tool mode for cleaning in tight spaces such
as furniture, between cushions, and stairs.
See ATTACHMENT USE TABLE (page 15).
Press the release button to remove the
brush tool. Set the combination tool in
upholstery brush mode as shown. Use
To return the combination tool to crevice
tool mode, press the release button and
slide the brush tool down the combination
tool.
in upholstery brush mode for cleaning
fabric surfaces such as fabric sofa. See
ATTACHMENT USE TABLE (page 15).
Set the combination tool in dusting brush
mode by pressing the release button and
sliding the dusting brush side of the brush
tool to the end of the combination tool.
Use in dusting brush mode for cleaning
loose surfaces such as drapes. See
ATTACHMENT USE TABLE (page 15).
- 14 -
CAUTION
When using attachments, be careful not
to over extend the flexible hose when
reaching. Trying to reach beyond the
hose stretch capability could cause the
vacuum cleaner to tip over.
CAUTION
DO NOT pull the vacuum cleaner
around the room by the hose. Property
damage or personal injury could result.
OPERATION MODES
ATTACHMENTS
Release Button
Dusting
Brush
Upholstery
Brush

PET HANDIMATE®
The Pet HandiMate® can be attached
to the end of the flexible hose and the
extension wand.
Pet HandiMate® pivots for convenient
cleaning.
Use Pet HandiMate® for cleaning fabric
surfaces such as furniture and carpet. See
ATTACHMENT USE TABLE (page 15).
- 15 -
ATTACHMENTS
WARNING
NEVER use the Pet HandiMate® directly
on pets, as it can cause injury.
CAUTION
Use attachments when the vacuum
cleaner is upright.
*Always clean attachments before using on fabrics.
ATTACHMENT USE TABLE
= Applicable
ATTACHMENT
CREVICE TOOL
DUSTING BRUSH
UPHOLSTERY BRUSH
PET HANDIMATE
Between
Furniture* Cushions* Drapes* Stairs Baseboards
Carpet Bare
CLEANING AREA
®

SUCTION CONTROL
To assist with push/pull force of the
vacuum on surfaces like thick carpet, the
suction control valve can be opened to
help reduce suction. Note that for best
cleaning results, the suction control valve
must be fully closed.
· Slide to right to open the suction control
and decrease suction. Opening control
decreases suction for draperies and
lightweight rugs.
· Slide to left to close the suction control
and increase suction. Closing control
increases suction for upholstery and
carpets.
PERFORMANCE/SAFETY FEATURES
BY-PASS VALVE
This vacuum cleaner has a By-Pass Valve
which prevents the motor from erheating ov
and damage. The valve opens to p vide ro
cooling air when a clog prevents normal
air flow to the vacuum cleaner suction
motor. You will notice a change of sound
as air rushes through the valve opening.
To correct the problem: rem e any clogs, ov
check and r eeded, check eplace filters if n
and empty dust cup if n ded.ee
NOTE: The By-Pass Valve may open
when using attachments or when cleaning
new carpet due to reduce ow or air d airfl
path is blocke caused bd, y mentthe attach s
themselves or by new carpet lint filling the
dust cup quickly.
HAIR ELIMINATORTM BRUSHROLL
For best performance, the floor nozzle is
equipped with a hair eliminatorTM brushroll,
which prevents build-up of hair, string and
other debris on the brushroll. To rem e ov
any hair wrapped around the brushroll,
simply continue vacuuming, allowing the
brushroll to automatically rem e the hair ov
wrap and send it to the dust cup.
Comb Teeth
CAUTION
Moving parts! To reduce the risk of
personal injury, DO NOT touch the
bru rsh oll n whe vacuum is on. Contacting
the brushroll while it is rotating can cut,
bruise or cause other injuries.
NOTE: Always keep the brushroll free
of carpet fiber, string, or hair build-up
to maintain a longer life of the brushroll
belt. If for some reason the brushroll does
become entangled by any string or hair,
stop using the vacuum and clean the
brushroll immediately.
- 16 -
Decrease Suction Increase Suction

1. Turn off and unplug vacuum cleaner. DO
NOT drip water on vacuum cleaner.
2. To clean exterior, or to reduce static
electricity and dust build-up, wipe outer
surface with a clean, soft cloth that has
been dipped in a solution of mild liquid
detergent and water, then wrung dry.
Wipe dry after cleaning.
NOTE: Wash attachments in warm
soapy water, rinse and air dry. Do not
clean in dishwasher.
1. Place attachments in storage position if
necessary (see page 9).
2. Gather the cord and wrap it loosely
around the upper and lower cord hooks.
Lock plug retainer onto the power cord.
3. Store the vacuum cleaner in a dry,
indoor area, on the floor with the handle
locked in the upright position.
- 17 -
Always follow all safety precautions when performing maintenance to the vacuum cleaner.
VACUUM MAINTENANCE AND CARE
WARNING
Electrical Shock and Personal Injury
Hazard
Disconnect electrical supply before
servicing or cleaning the vacuum
cleaner. Failure to do so could result in
electrical shock or personal injury from
vacuum cleaner suddenly starting.
CLEANING EXTERIOR AND ATTACHMENTS
VACUUM CLEANER STORAGE
CAUTION
Do not use attachments if they are wet.
Attachments used in dirty areas, such as
under a refrigerator, should not be used
on other surfaces until they are washed.
They could leave marks.
WARNING
Electrical Shock and Personal Injury
Hazard
Wrapping the cord too tightly puts stress
on the cord and can cause cord damage.
A damaged cord is an electrical shock
hazard and could cause personal injury
or damage.
WARNING
The floor nozzle is equipped with sharp
comb teeth inside. DO NOT touch comb
teeth when servicing or cleaning the
vacuum, which may cause personal
injury.

1. Press the dust cup release button to
remove the dust cup from the main body.
3. Position dust cup area of vacuum over
a waste receptacle. Press down on the
dust release button to open dust cup lid
and allow contents to drop into waste
receptacle.
2. Remove any clogs that might be located
in the suction port.
4. Shake the dust cup to release any debris
that might hang in the pre-filter.
5. Reinstall and insert the dust cup into the
slots on the bottom of the main body,
then press the dust cup into locked slot
and click into place.
NOTE: For best performance, empty
dust cup after every use. Never operate
vacuum cleaner without dust cup and
filters in place.
- 18 -
EMPTYING DUST CUP
WARNING
Always unplug power cord from
electrical outlet before performing any
service on vacuum cleaner.
Dust Cup
Release
Button
Dust Cup
I
II
Suction
Port
I
II
Dust
Release
Button

3. Clean pre-filter by gently tapping over a
trash container. Tap on several sides to
ensure best cleaning.
4. Reinstall the dust cup into the main
body. See installation instructions in the
EMPTYING DUST CUP (page 18).
The pre-filter is located inside the dust cup.
Clean the pre-filter as needed to optimize
suction power.
1. Remove the dust cup as outlined in the
EMPTYING DUST CUP (page 18).
NOTE: Make sure dust cup is free of
debris before opening.
2. Press the dust cup lid release button, and
open the lid.
Pre-fitler
It is recommended to clean the foam and
felt filters with cold water every three
months.
NOTE: When the cleaning of filters no
longer restores vacuum cleaner suction
to full power, or the filters are worn or
broken, replace the filters. To purchase
filters, call 1-877-531-7321 (US) / 1-844-
608-3081 (CA).
Regularly clean and replace the filters to
keep the vacuum's suction power optimal.
1. Remove the dust cup as outlined in the
EMPTYING DUST CUP (page 18).
2. Remove the foam and felt filters.
- 19 -
PRE-FILTER CLEANING
Dust Cup Lid
Release Button
FOAM AND FELT FILTERS CLEANING
Foam Filter
Felt Filter

5. Reinstall the dust cup. See EMPTYING
DUST CUP (page 18).
3. Wash with cold water only. DO NOT
use detergent or soap. Squeeze by hand
and allow to air dry. Allow all filters to
dry 24 hours before putting back into
vacuum cleaner.
NOTE: DO NOT operate without foam
and felt filters installed.
DO NOT wash in the dishwasher.
DO NOT install foam and felt filters if
damp.
4. Replace foam and felt filters into the
vacuum cleaner.
Replace belt whenever a burning rubber
smell caused by excessive slippage occurs.
NOTE: Make sure that the pile height
setting is on the LOW setting.
1. Lay the vacuum cleaner on floor with the
bottom up and the floor nozzle flat.
2. Use a Phillips head screwdriver to
remove the six screws from the belt
cover and the lower plate.
WARNING
Always unplug power cord from
electrical outlet before performing
maintenance to the vacuum cleaner.
- 20 -
Foam Filter
Felt Filter
FOAM AND FELT FILTERS CLEANING
BELT CHANGING
Belt Cover Lower Plate

4. Lift the lower plate combined with the
brushroll.
3. Remove the belt cover from the floor
nozzle.
5. Remove the worn or broken belt.
6. Clean any debris from the floor nozzle.
7. Loop the new belt around the motor
shaft and the belt path on the brushroll.
NOTE: Before reinstalling the lower
plate, make sure the belt is in the middle
of the belt path as shown.
I
- 21 -
BELT CHANGING
II
CAUTION
Motor shaft may be hot.
Belt Cover
Belt
Lower Plate
with Brushroll
Motor Shaft
WARNING
There are sharp edges inside to prevent
hair entanglement. Do not put any part
of the body into the floor brush during
maintenance.

- 23 -
10. Reinstall six screws into the lower plate
and the belt cover. Do not over-tighten the
screws.
PET HANDIMATE® CLEANING
WARNING
Always unplug the power cord from
an electrical outlet before performing
maintenance to the vacuum cleaner.
CAUTION
To reduce the risk of injury from moving
parts, remove Pet HandiMate from
vacuum hose or wand before servicing.
®
Cut off any carpet pile and lint entangled
around brushroll with a pair of scissors.
9. Reinstall the belt cover into place.
BELT CHANGING

- 24 -
CHECKING CONNECTION HOSE FOR
CLOGS
1. Check and remove any clogs in the
connection hose.
2. If necessary, release the connection hose
by removing one screw with a Phillips
head screwdriver and check for clogs.
3. Reinstall the collection hose and fix with
the screw. Do not over-tighten the screw.
CHECKING FLEXIBLE HOSE FOR CLOGS
If there is noticeable abnormal noise when
using the vacuum or the suction power
suddenly drops, it is necessary to check the
flexible hose for clogs.
Frequently check air path to make sure it is
free of obstructions.
1. Remove attachments from the end of the
flexible hose.
2. Remove the flexible hose ends from
the main body and the lower hose
connection by pressing the hose release
buttons.
3. Check and remove any clogs in the
flexible hose.
4. Reinstall the flexible hose to the vacuum
cleaner. See ASSEMBLY INSTRUCTIONS
(page 9).
REMOVING CLOGS
WARNING
Disconnect electrical supply before
removing clogs. Failure to do so could
result in electrical shock or personal
injury.
Hose Release
Button
Hose Release
Button
Connection
Hose

Dust escapes
from the vacuum.
Dust cup is not installed correctly. Position dust cup correctly and snap firmly in
place.
Foam filter or felt filter is worn or
broken.
Check and replace the foam filter or felt filter.
To purchase parts, call 1-877-531-7321 (US) /
1-844-608-3081 (CA).
Brushroll does not
turn.
Brushroll is jammed. Call 1-877-531-7321 (US) / 1-844-608-3081
(CA) for assistance.
Brushroll is not installed correctly. Call 1-877-531-7321 (US) / 1-844-608-3081
(CA) for assistance.
The belt is not routed correctly. Check the belt routing on page 20-23.
The belt is worn or broken. Replace the belt. To purchase parts, call
1-877-531-7321 (US) / 1-844-608-3081 (CA).
Airflow restricted
with attachments
in use; sound
changes.
Air path is blocked. Check for and remove any clogs and clean the
air path. Follow instructions on page 24.
Attachments in use restrict air flow. Check attachments for fuzz, lint, pet hair or
other debris.
Vacuum turns off
on its own.
The power cord plug is loose from
the outlet when using the vacuum.
Reinsert the power cord plug fully into the
outlet. Avoid pulling or dragging the power
cord when using the vacuum.
The motor is damaged. Call 1-877-531-7321 (US) / 1-844-608-3081
(CA) for assistance.
- 26 -
TROUBLESHOOTING
Produktspecifikationer
Varumärke: | Kenmore |
Kategori: | Inte kategoriserad |
Modell: | DU1093 |
Behöver du hjälp?
Om du behöver hjälp med Kenmore DU1093 ställ en fråga nedan och andra användare kommer att svara dig
Inte kategoriserad Kenmore Manualer

12 Mars 2025

6 Januari 2025

6 Januari 2025

6 Januari 2025

6 Januari 2025

6 Januari 2025

6 Januari 2025

6 Januari 2025

6 Januari 2025

6 Januari 2025
Inte kategoriserad Manualer
- Inte kategoriserad Siku
- Inte kategoriserad Eltako
- Inte kategoriserad Madrix
- Inte kategoriserad Kubo
- Inte kategoriserad Yuede
- Inte kategoriserad Generation
- Inte kategoriserad Bruynzeel
- Inte kategoriserad Xaphoon
- Inte kategoriserad SWIT
- Inte kategoriserad Wachendorff
- Inte kategoriserad Pylontech
- Inte kategoriserad OneConcept
- Inte kategoriserad Nolte
- Inte kategoriserad Basetech
- Inte kategoriserad Momo Design
Nyaste Inte kategoriserad Manualer

9 April 2025

9 April 2025

9 April 2025

9 April 2025

9 April 2025

9 April 2025

9 April 2025

9 April 2025

9 April 2025

9 April 2025
