Sida 1/32
© B54-4761-00/00 (KW/K2W/RW)
GPS NAVIGATION SYSTEM
SYSTÈME DE NAVIGATION GPS
SISTEMA DE NAVEGACIÓN GPS
DNX SERIES
DNX6960 DNX6160 DNX6020EX
DNX6460BT DNX5160
MONITOR WITH DVD RECEIVER
MONITEUR AVEC RÉCEPTEUR DVD
MONITOR CON RECEPTOR DVD
DDX SERIES
DDX616 DDX6046BT DDX516
INSTALLATION MANUAL
MANUEL D’INSTALLATION
MANUAL DE INSTALACIÓN
B54-4761-0000DNX6-5KEnr1.indd1B54-4761-0000DNX6-5KEnr1.indd1 09.11.115:35:59PM09.11.115:35:59PM
2
|
DNX SERIES/ DDX SERIES
Installation Procedure
1
..........1
2*
1
..........1
3
DNX SERIES only
..........1
4
DNX SERIES only
..........1
5
..........1
6
..........6
7
..........6
8
..........2
9*
2
..........1
0
†
..........1
!
†
..........2
@
†
..........1
*
1
Accessory of DNX6960/
DNX6160/ DNX6020EX/
DNX6460BT/ DDX616/
DDX6046BT.
*
2
Accessory of DNX6960/
DNX6160/ DNX6020EX/
DNX5160.
†
This accessory is used when
connecting an external
device to AV-IN jack on the
front panel of this unit. For
how to use this accessory,
refer to the instruction
manual of this unit.
Accessories
1. To prevent a short circuit, remove the key from the
ignition and disconnect the - battery.
2. Make the proper input and output wire
connections for each unit.
3. Connect the speaker wires of the wiring harness.
4. Connect the wiring harness wires in the following
order: ground, battery, ignition.
5. Connect the wiring harness connector to the unit.
6. Install the unit in your car.
7. Reconnect the - battery.
8. Press the reset button.
9. Perform the Initial Setup. (Refer to the Instruction
Manual.)
2WARNING
• If you connect the ignition wire (red) and the battery wire
(yellow) to the car chassis (ground), you may cause a short
circuit, that in turn may start a fire. Always connect those
wires to the power source running through the fuse box.
• Do not cut out the fuse from the ignition wire (red) and the
battery wire (yellow). The power supply must be connected
to the wires via the fuse.
Acquiring GPS Signals
The first time you turn on DNX SERIES, you must wait
while the system acquires satellite signals for the first
time. This process could take up to several minutes.
Make sure your vehicle is outdoors in an open
area away from tall buildings and trees for fastest
acquisition. After the system acquires satellites for the
first time, it will acquire satellites quickly each time
thereafter.
After the Installation
After the installation, perform the Initial Setup by
referring to the instruction manual.
B54-4761-0000DNX6-5KEnr1.indd2B54-4761-0000DNX6-5KEnr1.indd2 09.11.115:35:59PM09.11.115:35:59PM
