www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

S7C

Quick Start Guide

Saga 7” On-Camera 4K Support HDMI/3G-SDI Monitor

What’s Included

1x S7C Monitor

1x Sun Hood

1x Power Adapter

1x Shoe Mount

www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

Getting Started

Button Notes

F1 - F3 Buttons: Fuctions can be mapped in the menu.

Directional Buttons: Used to navigate the menu button and can also be mapped in the menu.

Menu Button: Opens the menu options.

Battery Release Buttons: Press to release the batteries.

ON OFF

Power

Button

Source

Button

F1 - F3

Buttons*

HDMI Input/Output

Terminal

SDI Input/Output

Terminal

On/Off Switch

3.5mm Headphone

Output

DC 7-24V

Power Terminal

Directional

Buttons*

Battery Release

Button*

Battery Release

Button*

Buttons*

www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re tooﬁlmmakers

Conﬁguration of Setting Menus

Assistant

Single Color – Toggle between mono colors: gray, red, green, blue

False Color – This feature utilizes a full spectrum of assigned color indicators to show overall brightness of the image. This helps achiever perfect

exposure.

Peaking – The monitor is equipped with a color peaking feature which highlights the desired focus area in a bright color. The operator adjusts the focus

until the subject is surrounded with the color outline.

Peaking Color – Adjust the color of peaking: red, green, blue.

Zebra – The monitor will display slanted lines where the image is overexposed or underexposed.

Histogram – Graphical representation of the tonal values of your image.

Audio Meters – Allows the operator to monitor audio channels.

Guides

Crosshair – Display a crosshair on the center of the screen.

Safety Guides – Safety border between the following: 80%, 85%, 90%, 93%, 96%

Aspect Guides – Toggle border between 4:3, 2.35:1, 1.85:1

Guide Color – Change the color of guide: white, black, red, green, blue

Video Conﬁguration

Aspect Ratio – Toggle between Auto, 16:10, 16:9, 4:3, 1.85:1, 2.35:1
