Sida 1/49
B5A-2484-00 (M/M2/X)© 2018 JVC KENWOOD Corporation
DNX9180DABS
DNX9180S
DNX9180SM
GPS NAVIGATION SYSTEM
INSTRUCTION MANUAL
• Updated information (the latest Instruction Manual, system updates, new
functions, etc.) is available from
<http://www.kenwood.com/cs/ce/>.
• The Instruction manual is subject to change for modification of
specifications and so forth. Be sure to download the latest edition of the
Instruction manual for reference.
<http://manual.kenwood.com/edition/im396/>
Basic Operations
7English
Basic Operations
Functions of the Buttons on the Front Panel
9
8
1 2 3 4 5 6 7
NOTE
• The panels shown in this guide are examples used to provide a clear explanation of operations. For this reason,
they may be different from the actual panels.
Number Name Motion
1
Remote
Sensor
• Receives the remote control signal.
2
S R,
(Volume)
• Adjusts the volume.
The volume will go up to 15 when you keep pressing .R
3
NAV • Displays the navigation screen.
4
HOME • Displays the HOME screen .(P.12)
• Pressing for 1 second turns the power off.
• When the power is off, turns the power on.
5
MENU • Displays the popup menu screen.
• Pressing for 1 second switches view camera display on/off. (DNX9180S/ (P.57)
DNX9180SM only)
– The camera whose view is displayed first changes according to the "Camera
Setup" setting and the shift lever position in the shift gate.
• Pressing for 1 second turns the screen off. (DNX9180DABS only)
6
• Displays the APP (CarPlay/ Android Auto/ Air Mirroring) screen.
• Pressing for 1 second displays the Voice Recognition screen .(P.53)
7
G• Displays the Angle Adjust screen.
– : Ejects the disc.[ ]DISC EJECT
– : Fully opens the panel to the location of the SD card slot.[ ]OPEN
• When the panel is opened, pressing closes the panel.
• To forcibly eject the disc, press it for 2 seconds and then touch after the [ ]DISC EJECT
message is displayed.
8
Disc insert
slot
• A slot to insert a disc media.
Basic Operations
9English
Initial Settings
Initial setup
Perform this setup when you use this unit first
time.
1
Set each item as follows.
■[ ]Locale
Select the country for the navigation system.
The language, the distance unit, and the
gasoline unit are set.
1Touch .[ ]Locale
2Select the desired country.
■[ ]Language
Select the language used for the control
screen and setting items. Default is “British
English (en)”.
1Touch .[ ]Language
2Touch .[ ]Language Select
3Select the desired language.
4Touch [].
For details of operation, see User Interface
Setup (P.62).
■[ ]Display
Set the button illumination color.
If it is hard to see the image on the screen
even, adjust the viewing angle.
1Touch .[ ]Display
2Touch [Key Colour].
3Select the desired color.
4Touch [].
5Touch [Viewing Angle].
6Select an angle
7Touch [].
For details of, see Display Setup (P.64).
■[ ]Camera
Set the parameters for the camera.
1Touch .[ ]Camera
2Set each item and touch [].
For details of, see Camera Setup (P.57).
■[ ]DEMO
Set the demonstration mode. Default is “ON”.
1Touch and select ON or OFF.[ ]DEMO
■[3way X'over]
Displays the message screen.
For detailed operation, see 3 way speaker
system setup (P.67).
2
Touch [ ]Finish .
NOTE
• These settings can be made from the SETUP
menu. See Setup (P.61).
Security Code Setup
You can set up a security code to protect your
receiver system against theft.
When the Security Code function is activated,
the code cannot be changed and the function
cannot be deactivated. Note that the Security
Code can be set with a 4 to 8 digit number of
your choice.
1
Press the button.[ ]MENU
Popup menu appears.
2
Touch [ ]SETUP .
SETUP Menu screen appears.
