Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new product.
© 2023 JVCKENWOOD Corporation
CA-GRL14SG
METAL MESH SPEAKER GRILLES DESIGNED AND ENGINEERED FOR
2014+ HARLEY-DAVIDSON® RUSHMORE PLATFORM STREET GLIDE®
AND ULTRA CLASSIC MOTORCYCLES
INSTRUCTION MANUAL
JVCKENWOOD Corporation
Important Notes
©2023 JVCKENWOOD Corporation. All Rights Reserved. KENWOOD® and eXcelon®
are registered trademarks of JVCKENWOOD Corporation. Harley-Davidson®, Electra
Glide®, Road Glide®, Street Glide®, Ultra Classic®, Tri Glide®, CVO™, Screamin Eagle®
and Tour-Pak® are trademarks or registered trademarks of Harley-Davidson, Inc. and/
or its affiliates and if used or implied are for reference only. There is no affiliation
between Harley-Davidson, Inc. and/or its aliates and JVCKENWOOD Corporation
and/or its aliates. All other trademarks are the property of their respective owners.
Specications subject to change without notice.
Metal Mesh Speaker Grilles Installation Instructions
Installation procedure
1. Remove your outer fairing.
NOTE: A towel or something similar is suggested to be placed over your front fender to
help in preventing dings or scratches during installation.
2. Speaker Cabinet Removal: On the brake side speaker cabinet, carefully remove the cable
going into the power port/cigarette lighter assembly. If your bike has the CB module
mounted “sideways” on the clutch side cabinet, undo the antenna cable and main harness.
The CB Module will stay attached to the clutch side cabinet when removed. Undo the
speaker wire plugs going into each cabinet (pink/pink black wires).
3. Installing The Grille: Undo the 3 screws that attach the factory grille to the inner fairing
and put them aside (The KENWOOD grille is installed using the 3 factory screws just
removed). In the KENWOOD grille, you will see two holes and one “keyhole” where the
screws go through and into the fairing. The keyhole in the KENWOOD grille needs to be
oriented so it is closest to the radio on each side to ensure proper fitment. With the new
grille in place, the cabinet can be re-installed to the bike.
4. Repeat Step 3 for the second cabinet. Plug the factory speaker wires back into each
cabinet’s speaker wires. Be sure to plug the power cable back into the power port/
cigarette lighter assembly on the brake side. If your bike has the CB module, make sure to
re-install the antenna cable and main harness, then re-install your fairing and windshield.
NOTE: We STRONGLY suggest completing
the grille swap on one side and then
moving to the other side!
Fig 1.1 and 1.2 have arrows that point to
the factory fasteners that will need to be
removed to allow the cabinets to come
out of the bike. Although the Brake Side is
shown, fastener locations are common for
both brake and clutch side cabinets.
Fig 1.1 Side View of
Brake Side Cabinet
Fig 1.2 Back View of
Brake Side Cabinet
For updated information (the latest Instruction Manual, etc.),
please visit the following website:
https://manual.kenwood.com/en_contents/search/
