important - UK only

attachment outlets

the mixer

safety

Switch off and unplug before fitting or removing tools/attachments, after

use and before cleaning.

This machine is not intended for use by young children or infirm persons

without supervision.

Keep your fingers away from moving parts and fitted attachments.

Never leave the machine on unattended.

Never use a damaged machine. Get it checked or repaired: see

‘service’, page 6.

Never use an unauthorised attachment or more than one attachment

at once.

Never exceed the maximum capacities on page 2.

Don’t let children play with this machine.

When using an attachment, read the safety instructions that come with it.

Only use this machine for domestic food preparation.

before plugging in

Make sure your electricity supply is the same as the one shown on

the underside of your machine.

The wires in the cord are coloured as follows:

Blue = Neutral, Brown = Live.

This machine complies with European Economic Community Directive

89/336/EEC.

before using for the first time

Remove all packaging.

Wash the parts: see ‘care and cleaning’, page 6.

know your Kenwood kitchen machine

high-speed outlet

citrus juicer outlet

slow-speed outlet

tool socket

mixer head

outlet catch

bowl

head-lift lever

on/off and speed switch

power unit

K-beater

whisk

dough hook

spatula

know your Kenwood kitchen machine

KENWOOD CHEF KM300, 400, 410 / MAJOR KM600, 800, 810

●

































   

















K-beater

whisk

dough hook

to insert a tool

to remove a tool

hints

important

shortcrust pastry

stiff yeast dough

soft yeast dough

fruit cake mix

egg whites

K-beater

whisk

dough hook

the mixer

●

the mixing tools and some of their uses

For making cakes, biscuits, pastry, icing, fillings, éclairs and mashed

potato.

For eggs, cream, batters, fatless sponges, meringues, cheesecakes,

mousses, soufflés. Don’t use the whisk for heavy mixtures (eg creaming

fat and sugar) - you could damage it.

For yeast mixtures.

to use your mixer

Turn the head-lift lever anti-clockwise and raise the mixer head till it

locks.

Turn till it stops then push.

Fit the bowl onto the base - press down and turn clockwise 

Turn the head-lift lever anti-clockwise and lower the mixer head till it locks.

Select a speed, then switch on by turning the speed switch.

Switch to pulse for short bursts.

Unscrew.

Switch off and scrape the bowl with the spatula frequently.

Eggs at room temperature are best for whisking.

Before whisking egg whites, make sure there’s no grease or egg yolk

on the whisk or bowl.

Use cold ingredients for pastry unless your recipe says otherwise.

points for bread making

Never exceed the maximum capacities below - you’ll overload the

machine.

If you hear the machine labouring, switch off, remove half the dough

and do each half separately.

The ingredients mix best if you put the liquid in first.

maximum capacities

KM300, 400, 410 models KM600, 800, 810 models

Flour weight: 680g - 1 8lb oz Flour weight: 910g - 2lb

Flour weight: 1.36kg - 3lb Flour weight: 1.5kg - 3 5lb oz

Total weight: 2.18kg - 4lb 13oz Total weight: 2.4kg - 5 5lb oz

Flour weight: 1.3 2.6kg - 2lb 14oz Flour weight: kg - 5lb 12oz

Total weight: 2.5kg - 5lb 8oz Total weight: 5kg - 11lb

Total weight: 2.72kg - 6lb Total weight: 4.55kg - 10lb

12 16

speeds 

creaming fat and sugar start on min, gradually increasing to ‘max’.

beating eggs into creamed mixtures 4- ‘max’.

folding in flour,fruit etc Min - 1.

all in one cakes start on min speed, gradually increase to max.

rubbing fat into flour min - 2.

Gradually increase to ‘max’.

Start on ‘min’, gradually increasing to 1.

for cleaning see page 6

KENWOOD CHEF KM300, 400, 410 / MAJOR KM600, 800, 810









troubleshooting

solution

●

problem

The whisk or K-beater knocks against the bottom of the bowl or isn’t

reaching the ingredients in the bottom of the bowl.

Adjust the height. Here’s how:

Unplug.

Raise the mixer head and insert the whisk or beater.

Hold it, then loosen the nut 

Lower the mixer head.

Adjust the height by turning the shaft. Ideally the whisk/K-beater should

be almost touching the bottom of the bowl 

Raise the head, hold the whisk/K-beater and tighten the nut.

to fit and use your round/D-shaped

splashguard (if supplied)

Raise the mixer head until it locks.

Fit the bowl onto the base.

Push the splashguard on until fully located . The hinged section

should be positioned as shown round  and D-shaped

Insert required tool.

Lower the mixer head ensuring the splashguard follows the shape of

the bowl.

During mixing, ingredients can be added directly to the bowl via the

hinged section of the splashguard.

You do not need to remove the splashguard to change tools.

Remove the splashguard by raising the mixer head and sliding it down.

KENWOOD CHEF KM300, 400, 410 / MAJOR KM600, 800, 810










